Roth Touchline Reference guide

ROTH TOUCHLINE ROOM THERMOSTAT

TYPICAL SYMBOLS THAT APPEAR IN THE DISPLAY OF THE ROOM

THERMOSTAT AND EXPLANATION TO THE SENSOR BUTTON

To increase the temperature press up

To decrease the temperature press down

Does this symbol light up? Change the batteries - 2 pcs. AAA 1,5V

Stand by (frost protection)

Reduced operation

Normal operation

OK button

Cancel

In order to increase or decrease the temperature on the thermostat, the thermostat must be active.

This is done by pressing the botton or for 2 seconds. Then you can adjust the temperature.

The new, desired temperature will be increased or decreased within a 0,5° interval.

The new, desired temperature will blink a few times and then the thermostat will show the actual

temperature in the room.

Please find a complete manual on roth-nordic.com under ”Downloads”. It is possible to adjust Touchline with

an app to iPhone, iPad or iPod. Buy the app in App Store and adjust the floor heating no matter where you are.



✓

Increase temperature

Menu button

Decrease temperature

Cancel button

OK button

Battery nearly empty

Actual temperature

in the room

The room

thermostat is on

standby

Time program

should be o

The room thermostat

has reduced operation

Normal operation

EXPLANATION TO THE SYMBOLS THAT CAN APPEAR IN

THE DISPLAY OF THE ROOM THERMOSTAT

Battery nearly empty

Relative energy consumption

Dew-point alarm (only when dew-point sensor is connected)

Window contact (only with accessory, will be available during 2013)

Wireless signal

Loss of wireless connection

General alarm

Operation disabled

Working days

Weekend

• Time and date

• Time program

Actual temperature

Room temperature

Floor temperature (only IR-version)

O (frost protection)

Reduced operation

Normal operation

Time program with external clock

Time program 1, 2 and 3

Cooling mode

Cooling lock

Heating mode

AUTO Auto mode: heating and cooling mode controlled by wireless









eco eco

°C
