Rose electronics CRV-R1V User manual
VideoSplitter CAT5
WWW.ROSE.COM
Video splitter over CAT5 cable
Splits, amplifies, and extends video from a single
video source to 6 or 12 monitors simultaneously
over CAT5 cable
Video resolutions up to 1600 x 1200
Each remote monitor can be up to 1,000 feet away
using industry standard CAT5 UTP cable
Optional Audio and Serial
Features and Benefits
JExtends a single video source to 6 or 12 video
monitors using CAT5 twisted pair, solid core cables
(Up to 1,000 feet)
JSerial and Full stereo audio (optional)
JVideo resolutions up to:
1600 x 1200 at 200 feet,
1280 x 1024 at 300 feet,
1024 x 768 at 1,000 feet
(Video resolution will vary depending
on the remote unit model used)
JEasy to install
JRack mountable chassis
The VideoSplitter™ CAT5 Advantage
The VideoSplitter CAT5 is the extender of choice for
businesses big and small that need to take a single
video source and extend it to remote monitors. The
serial/audio model takes a serial signal and full stereo
signal and distributes it to remote stations.
VideoSplitter CAT5 allows you to position 6 or 12
video monitors, speakers, and serial device (optional
serial and audio) up to 1,000 feet away from the
source using common twisted pair CAT5 cable. Each
of the modules connects to a CrystalView remote unit.
The VideoSplitter CAT5 is designed for plug-and-play
operation. First, connect the computer video (serial
and audio optional) to the local unit. Next, route the
CAT5 cable between the local and remote units.
Finally, connect the keyboard, monitor, and mouse
(serial and audio optional) to the remote unit. Now it is
ready to use.
Presentations, slide shows, schedules, and other
types of common information can be centrally
generated and displayed simultaneously on all remote
monitors. The serial and audio models can distribute
these signals to the remote stations.
Standard CAT5 connectors
Phone: 281-933-7673 E-mail: [email protected]
10707 Stancliff Rd. Houston, TX 77099
Rose Electronics – Europe: +49 (0)2454 969442 Rose Electronics – Asia: +65 6324 2322
DS-CRVVS- 2.2 Copyright Rose Electronics 2004. All rights reserved WWW.ROSE.COM
Typical Application
Display the video source on up to 12 remote monitors
(Serial/Audio optional model shown)
Introduction The VideoSplitter CAT5 is a versatile and
powerful product that extends the range to your
monitors up to 1,000 feet using industry standard CAT5
twisted pair cables. Serial and audio model extends
these signals to the remote station.
The system consists of the local VideoSplitter CAT5 and
a remote unit for each monitor used. The local unit
connects to your computer, The remote unit connects
to a video monitor (serial device and speakers –
optional) and the local and remote units are connected
together with industry standard CAT5 cable. Each
module (6 or 12) connects to a remote CrystalView unit.
Installation Installing the VideoSplitter CAT5 unit is a
very easy process. First, mount the VideoSplitter CAT5
Rack securely in your console rack. Next, connect a
CPU’s monitor port or other video source to the unit
using the appropriate adapter cable. Connect the audio
out/in and serial ports to the unit on the serial/audio
models. Connect a CAT5 cable between each module’s
RJ45 connector to a CrystalView remote unit’s RJ45
connector. Connect a monitor to the remote units
HD15F connector and power up the computer or video
source and the remote unit. Connect stereo speakers
and serial device to t he serial and audio model
(optional)
Operation Once the Remote and Local Unit modules
are connected and configured, the Remote video
monitors will all display the same image created by the
computer or video source. If the CrystalView Plus is
used for the remote units, a keyboard can be
connected to the unit to adjust the video compensation
if needed.
Part Numbers
CRV-6SLP-VS 6-Single video local units
CRV-12SLP-VS 12-Single video local units
/AUD suffix Serial and audio option
Optional Remote model
CRV-R Remote unit
CRV-MR Mini Remote unit**
CRV-R1V*** CrystalView Plus (Single video)
CRV-R2V*** CrystalView Plus (Dual video)
CRV-R4V*** CrystalView Plus (Quad video)
CRV-6SRP CrystalView Rack (Remote model)
/AUD suffix Serial and audio option
Cables and power adapter
CAB-08UTPnnn* Cable - CAT5 UTP (25-1,000 feet)
CAB-C1Y0000Cnnn*DB25M to HD15F
CAB-D9F6XD9M 1-DB9F to 6-DB9M
TFR-05D200FSUB Optional 5.0 V power adapter.
* nnn = length in feet
** Max length = 150’ using the Mini remote
*** CrystalView Plus remote will require multiple input
ports
Specifications
Dimensions Width Depth Height Weight
6-port unit 17in 4.2in 1.75in 3.75 - 4.00lbs
12-port unit 17in 4.2in 3.50in 5.00 - 5.50lbs
Chassis Aluminum
Resolution
<200’
200’ – 300’
300’ – 1,000’
1600 x 1200
1280 x 1024
1024 x 768
Connectors
CPU in
Link
Audio
Serial
DB25F
RJ45
(2) 3.5 mm stereo audio jacks
DB9
Power 5VDC external power adapter
Environmental 0°C - 45°C / 32°F - 113°F
0% - 80% RH non-condensing
Rear View (Video only model)
Rear View (Serial/Audio model)
