RSA Lighting ACCURUS ACT951MH User manual

DESCRIPTION Catalog # Type

Project

Comments Date

Prepared by

www.cooperlighting.com

SPECIFICATION FEATURES

7.25”

12.00”

13.00”

8.18”

4.63”

0.5” - 1.0”

Ceiling

Cut-Out

4.50”sq.

A...Housing

Housing and plaster frame: 18 gauge CRS

with ﬂat black powder coated internal

ﬁnish. Adjustable plaster frame can

accommodate up to 1” ceiling thickness.

B ...System Protection:

Thermal protection provided to guard

against overheating and misuse of

insulation over and around ﬁxture.

Vent holes in housing provide cooler

operation.

C ...Electrical

Integral j-box and electronic metal halide

ballast. 120V/277V input. Junction box

is U.L. listed for through branch wiring.

Includes ﬁve 1/2 trade size knockouts.

D...Lamp

MR16 metal halide lamp 20 or 39 watts.

GX10 TAL lamp socket included. Internal

rotation ring with locking adjustment.

Provides 360º rotation of trim and secures

original trim position after relamping.

E ...Mounting

Hanger Bars and Butterﬂy Brackets

included for residential and commercial

applications respectively.

Ceiling Cut-Out: 4.50” sq.

ACCURUS

ACT951MH

New Construction

Metal Halide

Housing

for 5” Square Trim

FOR METAL HALIDE MR16

20W or 39W

ORDERING INFORMATION

Housing

ACT951MH =

Accurus New Construction

Housing for Square Trim

w/Integral Metal Halide Ballast

Voltage

120 =120 volts primary

277 =277 volts primary

New construction housing for Accurus square trims. Includes electronic

metal halide ballast for use with 20W or 39W MR16 Metal Halide lamp.

For new construction applications. Insulation must be kept 3” from all

sides and at least 1” above the housing.

Speciﬁcations and Dimensions subject to change without notice.

RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX 818-349- 3031

Lamp Wattage

20 =20 watts

39 =39 watts

ACT951MH

rev 122007
