Rheem PRO415TM User manual

PROFESSIONAL

Available in 40 and 60 Gallon Electric Models



Upgradeable 6 Year Limited Tank Warranty to 8 Years*



2 Year Limited Parts Warranty*

•Unique professional design

•EverKleen™self cleaning dip tube

•Oversized magnesium anode rod

•R-Foam insulation (up to R-20)

•Temperature and pressure relief valve

included

•Factory installed plumbing nipples

•Professional installation

•Certified to the CAN/CSA C191.1-M90

efficiency standard

* See Residential Warranty Information Brochure for

complete warranty information.

Get

2 MORE YEARS

with ProtectionPlus™

DESCRIPTION FEATURES ROUGHING IN DIMENSIONS

STORAGE CAPACITY OVERALL HEIGHT TO ESTIMATED

STANDARD ELEMENTS HEIGHT DIAMETER DRAIN VALVE SHIPPING

U.S. IMP. ELEMENTS 208 VOLT 240 VOLT A B C WEIGHT

MODEL NUMBER GALS. GALS. LITERS QTY. WATT. AMP. WATT. AMP. IN. MM IN. MM IN. MM LBS. KG

PRO415TM 45 37.5 170 2 2250 10.8 3000 12.5 46 1168 21-3/4 552 3-1/2 89 117 53

PRO425TM 45 37.5 170 2 2250 10.8 3000 12.5 46 1168 24-1/4 616 3-1/2 89 134 61

PRO615TM 72 60 270 2 3380 16.3 4500 18.8 59 1499 23 584 3-1/2 89 177 80

PRO620TM 72 60 270 2 3380 16.3 4500 18.8 59 1499 24-1/2 622 3-1/2 89 188 85

In keeping with its policy of continuous progress and product improvement, Rheem reserves the right to make changes without notice.

The Exclusive Professional Installation Warranty

When this Rheem PROFESSIONAL water heater is installed by a

licensed contractor, the consumer can upgrade the limited tank

warranty from 6 to 8 years and the limited parts warranty from

1 to 2 years by returning to Rheem the warranty registration card

and a copy of the contractor’s invoice.

This Rheem exclusive warranty upgrade feature enhances your

value as a plumbing professional. A professional installation is a

better installation!

Refer to the warranty certificate enclosed with each heater for

specific details.

YEAR LIMITED

TANK WARRANTY

BECOMES

Notes: 3/4" N.P.T. Outlet, Inlet, Anode Rod, T&P Valve Connections. • 140°F Thermostat Setting. • Not available in 3 phase wiring.

Designed Exclusively For The Plumbing

Professional, With a Warranty to Match!

Before purchasing this appliance, read important energy cost and

efficiency information available from your supplier.

Rheem Manufacturing Company • Water Heater Division

Rheem Canada Ltd./Ltée,128 Barton Street West, Hamilton, Ontario L8N 3P3

03/06 WP FORM NO. 101-45CAN Rev. 7

Rheem Manufacturing Company • Water Heater Division

Rheem Canada Ltd./Ltée,128 Barton Street West, Hamilton, Ontario L8N 3P3

03/06 WP FORM NO. 101-45CAN Rev. 7

PROFESSIONAL

Designed Exclusively For The Plumbing

Professional, With a Warranty to Match!

CONSTRUCTION FEATURES

1. R-Foam Insulation – Rigid polyurethane foam for

improved economy and fuel savings. The use of

our patented insulator foam stops allows R-Foam

to be injected directly between the tank and outer

jacket. This uniform R-Foam application minimizes

the possibility of costly heat loss caused by

uninsulated areas (voids) common to some

other foam processes.

2. Rheemglas Tank – Rheem water heater tanks

are made of special materials with exacting care.

The tank surface is coated with an exclusive

porcelain formula called Rheemglas and fused to

the solid steel at 1600°F. The result is a smooth,

tough, glass-like lining that effectively resists the

corrosive attacks of hot water chemicals, thereby

assuring long water heater life. Tank is designed

and tested to withstand 300 PSI hydrostatic test

pressure, for working pressure of 150 PSI.

3. Elements – High quality copper.

4. Dip Tube – EverKleen™self-cleaning dip tube

reduces sediment buildup by channeling water

through a specially developed inlet tube.

5. Anode Rod – Premium grade, heavy duty anode

provides increased cathodic protection for longer

tank life. Effective in varying water conditions.

6. Electrical Junction Connection – (For 1/2" and

3/4" conduit) Front location for easy installation.

7. Over Temperature Protector – Automatically

cuts off power in excess temperature situations.

8. Automatic Temperature Control – Thermostat

keeps water at desired temperature.

9. Hot Water Outlet – Draws water from top of

storage tank where temperature is highest.

10. 3/4" Relief Valve Coupling.
