Rocket Fish RF-BTHP02 User manual
Bluetooth Stereo Headset
RF-BTHP02
User Guide
2
Bluetooth Stereo Headset
Contents
Features ......................................................................... 3
Package contents ................................................ 3
Components ......................................................... 4
Using your headset.................................................... 5
Charging the battery ......................................... 5
Turning your headset on or off ...................... 6
Pairing your headset .......................................... 6
Pairing a phone to your headset ................... 7
Multi-pairing method ........................................ 7
Using phone functions...................................... 8
Listening to music............................................... 9
Adjusting the volume ........................................ 9
Using EQ sound ................................................... 9
Resetting your headset ...................................10
LED status information....................................10
Troubleshooting .......................................................12
3
RF-BTHP02
Specifications ............................................................ 13
Legal notices.............................................................. 13
One-year limited warranty ................................... 15
Features
• Wireless Bluetooth connection to your wireless MP3
player, mobile phone, or PC
•Behind-the-headdesign
• Three EQ sound modes
• S u p p o r t s H S P, H F P, A 2 D P, AV R C P, a n d B l u e t o o t h 2 . 1
• Seven hours continuous music playback
•ACandUSBcharging
Package contents
• Bluetooth stereo headset
• AC power adapter
• Removable USB charging cable
•QuickSetupGuide
4
Components
#Component Description
1 Volume – button Press to decrease the volume.
2Power/talk button
3 Volume + button Press to increase the volume.
4LED
5Microphone
6Backward button Press to go to the previous song.
7 Play/pause button Press to start or pause playback.
8Forward button Press to go the the next song.
5
RF-BTHP02
Using your headset
Charging the battery
Your headset comes with a internal rechargeable battery.
To charge or recharge the battery:
1Turn off your headset.
2Connect your headset to a computer using the provided
USB charging cable or a power outlet using the provided
AC adapter. When the red LED changes to blue, charging
is complete. Average charging time is two hours.
9 USB port Connec the USB cable to this port
and a USB port on a computer to
recharge the battery.
10 Speakers Produce sound from the headset.
#Component Description
6
3When the battery is fully charged, unplug the USB cable
or AC adapter from your headset.
Note: The first time you charge the battery, leave your
headset connected to the USB cable or AC adapter at least
two hours.
Note: When the battery charge is low, the red LED flashes
and an alarm sounds.
Turning your headset on or off
To turn on your headset:
• Press and hold (talk) for about three seconds. The
blue LED starts blinking.
Note: If you press and hold (talk) for six seconds, your
headset goes into pairing mode. For more information see
“Pairing your headset” on page 6.
To turn off your headset:
• Press and hold (talk) for about three seconds.
Pairing your headset
To pair your headset:
1With your headset turned off, press and hold (talk)
for six seconds. The blue and red LEDs flash rapidly.
2On your device, select either RF-BTHP01 or RF-BTHP02
from the list of discovered Bluetooth devices.
3On your device, enter the password 0000 to pair your
headset.
7
RF-BTHP02
Pairing a phone to your headset
Connecting from the phone
Select RF-BTHP01 or RF-BTHP02 from the list of paired devices
on the phone.
Connecting from your headset
When you turn on your headset, it automatically connects to
the last device it was connected to.
Multi-pairing method
Before you can connect your headset to two devices, you
must pair to each device individually using the appropriate
profiles. For phone conversation, use the HSP or HFP profile.
For high quality audio, use the A2DP profile.
A profile can only connect one device at a time. For example,
you cannot use a phone’s MP3 player and a computer’s MP3
player at the same time, because both players are connected
through the A2DP profile.
You can connect the phone using the HSP profile and the
computer using A2DP. This way, you can listen to the music
from the computer and answer phone calls at the same time.
Notes:
In multi-pairing mode, some functions may be restricted
depending on the host devices.
Not all devices and functions may be compatible with
multi-pairing.
8
Using phone functions
Note: If you connect a phone and an MP3 player, the device
you connect last has priority. For example, if you connect a
phone, then connect an MP3 player, you can answer the
phone while listening to music, but you cannot use the
phone’s redial or voice recognition functions because the
MP3 player controls the buttons.
To use phone functions:
• To voice dial, press (talk) once to activate voice
dial. (Some phones may not support this function.)
• To redial the last number, double-click (quickly press
twice) (talk).
• To answer a call, press (talk).
• To end a call, press (talk).
• To refuse an incoming call, press (play/pause).
• To adjust the volume, press the + or – volume button.
• To switch a call between the headset and phone,
press (talk) twice. (Some phones may not
support this feature.)
• To answer a call while listening to music, press
(talk). To end the call press (talk) again.
When the call ends, music resumes playing.
9
RF-BTHP02
Listening to music
Note: If you connect a phone and an MP3 player, the device
you connect last has priority. For example, if you connect a
phone, then connect an MP3 player, you can answer the
phone while listening to music, but you cannot use the
phone’s redial or voice recognition functions because the
MP3 player controls the buttons.
Note: The Bluetooth device you connect must support AVRCP
(Audio Video Remote Control Profile).
To listen to music:
• To play a song on the phone’s MP3 player, press
(play/pause).
• To pause or resume playback, press (play/pause).
• To stop playback, press and hold (play/pause).
• To select a song during playback, press or .
• To fast forward or fast reverse during playback, press
and hold or . (Some phones may not support
this function.)
Adjusting the volume
To adjust the volume:
• Press the + or – volume button.
Using EQ sound
There are three types of EQ sound effects:
• Normal (EQ off)
•Bass
•Soft
The mode sequence is: Bass – Normal – Soft – Normal – Bass,
etc.
A “beep” sound indicates each mode change.
10
To select a sound mode:
• While in play/pause mode, quickly press twice
(play/pause).
Resetting your headset
To reset your headset:
• Press (play/pause), , and at the same time.
Note: The pairing information is retained. When you turn on
your headset, it automatically connected to the last
connected device.
LED status information
Headset status LED
Powering on Blue LED is on.
Powering off Red LED dims, then disappears.
Low battery Red LED continues to blink.
Recharging Red LED stays on.
Recharging complete Blue LED stays on.
Pairing mode Blue and red LED flash rapidly.
Connection complete Blue LED blinks every three seconds.
Receiving a call Blue LED flashes rapidly.
Talking on the phone Blue LED repeatedly brightens and dims.
Playing music Blue LED repeatedly brightens and dims.
