Royal Enfield Classic 350 2021 User manual

BS VI - SIGNALS

FOREWORD

We congratulate you on your choice of the legendary Bullet motorcycle and welcome you to the exciting world

of motorcycling on a Royal Enfield. This manual will help you to operate your Classic 350 Signals motorcycle, the

right way and guide you to maintain your motorcycle meticulously. We have also provided tips on safe riding

and on minor adjustments for the care of your motorcycle. Please avail four free and three paid services at the

nearest Royal Enfield Authorised Dealer / Service Center, at the appropriate time to maintain your Bullet

motorcycle in top riding condition. Log on to the exciting world of Royal Enfield website: www.royalenfield.com

to get to know more about the company, its products and exciting news from time to time. We request you to

carefully read the terms and conditions of warranty and other useful information given in this manual before

starting to use your Bullet Motorcycle.

NOTICE

All information in this manual is based on the latest product information available at the time of publication. Due to continuous

Part No. RAM00208/A / Qty. 10,000 / Oct. 2021 / 10134

improvements, there may be discrepancies between the information in this manual and your motorcycle. Royal Enfield reserves

the right to make production changes at any time without prior notice and without incurring any obligation to make the same or

similar changes to motorcycles previously built or sold.

All images shown are for reference to explain and need not to be exactly the same on the model you own. Technical specifications

are subject to change without prior notice.

or otherwise dealt without the express permission in writing of Royal Enfield”.

NOTE: BS VI - This m otorcy cle meets

E mi ss i on No r m s - Bh ar at ( Tr e m )

St ag e - VI

D i s c l a i m e r

Applicable for all Matt finish motorcycles

1. Do not polish matt finished paint surfaces in your motorcycle as it will

increase the gloss level.

2. Wash the painted parts only with plain water and do not use any strong

solvents, cleaning agents or detergents.

3. Scratches, if happens on the matt finish parts cannot be touched up and

corrected / removed.

4. Warranty is not applicable for any matt finished painted parts of the

motorcycle.

5. The Heat Resistance Coated components such as silencer pipe, exhaust

etc... shall not be wiped clean with oiled cloth as it can generate smoke

when the vehicle is driven and also leave patch marks.

D i s c l a i m e r

Please note that in case of fuel tank

replacement, for any reason or under any

circumstances, we will not be able to

supply fuel tank with the same or a

preferred serial number.

CONTENTS

Personal and Motorcycle Information 4

Technical Specifications 5

Recommended Lubricants 8

Safety Definitions 9

Motorcycle Identification Numbers 10

Location of Key Parts 11

Operation of Controls 14

Pre-Operational Checks 18

Safe & Happy Riding 19

Running in Period 20

Warning Indications & Safety Systems 21

Starting 25

Gear Shifting, Riding & Stopping 26

Parking 27

Periodical Maintenance Chart 28

Tools & First Aid kit 31

Wheel Removal & Assembly 32

Minor Maintenance Tips 37

Long Trip Precautions 48

Washing Procedure 49

Storage Precautions 50

Trouble Shooting 51

Warranty Terms & Conditions 53

Emission Warranty 55

EVAP 58

Environment Care 60

Service & Maintenance Record 61

Regional & Area Offices 63

Notes 64

PERSONAL & MOTORCYCLE INFORMATION

Name

Door No./Street

Locality

City State Pin

Contact Nos. Res: Off: Mobile : Email :

Engine No. Battery No.

Frame No. Battery make

Reg. No. Licence No.

Date of Sale Valid till dt.

Model Key No. :

Tyre make Colour

Sold by Dealer Code

ENGINE

Engine Type ............. Single Cylinder 4 Stroke

Bore ............................ 70 mm

Stroke ......................... 90 mm

Swept volume .......... 346.36 cc

Compression ratio . 8.5+0.3:1

Maximum Power ..... 14.08 kW @ 5250 rpm

Maximum Torque .. 28 Nm @ 4000 rpm

Idle rpm .................... 1050+100

Starting ...................... Kick Start

............................. E-Start

Air filter element .... Paper element

Lubrication ............... Wet sump

Engine oil capacity 2.75 l (First Fill only)

............................. 2.30 to 2.50 l (subsequent refills)

Engine oil grade .... SAE 15 W 50 API SL Grade &

............................. Above JASO MA2 Semi Synthetic

Cooling ...................... Natural air flow

IGNITION SYSTEM

Ignition system ........ Electronic ignition ECU/Variable

Spark plug Electrode gap

WQR8DC : 0.80 to 0.90 mm

Spark plug ............... WQR8DC M14 (Bosch)

TRANSM ISSION

Clutch ......................... Wet multiplate (6 plates)

Primary drive .......... Duplex chain

Primary ratio ........... 2.15 : 1

Gear box .................. Constant Mesh, 5 Speed

Gear Ratio ................ 1 3.06:1

............................. nd

2 2.01:1

............................. rd

3 1.52:1

............................. th

4 1.21:1

............................. th

5 1:1

Final drive ................ 16 Teeth (Sprocket)

Final Ratio ................ 2.375:1

Drive Chain links .... 102 links

C A U T I O N

nThe use of petrol containing more than the specified ethanol

may cause the fuel tank corrosion & paint damage and may

also damage the rubber tubes in the fuel line as well.

nIt is recommended to use only unleaded petrol, as leaded

petrol may cause damage to the catalytic converter.

Tyre Pressure

Solo Front ............... 20 psi/1.41 kg/cm

Rear ............... 30 psi/2.11 kg/cm

With Pillion Front ............... 22 psi/1.55 kg/cm

Rear ............... 32 psi/2.25 kg/cm

Steering Lock ........................ In built

Fuel Type ........................ Unleaded Gasoline

Ethanol Content ..................... E10 or less

Minimum Octane rating ...... 91 RON (Research Octane

........................ Number) or Higher

Fuel tank capacity ................. 13.5 l approx.*

Low fuel warning .................. 4+0.5 l approx.*

* The above values are approximate and the actual fuel filling

capacity will vary from the values mentioned.

ELECTRICALS

Generation .............................. Alternator (III Phase)

System ...................................... 12 V - DC

Battery ...................................... 12 V - 12 Ah MF

Head lamp .............................. 12 V, H4-60/55 W (Halogen)

Brake/Tail lamp ...................... 12 V, P21/5 W

Parking lamp ........................... 12 V, 2 W X 2 Nos.

Position lamp .......................... 12 V, 4 W

CHASSIS

Type ............... Single downtube, using engine

............... as stressed member

Frame ............... Tubular

Suspension Front ...... Telescopic, 35 mm forks, 130 mm travel

Rear ....... Twin gas charged shock

............... absorbers with 5 step adjust

............... able preload, 80 mm travel

Brakes ............... Hydraulic Disc Brakes Front

............... & Rear with ABS System

Front: ..... 280 mm dia disc with twin

............... piston caliper

Rear: ...... 240 mm dia disc with single

............... piston & floating caliper

Tyre size Front ...... 90/90 X 19” - 52 P

Rear ....... 110/90 X 18” - 61 P

Speedometer lamp ................ 12 V, 3.4 W

High beam indicator .............. 12 V, 1.7 W

Neutral lamp tell tale ............... 12 V, 1.7 W

Turn signal tell tale .................. 12 V, 1.7 W

Turn signal ................................. 12 V, 10 W X 4 Nos.

Horn .............................................. 12 V, 2.5 Amp (Max.)

Starter Motor ............................. 12 V, 0.70 kW

Warning Indicator lamps ...... 12 V, 1.7 W x 3 Nos

DIMENSIONS

Length ............................ 2160 mm

Width ............................... 790 mm (without mirrors)

Height ............................. 1090 mm (without mirrors)

Wheel base ................... 1390 mm

Ground clearance. .... 135 mm

Saddle Height .............. 800 mm

WEIGHTS

Kerb weight (90% fuel & oil) .... 195 kg

Gross Vehicle Weight ................... 350 kg

Luggage load carrier ............... Should not be more

.................................................. than 15 kg

nValues / Dimensions given above are for your guidance only.

nIn view of continuous improvements being done on our products, the specifications are likely to change

without prior notice.

W A R N I N G

Using bulbs / other electrical gadgets other than specified

rating may lead to over loading / erratic behaviour / premature

failure of electrical system.

Modifications on the motorcycle which are not approved by

Royal Enfield may not only disqualify for warranty, but also

affects performance of the motorcycle.

RECOMMENDED LUBRICANTS

Grade SAE 15 W 50 API SL Grade &

Above JASO MA2

Semi Synthetic

Capacity 2.75 l (First Fill only)

2.30 to 2.50 l

(during oil & filter element

replacement in periodical

maintenance)

Use of Wrong grade oil will reduce the life of the moving parts and seriously affect performance.

C A U T IO N

Eng in e Oi l

DO NOT Mix DOT 4 & Other brake fluid together.

Grade Royal Enfield Front

Fork Oil (or 1F

Grade Endurance)

Capacity 195 ml/leg

Fr ont Fo rk Oil

Capacity Front : 100 ml

Rear : 100 ml

Grade DOT 4

B r ake F l u id

NOTE

Recommendation subject to change without notice.
