Royal Sovereign Paramount 65X User manual

Paramount 65X

Royal Sovereign International Inc.

Owner's Manual

GRAPHIC LAMINATION

PRODUCTS

Please read and retain these instructions.

To register your product, please go to www.royalsovereign.com

www.royalsovereign.com

CONTENTS

1. Introduction 3

2. Safety Precautions 4

4. Installation 5

5. Product Identification7

6. Control Panel 8

7. Using Foot Pedal 9

8. Loading Film 9

9. Threading Film 9

9.1 Decaling 10

9.2 Mounting 10

10. Maintenance 10

11. Troubleshooting 11

12. Specifications 12

13. Warranty 13

Graphic Lamination Products

1. INTRODUCTION

Thank you for choosing a Royal Sovereign laminator. It has been designed and

manufactured to provide years of continuous service.

For complete operating and maintenance information please read this manual

thoroughly. Upon receipt of your laminator, please inspect the box, the machine and all

other contents for shipping damage.

Damage should be brought to the immediate attention of the delivering carrier

Model Paramount 65X

2. SAFETY PRECAUTIONS

Failure to comply with any of the following safety procedures could result in serious injury.

Please read the instructions carefully and keep for future reference.

1. Only a licensed electrician should install wiring and outlet for the laminator.

2. Ensure the unit is plugged into a properly grounded outlet with the correct voltage.

3. Make sure the pressure value is less than 0.6 MPa (87PSI) which can be adjusted it by the regulating

valve which is located in the body on the right hand side then connect the air pipe to the air intake.

4. Keep hands and clothing (i.e. Neckties) away from rollers. The rollers have pinch points that can trap

body parts or clothing and cause serious injury.

5. Keep ammable and wet objects away from the machine.

6. Place machine on a level surface,then set the moveable feet down to oor to keep the machine steady.

7. Avoid excessive sunlight, humidity and extreme temperatures.

8. Ensure the unit is turned o, cooled, and unplugged from the outlet prior to moving and/or repairing.

9. Keep out of reach of children.

10. Only Royal Sovereign authorized maintenance and service technicians should make repairs.

11. Do not attempt to laminate items that exceed total recommended material thickness for the unit

12. When cleaning the machine, don't use ammable sprays or materials.

13. Do not touch the rollers when they are hot or place foreign objects inside the machine.

14. Do not cover the surface of the machine until the machine has completely cooled.

15. In the event of an emergency, press emergency switch immediately.

16.Temperature of circumstance: 20°C ± 5°C; humidity of circumstance < 95% (20°C ± 5°C)

17. Warning - Hazardous Moving Parts – Keep Fingers And Other Body Parts Away.

Paramount 65X

3. INSTALLATION

Note: The laminator should be installed by a trained service technician.

The laminator comes fully assembled, except for the feed table and paper guide to avoid shipping damage. Upon arrival,

thoroughly inspect the unit. It is imperative that any shipping damage is reported and a claim is filed with the delivering

carrier immediately upon receipt.

The laminator should be located in an area with adequate work space for feeding graphics and lamination materials.

Avoid placing the laminator in a dusty area or near sources of extreme heat or cold.

Once the laminator is in place, lock the casters into position. Always unlock the casters when moving to a different location.

ELECTRICAL REQUIREMENTS

Royal Sovereign recommends that a licensed electrician ensures proper power installation to your laminator in accordance

with electrical codes in your area.

The laminator should have a dedicated power line.

120V UL 230V UL 240V UK

220V EU 220V AU

4. INCLUDED WITH LAMINATOR

Thoroughly inspect the parts and the unit. It is imperative that any missing parts are reported and a claim is filed with the

reseller immediately upon receipt of shipment.

Part Name Quantity Picture

Laminator 1

Owner's Manual 1

Spare Motor Fuse - FUSE(50T)

(6.3A) 1

Spare Main Power Fuse - FUSE(65TS)

10A/20A 1

Key 2

Paramount 65X

5. PRODUCT IDENTIFICATION

1Film Tension Knob 9Shaft Feeder

2Shaft Release Liner 10 Air Intake

3Emergency Switch 11 Knob Speed Control

4Roller 12 Button

5Safety Sensor 13 Pressure Gauge

6Table Front 14 Pressure Regulating Valve

7Foot 15 Pneumatic Toggle

8Foot Switch 16 Door Lock

6. CONTROL PANEL

Heat

To change the mode from cold to heat assist.

Temperature for heat assist on upper roller is

max 122°F/50°C.

Reverse To reverse the rollers, press and hold the button.

Speed Rotate the knob to control the roller’s speed from

0 to 19.7 ft/min.

Run/Stop To start or stop the rollers.

Pressure gage: To indicate the pressure of top roller from

0 to 1Mpa (145Psi) pressure value

Pressure regulating valve: To change the pressure of top roller

from 0 to 0.6Mpa (87Psi) pressure value

Pneumatic Toggle: To make the top roller go up and down

Paramount 65X

7. USING FOOT PEDAL

Place the foot pedal on the floor in front of the machine. Once all correct settings are displayed,

you may use the foot pedal to operate the laminator for “Hands Free Operation.” To activate

the machine, press the foot pedal once and then release. Repeat to stop the rollers.

8. LOADING FILM

Royal Sovereign films are wound with the adhesive side facing the inside of the roll

(adhesive in).

Loading films to upper and lower film shafts:

Remove the upper and lower film shafts from the machine and load the films (Center the upper and lower films on the shaft).

Note the direction of the adhesives on the lower and upper films

9. THREADING FILM

1. Turn the power switch on (“I” position). The Power switch is located on the rear left side of the unit.

2. Complete the steps as in the “LOADING FILM” section

3. Pull the top lm down to the bottom of the craft paper/mounting lm.

4. Align and center the craft paper/mounting lm to the top lm

5. Peel the top lm o

Please adjust the wheel to change the roller pressure with dierent material for the best laminating quality.

1. Lay the decaled image face down on a at surface. Carefully peel back and put a crease along the

edge of the release liner

2. With the image facing up, align the image onto the board. Press rmly from the center out.

3. Adjust the pressure lever to ensure the proper opening.

4. Flip the image over the upper roller and hold on to the release liner.

5. Press the foot pedal once, and then let it go while slowly pulling the release liner as the board enters

the main roller nip.

Press the foot pedal once again when the board has completely exited from the rear of the unit.

Trim the board if necessary.

10. MAINTENANCE

Cleaning the Body of the laminator

1. To clean the machine body, dampen a cloth with water only and gently wipe the machine clean.

Removing Adhesive Build Up

1. Remove the lm from the laminator.

2. Use a damp (water only) cloth and a rubber gum eraser to remove the adhesive on the

Teon (metal) and silicone rollers.

Note Rub rmly but do not scrub the rollers vigorously as this may scratch the surface.

Do not use sharp metal objects, steel wool, or abrasives, as these may also damage the rollers.

Lubrication

1. Drive chain and sprockets should be lubricated with either a light coat of gear lube or

heavy grease (lithium grease) after 6 months or 1000 hours of operation, whichever comes rst.

9.1. Decaling

9.2. Mounting
