Rinnai ORH15S User manual

This appliance shall be installed in accordance with:

• Manufacturer’s Installation Instructions

• Current AS/NZS 3000 Electrical Installation (Wiring Rules)

• Local Regulations and Municipal Building Codes including local OH&S requirements

This appliance must be installed, maintained and removed by an Authorised Person.

For continued safety of this appliance it must be installed and maintained in

accordance with the manufacturers instructions.

Operation & Installation Manual

Outdoor Radiant Heater

Models: ORH15S / ORH18M / ORH24L / ORH32XL

Rinnai 2 ORH OIM

This page is intentionally blank

Rinnai 3 ORH OIM

TABLE OF CONTENTS

Warnings and Important Information 4

About Your Outdoor Radiant Heater 6

Radiant Heating Principles �� 6

Features �� 6

Specications �� 6

General Design Layout / Carton Contents �� 7

Operation �� 7

Installation 8

Regulatory Requirements �� 8

Unpacking �� 8

Approximate Heating Area �� 8

Outdoor Radiant Heater Mounting �� 8

Clearances �� 9

Installation Method �� 10

Electrical connections �� 11

Location of Electrical Connection �� 11

Multiple Installations �� 11

Care & Maintenance 12

Cleaning �� 12

Save A Service Call �� 12

When to Call for Service �� 12

Warranty 13

Contacts 16

Rinnai 4 ORH OIM

READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE.

Always comply with the following precautions to avoid dangerous situations and to ensure optimum

performance. When using an outdoor radiant heater, it is necessary to observe specic precautions.

Failure to carefully read and follow all instructions and precautions in this manual can result in equipment

malfunction, property damage, personal injury and/or death�

Use this appliance only as described in this manual� Any other use is not recommended by the

manufacturer and may cause re, electric shock or injury.

WARNINGS: WHEN IGNORED, CAN RESULT IN SERIOUS INJURY OR DEATH.

CAUTIONS: WHEN IGNORED, CAN RESULT IN MINOR INJURY OR PRODUCT DAMAGE.

WARNING

It is important that the following precautions are followed to minimise the risk of overheating, re, electric

shock and injury:

The appliance MUST BE installed at least 2.1m above the oor.

Handle the appliance with care, avoid vibrations and knocks� Unpack the appliance and check for damage�

DO NOT INSTALL A DAMAGED APPLIANCE� If the appliance is damaged or defective, contact your

supplier for advice, the appliance may ONLY be serviced by the manufacturer or the manufacturer’s

agent or similarly qualied person.

DO NOT install or use the appliance if the power cord is damaged� If it is damaged or requires replacing,

it must be replaced by the manufacturer or the manufacturer’s agent or similarly qualied person.

Ensure that the voltage and frequency of the power supply correspond to the ratings on the data plate

of the appliance�

Models ORH15S, ORH18M and ORH24L are tted with an Australian exible 1m cord and 3 pin plug. A

dedicated 240V 50Hz earthed 10 Amp power point must be used with this appliance�

Model ORH32XL are tted with an Australian exible 1m cord and 3 pin plug. A dedicated 240V 50Hz

earthed 15 Amp power point must be used with this appliance�

DO NOT use power boards or double adaptors for this appliance�

This appliance MUST NOT be located immediately below or directly in front of a power point / electrical

connection� The power point / electrical connection is to be within 1m of the appliance, yet should be

located outside the physical footprint of the unit to prevent exposure to heat build-up behind the appliance�

If the heater is to be mounted on an incline such as a vaulted ceiling, ensure the power point / electrical

connection is located at that lowest point of the appliance (see page 11 for details)�

The appliance may be direct wired ONLY by a licensed electrical trades person in accordance with local

regulations�

The appliance should be connected to an electric circuit equipped with an automatic circuit breaker�

DO NOT connect the appliance to the mains power until it has been installed in its nal location and

adjusted to the position it will be used in�

The installation MUST BE equipped with an all-pole disconnection mechanism in accordance with wiring

rules�

The electrical cord MUST NOT come into contact with the heated parts of the appliance� DO NOT unplug

the appliance by pulling on the exible cord.

DO NOT coil or bundle the electric cord to reduce its length as overheating of the cord may occur which

could result in a re hazard.

Use of an extension cord on this appliance is not recommended� The appliance is NOT intended to be

used as a portable heater�

IMPORTANT

WARNINGS AND IMPORTANT INFORMATION

Rinnai 5 ORH OIM

WARNING

This appliance MUST NOT be installed where curtains or other combustible materials could come into

contact or in close proximity with it� In some cases curtains may need restraining�

When installed outdoors this appliance is suitable for under cover use ONLY�

DO NOT place articles or on or against this appliance�

DO NOT place any items of clothing, hand towels or similar over the appliance to dry�

DO NOT spray aerosols in the vicinity of this appliance whilst the appliance is operating� Most aerosols

contain ammable gas, which can be a re hazard if used near the appliance when it is in use.

DO NOT use or store ammable materials, liquids, etc. near this appliance. Combustible materials must

not be placed where the appliance could ignite them�

DO NOT use the appliance in areas where the presence of ammable dust particulates may cause an

explosion�

Do not use the appliance, in a green house, barn or stable or on a on a building site or where ammable

dust may be present�

DO NOT use this appliance in the place of animal propagating areas�

DO NOT use the appliance as a sauna heater�

DO NOT leave the appliance unattended whilst in operation�

CAUTION when being operated the surfaces of this appliance will get VERY HOT - DO NOT TOUCH

ANY PART OF THE APPLIANCE WHILE IT IS TURNED ON� To avoid burns, DO NOT touch the any

surface of the appliance with any body part� The appliance must be located in a position that prevents

contact by any person (including accidental)�

The appliance will retain signicant heat for a period after shut down. To avoid burns, DO NOT touch the

any surface of the appliance with any body part during this period�

This appliance is not intended for use by persons (including children) with reduced physical, sensory or

mental capabilities or lack of experience and knowledge, unless they have been given supervision or

instruction concerning use of the appliance by a person responsible for their safety and have the capacity

to follow those instructions�

The appliance is not intended for use by young children or inrm persons without supervision.

Young Children must be supervised when in the vicinity of this appliance while it is in operation�

This appliance is NOT equipped with a device to control the room temperature� DO NOT use this

appliance in small rooms (see “Approximate Heating Area” on page 8) when they are occupied by

persons not capable of leaving the room on their own, unless constant supervision is provided�

DO NOT allow young children or the inrm to remain unsupervised or sleep directly in front of or below

the appliance while in operation�

NO USER SERVICEABLE PARTS - NEVER dismantle the appliance� Tampering with electrical

connections and components is highly dangerous and can result in equipment malfunction, property

damage, personal injury and/or death�

DO NOT modify this appliance. Modifying from original specications may create a dangerous situation

and will void your warranty�

WARNINGS AND IMPORTANT INFORMATION

Rinnai 6 ORH OIM

RADIANT HEATING PRINCIPLES

Radiant heat is widely regarded as the most

comfortable, healthiest and most natural form

of outdoor heating available. This heating type

is based on the same primary source of heat

we know - the warmth of the sun. It warms you

and the objects around you instead of the air.

The warmth felt from the sun is not warm air but

infra-red energy. Like the sun, radiant energy

from the heater moves in straight lines, directly

warming the people and objects in its path

which in turn acts as small heat convectors,

giving off their own gentle heat to enhance

people feeling warm.

This radiant heating principle is common to all 4

models, regardless of the wattage of the heater.

As the wattage and product length increases

the heating footprint will be greater.

FEATURES

This outdoor radiant heater uses electricity as the heating medium. It operates on the infrared radiant heating

principle directly warming people and objects in the area instead of the air within it.

Ease of Installation & Operation

Suitably sized 3 pin plugs are provided to allow for ease of installation to a wall socket. It is designed to be

plugged into a circuit that has an operating isolation switch within reach of the user which enables the heater to

be switched on or off.

Silent Operation

Electric element operation eliminates fan noise.

Draft Free

Non fan operation also means no drafts.

IP65

Water ingress protection allows for safe cleaning of the external heater casing using a typical low pressure

garden hose or by using a wet sponge.

SPECIFICATIONS

Model; ORH15S ORH18M ORH24L ORH32XL

Max. rated power 1500W 1800W 2400W 3200W

Rated voltage 240V 50Hz

Three pin plug type 10 Amp 15 Amp

Length of power lead (mm) 1000

IP Rating IP65

Heater Body

Dimensions

(mm)

Length 1030 1210 1490 1900

Width 160

Height 50

Unit Weight (kg) 4.8 5.4 6.5 8.2

Available installation options Ceiling and Wall mount

Recommended

mounting heights (mm)

From Min. / Max. * 2100 / 3000

Ideal. 2100 - 2700

Clearances Vertically from a surface Min. 1000

Other See "Clearances" on page 9 for requirements

* Heating effectiveness will be reduced if appliance is mounted at greater heights.

L H

ABOUT YOUR OUTDOOR RADIANT HEATER

Rinnai 7 ORH OIM

GENERAL DESIGN LAYOUT / CARTON CONTENTS

The packaging for this appliance should contain:

1. Outdoor Radiant Heater: a. Heater body b. Front radiating surface.

2. 1000mm Flexible power cord with three pin plug

3. Operation Indicator Light

4. Adjustable angle mounting bracket (x2)

5. Mounting bracket locking plates (x2)

6. Operating & Installation Instructions

OPERATION

1. Before operating the heater for the time or after periods of non use ensure that the radiating surface is

clean and free of debris or dust see "Cleaning" on page 12.

2. Ensure that the GPO for the heater is in the "ON" position, then switch "ON" the power at the isolating switch

(if

3. The orange operation indicator will light to indicate the heater is on and the heater will begin to radiate infrared

heat.

NOTE

The heater may take up to 15 minutes to reach maximum heat, depending on the area being

heated and the conditions.

4. Switch "OFF" the power at the isolating switch to turn off the heater. The operation indicator will go out.

NOTE

The heater may take up to 30 minutes to fully cool down, depending on the area being heated and

the conditions.

ABOUT YOUR OUTDOOR RADIANT HEATER

Rinnai 8 ORH OIM

REGULATORY REQUIREMENTS

• The heater must be installed in accordance with the manufacturers installation instructions�

• The heater MUST ONLY be installed or removed by an authorised person�

• The heater MUST be installed in accordance with AS/NZS 3000 and all other applicable local municipal

building codes including OH&S requirements

UNPACKING

IMPORTANT

If any damage is present DO NOT INSTALL or OPERATE the appliance and contact your supplier

for advice.

APPROXIMATE HEATING AREA

Heater

Indoor Area Spot Heating

Dimension ORH15S ORH18M ORH24L ORH32XL

A 1030 1210 1490 1900

B 1700 2050 2650 3550

C 2150 2150 2150 2150

Outdoor Covered / Enclosed Area

Dimension ORH15S ORH18M ORH24L ORH32XL

A 1030 1210 1490 1900

B 1400 1600 2050 2750

C 2150 2150 2150 2150

OUTDOOR RADIANT HEATER MOUNTING

This outdoor radiant heater comes with a pair of stainless steel adjustable angle mounting brackets� The adjustable

angle enables the heater to be installed on vertical, horizontal and inclined surfaces�

The ideal mounting position is directly above the area to be heated with a longitudinal orientation and facing

vertically downwards� If this is not possible, the heater(s) can be mounted on a wall and angled downwards� For

this application ensure the mounting height is within 2�1m to 2�7m�

WARNING

The heater must never be installed in the upwards or inwards facing position, the heating surface

must always be positioned to direct the heat in a downwards or outwards direction.

Vertical wall mount

Inclined ceiling mount

Horizontal ceiling mount

Angled horizontal ceiling mount

Correct Installation

Incorrect Installation

WALL

CEILINGCEILINGCEILINGCEILING

INSTALLATION

Rinnai 9 ORH OIM

CLEARANCES

Minimum clearances when mounting the heater on A VERTICAL WALL.

Minimum clearances when mounting the heater parallel with A CEILING.

Minimum clearances when mounting the heater at an ANGLE TO A CEILING.

1500 Min.

100 Min.

220 Min.

1000 Min. to surfaces (ie table tops, ect)

2100 Min. from floor

3000 Max. from floor (recommended)

Fans, lights and

sprinkler fittings

MUST NOT

be below heater

Same both ends

600 Min.

600 Min600 Min

175 Min

Fans, lights and

sprinkler fittings

MUST NOT

be below heater

Same both ends

600 Min.

1000 Min. to surfaces (ie table tops, ect)

2100 Min. from floor

3000 Max. from floor (recommended)

1500 Min.

600 Min.

Fans, lights and

sprinkler fittings

MUST NOT

be below heater

125 Min.

Same both ends

600 Min.

1000 Min. to surfaces (ie table tops, ect)

2100 Min. from floor

3000 Max. from floor (recommended)

INSTALLATION

Rinnai 10 ORH OIM

INSTALLATION METHOD

1. Open the packaging and carefully take the heater out and inspect for any damage.

2. Determine the mounting position for the heater, refer to "Approximate Heating Area" on page 8 "Outdoor

Radiant Heater Mounting" on page 8 and 9 to assist with the location of the heater.

3. Set the adjustable angle mounting brackets (2.) to desired angle:

For ceiling mounted installations the available mount angles are restricted to 0°, 15° and 30° only.

For wall mounted installations the available mount angles are restricted to 15°, 30° and 45° only.

4. Mark the position of the two brackets, using the following minimum recommended bracket spacing below to

determine the correct location.

Dimension (mm) ORH15S ORH18M ORH24L ORH32XL

A 530 ± 50 710 ± 50 990 ± 50 1400 ± 50

5. Install the brackets onto the nominated surface or structure using appropriate screws suitable for the

mounted surface material and able to support more than double the weight of the heater being installed, refer

to on page 6.

6. Hang the heater on the brackets and secure in place with the mounting bracket locking plates

0° 15° 45°30°

CeilingWall

INSTALLATION

by tighting bolts labelled A first, then B as indicated below.

This manual suits for next models

Table of contents

Other Rinnai Heater manuals

Rinnai

Rinnai RHFE-551FA User manual

Rinnai

Rinnai ES17 User manual

Rinnai

Rinnai DD180 Specification sheet

Rinnai

Rinnai 37AHA04508KA5 User manual

Rinnai

Rinnai RCE-460PTR User manual

Rinnai

Rinnai Energysaver RHFE-556FM User manual

Rinnai

Rinnai FC510N User manual

Rinnai

Rinnai REH-311FT(B) User manual

Rinnai

Rinnai FS35ETRBL/US Specification sheet

Rinnai

Rinnai RE650PMS(H) User manual

Rinnai

Rinnai Demand Duo User manual

Rinnai

Rinnai RHFE-309FT Specification sheet

Rinnai

Rinnai RCE-429A Quick start guide

Rinnai

Rinnai rhfe-431ft User manual

Rinnai

Rinnai Granada 252 User manual

Rinnai

Rinnai RHFE-557FT User manual

Rinnai

Rinnai RHFE-951ETR User manual

Rinnai

Rinnai Avenger 25 User manual

Rinnai

Rinnai Energysaver RHFE-559T User manual

Rinnai

Rinnai ASPIRATION RHFE-750ETR User manual

Rinnai

Rinnai Arriva 750 User manual

Rinnai

Rinnai RHFE-556 FM User manual

Rinnai

Rinnai FC824 User manual

Rinnai

Rinnai RHFE-556FTD Operating instructions

Popular Heater manuals by other brands

oventrop

oventrop Regucor Series quick start guide

Blaze King

Blaze King CLARITY CL2118.IPI.1 Operation & installation manual

ELMEKO

ELMEKO ML 150 Installation and operating manual

BN Thermic

BN Thermic 830T instructions

KING

KING K Series Installation, operation & maintenance instructions

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Installation instructions and owner's manual

Well Straler

Well Straler RC-16B user guide

EUROM

EUROM 333299 instruction manual

Heylo

Heylo K 170 operating instructions

Eterna

Eterna TR70W installation instructions

Clarke

Clarke GRH15 Operation & maintenance instructions

IRSAP

IRSAP The Radiator Company Ovali Fitting instructions

Empire Heating Systems

Empire Heating Systems WCC65 Installation and owner's instructions

Wetekom

Wetekom 92 86 43 Original instructions

Desa

Desa SPC170-F owner's manual

Watlow

Watlow Watrod Electric Tubular Heaters Specifications

Haverland

Haverland ECO-DRY GPS Series Instruction & installation manual

Stelpro

Stelpro ASILVC2060 Series user guide
