Rexel Auto+ 300X Instruction Manual

start here

démarrez ici

starten sie hier

iniziare qui

begin hier

empieza aquí

comece aqui

buradan başlayın

ξεκινήστε εδώ

start her

aloita tästä

start her

börja här

rozpocznij tutaj

začněte zde

kezdés itt

начинать здесь

SHREDDERS

AUTO+300X&300M™

2min

GB instruction manual 6

F manuel d’utilisation 14

D bedienungsanleitung 22

I manuale d’istruzioni 30

NL gebruiksaanwijzing 38

E manual de instrucciones 46

P manual de instruções 54

TR kullanım kılavuzu 62

GR οδηγίες 70

DK brugsvejledning 78

FI käyttöopas 86

NO bruksanvisning 94

S bruksanvisning 102

PL instrukcja obsługi 110

CZ návod k obsluze 118

H használati útmutató 126

RUS руководствo по зкcплyатации 134

SHREDDERS

AUTO+300X&300M™

6register this product online at www.accobrands.com

To guard against injury, the following basic safety precautions must be observed in the set-up of this

product.

• Ensure the machine is plugged into an easily accessible power outlet, and ensure the cable is not

likely to trip up a passer by.

• Any attempt to repair this unit by unqualied personnel will invalidate the warranty. Please return to

supplier.

• Unplug your shredder before moving it or when it is not in use for an extended period of time.

• Do NOT operate with a damaged power supply cord or plug, after it malfunctions, or after it has

been damaged in any manner.

• Do NOT overload electrical outlets beyond capacity as this can result in re or electrical shock.

• The socket-outlet should be installed near the equipment and shall be easily accessible.

• Do NOT alter the attachment plug. The plug is congured for the appropriate electrical supply.

• Do NOT use near water.

• Do NOT use aerosol dusters or cleaners.

• Do NOT spray anything into the shredder.

• Do NOT load the auto-feed chamber with unopened junk mail, magazines, bound documents etc.

Although this shredder has been designed to comply with UL 60950-1 EN 60950-1 safety standards

including the “probe accessibility tests”, do not operate the shredder near children or pets.

autofeed technology

The Auto+ 300X and 300M has been designed to automatically shred up to 300 sheets from the

auto-feed chamber and up to 8 sheets through the manual feed slot. The auto-feed mechanism has

been designed to handle paper fastened with staples and paper clips and to only pull a few sheets

of paper into the cutting mechanism to minimise the risk of paper jams.

AUTO+ 300X&300M™SHREDDERS 7

warning symbols

Sheet capacity of manual feed

entry slot.

This means no aerosols.

This means keep children away

from shredder.

This means you should be careful

because long hair can become

entangled in the cutting head.

This means don’t reach into the

feed opening of the cutting head.

This means be careful of loose

jewellery which could become

entangeld in the cutting head.

This means no oil lubrication,

use Rexel oil sheets only.

This means be careful of ties and

other loose clothing which could

become entangled in the cutting

head.

This means the shredder can

accept small paperclips.

This means the shredder can

accept small staples.

Safety First

control panel and indicators

Lock indicator – This means the

paper loading door is locked (during

shredding).

Power On indicator – This means

the machine is turned on.

Paper jam indicator – This means

there is a paper jam in the auto feed

chamber.

If this symbol is ashing the

shredder is attempting to clear a

paper jam automatically.

If this symbol is permanently

illuminated red please follow the

instructions under ‘Rare Occasion

of Jamming’.

Continuous Jam Boost

Auto

Reverse

Loading Door Locking

Mechanism – PIN Password

Buttons – Enter a four digit code

to lock the loading door during

shredding.

Cool Down indicator – This means

the machine is cooling down.

Jam Free indicator – This alerts

the user when too much paper is

fed into the manual feed slot (see

section on Jam Free Technology).

Paper Loading Door/Bin Door

Open or Bin Full indicator –

This means either:

• Loading door is open

• Bin is open

• Bin is full

8register this product online at www.accobrands.com

Auto+ 300X/300M shredding capability

Auto+ 300X/300M CAN shred the following:

• 300 sheets

• Stapled paper, 25mm within the corner

• 26/6 and 24/6 or smaller staples

• Small sized paper loaded centrally

• 300 sheets

• Paper clip paper, 25mm within the corner (300M through manual feed slot ONLY)

• Capable of shredding small/medium paper clips (max. wire thickness = 0.9 mm)

• >80/100gsm paper (through manual feed slot ONLY)

• A3 folded in half max. 2 sheets

• 300 sheets

• 80 gsm paper

- A4 - 210mm x 297mm

- A5 - 148mm x 210mm

- A3 single sheet folded in half to make A4

Auto+ 300X/300M CAN shred (through the manual feed slot):

Thick paper or

card.

Multiple folded

sheets (e.g. A3

sheets folded in

half).

Unopened mail

(e.g. junk mail).

Glossy paper or

a sheet covered

with print on both

sides.

Auto+ 300X/300M CANNOT shred the following:

Large clips.

Check the length

of the paperclip

is not longer than

32mm.

Heavy duty

staples. Check

the staple leg

length is not

greater than

6mm.

Bound

documents

Bulldog clips

Magazines or

other documents

bound by multiple

staples or clips.

Adhesive labels.

Plastic sheets,

laminated

documents,

plastic folders.

AUTO+ 300X&300M™SHREDDERS 9

bin or loading door open safety function

As a safety precaution, if the bin or loading door is opened during shredding, the shredder will stop

and the bin full indicator will illuminate ( ).

jam free technology in manual feed slot

Sensors in the paper feed area measure the thickness of paper about to be shredded. The ability to

shred or not is communicated through red and green lighting. Green means that the stack of paper

is within the shredders sheet capacity and OK to shred. Red means that you have too much paper,

remove some sheets in order to shred.

Given that you are unable to shred more sheets of paper than the shredder is capable of

shredding, paper jams are prevented.

This prevents time wasted through reversing paper and unblocking jams not to mention the mess it

can create.

intelligent help

1 In the unlikely event of the shredder jamming, the Auto+ 300X and 300M will stop shredding,

and the jam icon will blink in orange.

2 The shredder will illuminate the FWD ( ) and REV ( ) buttons in the sequence necessary

to clear the jam.

3 If the jam cannot be intelligentally cleared, the jam icon ( ) will illuminate in red. At this point

open the auto feed chamber to clear any jammed material.

automatic jam clearance

Intelligent Jam Clearance: In the unlikely event of the shredder jamming, the Auto+ 300X and 300M

will automatically reverse and forward the engine three times to clear a jam. During this operation

the Paper Jam indicator will ash ( ).

10 register this product online at www.accobrands.com

1. operation

1 Unpack the product.

2 Connect the shredder to mains supply.

3 Ensure the ON/OFF button on the back of the machine is in the ON position, which will

illuminate the blue standby symbol ( ).

4 To commence shredding, press the Auto button ( ), which sets the shredder into auto mode.

You are now ready to shred.

5 To load the shredder, simply lift the loading door handle to open the loading door and insert

documents. You can open the door further to 90 degrees for easier access if required Load up

to 300 sheets at a time into the feed chamber. Do not ll above the 300 MAX level, this could

damage the shredder.

6 The shredder will start the shredding cycle automatically ONLY after closing the loading door.

If there is still paper in the Autofeed chamber after rst attempt, open and re-close the paper

loading door a second time.

Attention: If required you can now lock the loading door by entering a 4 digit code (see Locking

the Paper Loading Door section).

7 If you only have up to 8 sheets to shred, you can use the manual feed slot, provided the auto

feed chamber is empty.

8 Insert paper to be shredded into the feed area. The shredder will detect the paper and start

automatically.

9 If the shredder is left in auto mode for more than 2 minutes without being used, the shredder will

automatically turn back to sleep mode in order to save power.

10 The shredder will automatically ‘wake up’ from sleep mode when paper is inserted into the

shred mouth or you open the loading door. There is no need to press the Auto button ( ).

2. reverse function

1 Should you wish to reverse paper out whilst shredding, a reverse button ( ) has been tted for

your convenience.

2 Reverse the paper out then turn the machine o using the ON/OFF switch at the rear of the

shredder. Remove the paper from the manual feed slot (if being used) or open the loading door,

remove the remaining stack of paper, then pull the jammed paper free of the cutting mechanism.

3 To resume shredding, turn the shredder on using the ON/OFF switch at the rear of the shredder.

Return the switch to the auto position ( ).
