LR-26B, LR-27B, LR-28A, or LR-623
Stock No. 03 5804
Page 2 of 19
IMPORTANT FACTS ABOUT THIS MANUAL
The Rugby®model SF-26B, SF-28A, and SF-623 hoists are installed with a sub-frame. The model
LR-26B, LR-27B, LR-28A, and LR-623 hoists are installed without a sub-frame. If you are install-
ing an LR-26B, LR-27B, LR-28A, and LR-623, this manual (Part #03 5804) is the correct manual.
If you are installing an SF-26B, SF-28A, or SF-623, this manual (part #03 5804) is the incorrect
manual to use. The correct manual (Part #03 6077) should be obtained and used. This manual
(part #03 5804) covers only the installation of the hoist itself and the rear hinge.
This manual does not cover the installation and operation of the body prop or body props. The
installation and operation of the body prop or body props is covered in the manual #03 6034. The
#03 6034 manual is included in every LR-26B, LR-27B, LR-28A, or LR-623 application sold by
Rugby Manufacturing Co.
This manual (part #03 5804) does not cover the installation and operation of the hydraulic system.
There are four different types of hydraulic systems available for some or all of the hoist models
(LR-26B, LR-27B, LR-28A, or LR-623).
The four types of hydraulic systems and their respective installation and operation manuals are listed
below:
Installation and Operation Type of Hydraulic System
Manual Part Number
03 5679 Drive shaft driven pump with mid-latch cable
03 5650 Direct Mount Pump with tower control
03 5669 Electric double acting with push button control
03 5670 Electric single acting with push button control
Depending on the type of hydraulic system purchased, one of the above manuals will be included in
every LR-26B, LR-27B, LR-28A, or LR-623 sold by Rugby Manufacturing Co. Before installing
one of the before mentioned hoists, be sure you have the proper manuals to do the job. If you do not
have the correct manuals contact Rugby Manufacturing Co.
