Regency B36XT Bellavista Quick start guide

WARNING:

Iftheinformationintheseinstructionsarenotfollowedexactly,

a ﬁre or explosion may result causing property damage,

personal injury or loss of life.

FOR YOUR SAFETY

Do not store or use gasoline or other ﬂammable vapors and

liquids in the vicinity of this or any other appliance.

Installation and service must be performed by a qualiﬁed

installer, service agency or the gas supplier.

FOR YOUR SAFETY

What to do if you smell gas:

Do not try to light any appliance

Do not touch any electrical switch:

do not use any phone in your

building.

Immediately call your gas supplier

from a neighbour's phone. Follow

the gas supplier's instructions.

If you cannot reach your gas

supplier, call the ﬁre department.

FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4

918-769c

Regency Bellavista™B36XT

Gas Fireplace

05/05/14

Owners &

Installation Manual

www.regency-ﬁre.com

Tested by: Installer: Please complete the details on the back cover

and leave this manual with the homeowner.

Homeowner: Please keep these instructions for future reference.

MODEL: B36XT

Medium DV Gas Fireplace

Bellavista B36XT Video

2Regency Bellavista™ B36XT Gas Fireplace

To the New Owner:

Congratulations!

You are the owner of a state-of-the-art Gas Fireplace by REGENCY®. The Bellavista™ B36XT has been designed to

provide you with all the warmth and charm of a wood ﬁreplace at the ﬂick of a switch. The Bellavista™ B36XT has

been approved by Warnock Hersey/Intertek for both safety and efﬁciency. As it also bears our own mark, it promises

to provide you with economy, comfort and security for many trouble free years to follow. Please take a moment now

to acquaint yourself with these instructions and the many features of your Regency®Fireplace.

Bellavista B36XT

Gas Fireplace Beneﬁts

Regency Bellavista™ B36XT Gas Fireplace 3

MANUFACTURED MOBILE HOME REQUIREMENTS

INFORMATION FOR MOBILE/MANUFACTURED HOMES AFTER FIRST SALE

This Regency®product has been tested and listed by Warnock Hersey as a Direct Vent Wall Furnace to the following standards:

VENTED GAS FIREPLACE HEATERSANSI Z21.88a-2007 / CSA2.33a-2007 and GAS-FIREDAPPLIANCES FOR USEAT HIGH

ALTITUDES CAN / CGA 2.17-M91.

This Direct Vent System Appliance must be installed in accordance with the manufacturer's installation instructions and the

Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280, or the current Standard of Fire Safety Criteria for

Manufactured Home Installations, Sites, and CommunitiesANSI/NFPA501A, and with CAN/CSAZ240-MH Mobile Home Standard

in Canada.

This appliance installation must comply with the manufacturer's installation instructions and local codes, if any. In the absence of

local codes follow the current National Fuel Gas Code,ANSI Z223.1 and the current National Electrical Code ANSI/NFPA70 in the

U.S.A., and the current CAN/CGA B149 Gas Installation Code and the current Canadian Electrical Code CSA C22.1 in Canada.

This appliance comes equipped with a dedicated #8 Ground Lug for attachment of the ground wire to the steel chassis as applicable

to local codes.

The appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, with

the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, CSA C22.1.

This appliance may only be installed in an aftermarket permanently located, manufactured (U.S.Aonly) or mobile home, where not

prohibited by local codes.

This appliance can only be used with the type of gas indicated on the rating plate. This appliance is not convertible for use with

other gases.

Ensure that structural members are not cut or weakened during installation.

4Regency Bellavista™ B36XT Gas Fireplace

TABLE OF CONTENTS

SAFETY LABEL

Copy of Safety Decal.....................................................5

REQUIREMENTS

MA Code - CO Detector.................................................6

DIMENSIONS

Unit Dimensions ............................................................7

INSTALLATION

Important Message ......................................................8

Before You Start ............................................................8

General Safety Information............................................8

Installation Checklist.....................................................9

Locating Your Gas Fireplace.........................................9

Clearances ..................................................................10

Mantel Clearances.......................................................11

Mantel Leg Clearances................................................12

Non- Combustible Requirements: ...............................12

Framing ......................................................................13

Finishing......................................................................14

Unit Assembly Prior to Installation...............................15

Venting Introduction.....................................................17

Vent Restrictor, Bafﬂe & Heat Deﬂector Installation ....18

Exterior Vent Termination Requirements.....................19

Venting Arrangements horizontal terminations.....24

Flex Vent or RIGID PIPE 5" x 8"..........................24

Horizontal Terminations...............................................25

Flex Vent 5" x 8" .................................................25

RIGID PIPE 5" x 8"..............................................26

AstroCap XL & Rigid rear vent kit corner installations.27

Rigid pipe 5" x 8" .................................................27

Venting arrangements Horizontal Terminations...28

RIGID PIPE 4" x 6-5/8"........................................28

Horizontal or vertical terminationS.......................29

Rigid pipe 4" x 6-5/8"...........................................29

Horizontal terminations................................................30

Two (2) 90oElbows (Rigid Pipe 4" x 6 - 5/8") ..............30

Horizontal terminations................................................30

Three (3) 90oElbows (Rigid Pipe 4" x 6 - 5/8")............30

venting arrangements For Vertical TerminationS.31

RIGID PIPE 4" x 6-5/8"........................................31

Vertical terminations ...................................................32

Three (3) 90oElbows (Rigid Pipe 4" x 6 - 5/8")............32

venting arrangements..........................................33

With Co-linear Flex System.................................33

Vertical Terminations ...........................................34

Co-linear Flex System Into Masonry Fireplaces .34

Unit Installation with Horizontal Termination ...............35

4" x 6-5/8" or 5" x 8" venting.......................................35

Unit Installation with Horizontal Termination ...............36

5" x 8" venting unit installation w/ Vertical Termination37

4" x 6-5/8" venting .......................................................37

Gas Line Installation....................................................37

Pilot Adjustment...........................................................38

High Elevation .............................................................38

Gas Pipe Pressure Testing..........................................38

S.I.T. Valve Description................................................38

Conversion from NG to LP ..........................................39

DC Sparker battery replacement.................................41

Brick panel installation.................................................42

Optional stainless steel / black enamel .......................43

Log set installation.......................................................45

Optional Wall Thermostat ...........................................48

Optional Remote Control.............................................48

Optional Wall Switch....................................................48

Optional Fan installation..............................................49

Aeration Adjustment ....................................................50

Wiring Diagram............................................................50

Wiring diagram for GTMF remote...............................51

Optional accent light Installation..................................53

Flush glass door Installation........................................56

Optional ﬁnishing trim Installation................................57

Flush Louvers and Flush Panel installation.................57

Full Screen Arch Door and Frame Installation.............58

OPERATING INSTRUCTIONS

Operating Instructions .................................................59

First Fire ......................................................................59

Lighting Procedure ......................................................59

Shutdown Procedure...................................................59

Normal Operating Sounds of Gas Appliances.............59

Copy of Lighting Plate Instructions..............................60

MAINTENANCE

Maintenance Instructions.............................................61

Log Replacement ........................................................61

Thermopile / Thermocouple.........................................61

Bulb Replacement.......................................................61

Removing Valve...........................................................62

Installing Valve.............................................................62

PARTS LIST

Main Assembly ............................................................63

Burner Assembly .........................................................65

WARRANTY

The Warranty: Limited Lifetime ...................................67

Regency Bellavista™ B36XT Gas Fireplace 5

SAFETY LABEL

Thisisacopyofthelabelthataccompanieseach

Bellavista™B36XTDirectVentGasFireplace.

We have printed a copy of the contents here

for your review.

NOTE: Regency®units are constantly being

improved. Check the label on the unit and if

there is a difference, the label on the unit is

the correct one. COPY OF SAFETY DECAL

FortheState of Massachusetts, installation

and repair must be done by a plumber or

gas ﬁtter licensed in the Commonwealth of

Massachusetts.

For the State of Massachusetts, ﬂexible

connectors shall not exceed 36 inches in

length.

For the State of Massachusetts, the appli-

ances individual manual shut-off must be a

t-handle type valve.

The State of Massachusetts requires the

installation of a carbon monoxide alarm in

accordancewithNFPA720andaCOalarm

withbatterybackupinthesameroomwhere

the gas appliance is installed.

-DO NOT REMOVE THIS LABEL / NE PAS ENLEVER CETTE ÉTIQUETTE

353

DOOR SEAL: Please

check that the door is

properly sealed

FPI Fireplace Products International Ltd. Delta, BC, Canada

Minimum Clearances to Combustibles /

Degagement Minimum De Materiaux Combustibles

Serial No./ No de serie

918-763c

MAY BE INSTALLED IN MANUFACTURED (MOBILE) HOMES AFTER FIRST SALE.

Listed:

Certified for/Certifi e pour:

Tested to:

VENTED GAS FIREPLACE HEATER /

CANADA and U.S.A.

FOYER AU GAZ À ÉVACUATION

CAN/CGA-2.17-M91(R2009)

ANSI Z21.88-2009/CSA 2.33-2009

Electrical supply/Électrique 115VAC, 1.13 A, 60Hz.

NOT FOR USE WITH SOLID FUELS. /

NE PAS UTILISER AVEC DU COMBUSTIBLE SOLIDE.

Made in Canada/ Fabrique au Canada

Duplicate S/N

0" Clearance to

combustibles from:

Mantel Clearances from

Fireplace Opening:

Side Wall Clearance

from Fireplace Opening

Ceiling from Top of

Fireplace Opening:

Mantel Depth:

Alcove Clearances:

Minimum Vent Clearances:

Top, sides, bottom and rear of unit

(A) Min. 13" (330mm)

B) Min. 12” (305mm)

C) 36-3/4” (933mm)

D) Max. 12” (304mm)

F) Max. Depth 36" (914mm)

Vertical Vent 1-1/2" (38mm)

(on one side)

E) Min. Width 84" (2134mm),

Horizontal Top 2" (51mm)

Horizontal Side 1-1/2" (38mm)

Horizontal Bottom 1-1/2" (38mm)

(See Instruction Manual for

detailed instructions)

ÉÉ

QUIP A L'UISINE POUR GAZ PROPANE

CONCU POUR ETRE POELE: Mod le B36XT-LP

PROPANE GAS: Model B36XT-LP

Minimum supply pressure

Manifold pressure high

Manifold pressure low

Orifice size

Minimum input

Maximum input

Altitude

NATURAL GAS: Model B36XT-NG

APPAREIL FONCTIONNANT AU NATURAL GAS

CONCU POUR ETRE POELE: Mod le B36XT-NG

Pression d'allimentation minimum

Pression à la tubulure d' chappement lev e

Pression à la tubulure d' chappement basse

Grandeur de l'injecteur

D bit minimum selon

D bit maximum selon

l'altitude

Calorifique

ééé

5.0" (1.25 kPa)

3.5" (0.87 kPa)

1.6" (0.40 kPa)

#35 DMS

0-4500 ft/pi (0-1372 m)

WC/C.E.

21,500 Btu/h (6.3 kW)

31,000 Btu/h (9.09 kW)

Pression d'allimentation minimum

Pression à la tubulure d' chappement lev e

Pression à la tubulure d' chappement basse

Grandeur de l'injecteur

D bit minimum selon

D bit maximum selon

l'altitude

Calorifique

ééé

11" (2.74 kPa)

10" (2..49 kPa)

6.4" (1.60 kPa)

#51 DMS

0-4500 ft/pi (0-1372 m)

WC/C.E.

25,000 Btu/h (7.33 kW)

31,000 Btu/h (9.09 kW)

Minimum supply pressure

Manifold pressure high

Manifold pressure low

Orifice size

Minimum input

Maximum input

Altitude

This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSI Z223.1, or Natural Gas and Propane Installation Code, CSA B149.1.

This appliance must be installed in accordance with the Standard CAN/CSAZ240 MH, Mobile Housing, in Canada, or with the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280, in

the United States, or when such a standard is not applicable,ANSI/NCSBCS A225.1/NFPA501A, Manufactured Home Installations Standard or ANSIA119.2 ou NFPA501C Standard for Recreational Vehicles

This appliance is only for use with the type of gas indicated on the rating plate and may be installed in an aftermarket, permanently located, manufactured (mobile) home where not prohibited by local codes. See

owner's manual for details. This appliance is not convertible for use with other gases, unless a certified kit is used. (Kit #576-969).

Fan Part # 576-917.

Installer l'appareil selon les codes ou règlements locaux, ou, en l'absence de tels règlements, selon les codes d'installationANSI Z223.1, National Fuel Gas Code ou CSA-B149.1 en vigueur.

Installer l'appareil selon la norme CAN/CSA-Z240, Série MM, Maison mobiles ou CAN/CSA-Z240 VC, Véhicules de camping, ou la norme 24 CFR Part 3280, Manufactured Home Construction and Safety

Standard. Si ces normes ne sont pas pertinentes, utilisez la norme ANSI/NCSBCS A225.1/NFPA 501A, Manufactured Home Installations Standard, ouANSI A119.2 ou NFPA 501C Standard for Recreational

Vehicles.

This vented gas fireplace heater is not for use with air filters. Ne pas utiliser de filtre à air avec ce foyer au gaz à évacuation.

FOR USE WITH GLASS DOORS CERTIFIED WITH THE APPLIANCE ONLY

Cet appareil doit être utilize uniquement avec le type de gaz indiqué sur la plaque signalétique. Cet appareil peut être installé dans une maison préfabriquée ou mobile (É.-U. seulement) installée à demeure si

les règlements locaux le permettent. Voir la notice de l'utilisateur pour plus de renseignements. Cet appareil ne peut pas être utilisé avec d'autres gaz sauf si une trousse de conversion certifiée est fournie.

POUR UTILISATION UNIQUEMENT AVEC LES PORTES EN VERRE CERTIFIÉES AVEC L'APPAREIL

4001172

6Regency Bellavista™ B36XT Gas Fireplace

REQUIREMENTS

5.08: Modifications to NFPA-54, Chapter 10

(2) Revise 10.8.3 by adding the following additional requirements:

(a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for

residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than

seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall

be satisfied:

1. INSTALLATION OF CARBON MONOXIDE DETECTORS. At the time of installation of the side wall horizontal vented gas fueled

equipment, the installing plumber or gasfitter shall observe that a hard wired carbon monoxide detector with an alarm and battery back-up is

installed on the floor level where the gas equipment is to be installed. In addition, the installing plumber or gasfitter shall observe that a battery

operated or hard wired carbon monoxide detector with an alarm is installed on each additional level of the dwelling, building or structure

served by the side wall horizontal vented gas fueled equipment. It shall be the responsibility of the property owner to secure the services of

qualified licensed professionals for the installation of hard wired carbon monoxide detectors

a. In the event that the side wall horizontally vented gas fueled equipment is installed in a crawl space or an attic, the hard wired carbon

monoxide detector with alarm and battery back-up may be installed on the next adjacent floor level.

b. In the event that the requirements of this subdivision can not be met at the time of completion of installation, the owner shall have a period of

thirty (30) days to comply with the above requirements; provided, however, that during said thirty (30) day period, a battery operated carbon

monoxide detector with an alarm shall be installed.

2. APPROVED CARBON MONOXIDE DETECTORS. Each carbon monoxide detector as required in accordance with the above provisions

shall comply with NFPA 720 and be ANSI/UL 2034 listed and IAS certified.

3. SIGNAGE. A metal or plastic identification plate shall be permanently mounted to the exterior of the building at a minimum height of eight

(8) feet above grade directly in line with the exhaust vent terminal for the horizontally vented gas fueled heating appliance or equipment. The

sign shall read, in print size no less than one-half (1/2) inch in size, "GAS VENT DIRECTLY BELOW. KEEP CLEAR OF ALL

OBSTRUCTIONS".

4. INSPECTION. The state or local gas inspector of the side wall horizontally vented gas fueled equipment shall not approve the installation

unless, upon inspection, the inspector observes carbon monoxide detectors and signage installed in accordance with the provisions of 248 CMR

5.08(2)(a)1 through 4.

(b) EXEMPTIONS: The following equipment is exempt from 248 CMR 5.08(2)(a)1 through 4:

1. The equipment listed in Chapter 10 entitled "Equipment Not Required To Be Vented" in the most current edition of NFPA 54 as adopted by

the Board; and

2. Product Approved side wall horizontally vented gas fueled equipment installed in a room or structure separate from the dwelling, building or

structure used in whole or in part for residential purposes.

Approved side wall horizontally vented gas equipment provides a venting system design or venting system components with the equipment, the

instructions provided by the manufacturer for installation of the equipment and the venting system shall include:

1. Detailed instructions for the installation of the venting system design or the venting system components; and

2. A complete parts list for the venting system design or venting system.

(d) MANUFACTURER REQUIREMENTS - GAS EQUIPMENT VENTING SYSTEM NOT PROVIDED. When the manufacturer of a

Product Approved side wall horizontally vented gas fueled equipment does not provide the parts for venting the flue gases, but identifies

"special venting systems", the following requirements shall be satisfied by the manufacturer:

1. The referenced "special venting system" instructions shall be included with the appliance or equipment installation instructions; and

2. The "special venting systems" shall be Product Approved by the Board, and the instructions for that system shall include a parts list and

detailed installation instructions.

(e) A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipment, all venting instructions,

all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of

the installation.

MA Code - CO Detector

(for the State of Massachusetts only)

Regency Bellavista™ B36XT Gas Fireplace 7

DIMENSIONS

UNIT DIMENSIONS

40-5/16” (1024mm)

21”(533mm)

33” (838mm)

36” (914mm)

35-1/4”

(895mm)

30-3/8” (762mm)

1”(25.4mm)

41-5/16”

(1049mm)

35-1/4”

(895mm)

26-1/2” (673mm)

20-1/4” (514mm)

17-5/16” (440mm)

20-5/16” (516mm)

33-1/16”

(840mm)

11-7/16”

(291mm)

38-1/16” (967mm)

39-1/2” (1003mm)

35-1/2” (902mm)

Full Screen Doors

8Regency Bellavista™ B36XT Gas Fireplace

INSTALLATION

9) Wear gloves and safety glasses for protection

while doing required maintenance.

10) Be aware of electrical wiring locations in walls

andceilingswhencuttingholesfortermination.

11) Under no circumstances should this appliance

be modiﬁed. Parts that have to be removed for

servicing should be replaced prior to operating

this appliance.

12) Installation and any repairs to this appliance

should be done by a qualiﬁed service person.

Aprofessionalservice person should be called

to inspect this appliance annually. Make it a

practice to have all of your gas appliances

checked annually.

13) Do not slam shut or strike the glass door.

14) Undernocircumstancesshouldanysolidfuels

(wood,paper,cardboard, coal, etc.) beused in

this appliance.

15) The appliance area must be kept clear and

freeofcombustiblematerials,(gasesandother

ﬂammable vapours and liquids).

Emissions from burning wood or gas could

contain chemicals known to the State of

California to cause cancer, birth defects or

other reproductive harm.

IMPORTANT MESSAGE

SAVE THESE

INSTRUCTIONS

The B36XT Gas Fireplace must be installed in

accordance with these instructions. Carefully

read all the instructions in this manual ﬁrst.

Consult the "authority having jurisdiction" to

determinethe need for apermit prior to starting

the installation. It is the responsibility of the

installer to ensure this ﬁreplace is installed in

compliancewithmanufacturersinstructionsand

all applicable codes.

BEFORE YOU START

Safeinstallationandoperationofthisappliance

requires common sense, however, we are

required by the Canadian Safety Standards

and ANSI Standards to make you aware of

the following:

GENERAL SAFETY

INFORMATION

1) The appliance installation must conform with

local codes or, in the absence of local codes,

with the current Canadian or National Gas

Codes,CAN1-B149orANSIZ223.1Installation

Codes.

2) The appliance when installed, must be

electrically grounded in accordance with local

codes,orintheabsenceoflocalcodeswiththe

current National Electrical Code, ANSI/NFPA

70 or CSA C22.1 Canadian Electrical Code.

3) See general construction and assembly

instructions. The appliance and vent should

be enclosed.

4) This appliance must be connected to the

speciﬁed vent and termination cap to the

outsideofthebuildingenvelope.Neverventto

another room or inside a building. Make sure

thattheventisﬁttedasperVentinginstructions.

5) Inspect the venting system annually for

blockage and any signs of deterioration.

6) Venting terminals shall not be recessed into a

wall or siding.

7) Any safety glass removed for servicing must

be replaced prior to operating the appliance.

8) To prevent injury, do not allow anyone who

is unfamiliar with the operation to use the

ﬁreplace.

CHILDREN AND ADULTS SHOULD BE

ALERTED TO THE HAZARDS OF HIGH

SURFACE TEMPERATURES, ESPE-

CIALLY THE FIREPLACE GLASS, AND

SHOULD STAY AWAYTO AVOID BURNS

OR CLOTHING IGNITION.

INSTALLATION AND REPAIR SHOULD

BE DONE BY AN AUTHORIZED

SERVICE PERSON. THE APPLIANCE

SHOULD BE INSPECTED BEFORE

USE AND AT LEAST ANNUALLY BY A

PROFESSIONAL SERVICE PERSON.

MORE FREQUENT CLEANING MAY

BE REQUIRED DUE TO EXCESSIVE

LINT FROM CARPETING, BEDDING

MATERIAL,ETC. IT IS IMPERATIVETHAT

CONTROL COMPARTMENTS,BURNERS

AND CIRCULATING AIR PASSAGEWAYS

OF THE APPLIANCE BE KEPT CLEAN.

DUE TO HIGH TEMPERATURES, THE

APPLIANCE SHOULD BE LOCATED

OUT OF TRAFFIC AND AWAY FROM

FURNITURE AND DRAPERIES.

WARNING: FAILURE TO INSTALL THIS

APPLIANCE CORRECTLY WILL VOID

YOUR WARRANTY AND MAY CAUSE A

SERIOUS HOUSE FIRE.

CLOTHING OR OTHER FLAMMABLE

MATERIAL SHOULD NOT BE PLACED

ON OR NEAR THE APPLIANCE.

YOUNG CHILDREN SHOULD BE CARE-

FULLY SUPERVISED WHEN THEY ARE

IN THE SAME AREA AS THE APPLI-

ANCE. TODDLERS,YOUNG CHILDREN

AND OTHERS MAY BE SUSCEPTIBLE

TO ACCIDENTAL CONTACT BURNS. A

PHYSICAL BARRIERS IS RECOMMEND-

ED IFTHERE ARE AT RISK INDIVIDUAL

INTHE HOUSE. TO RESTRICT ACCESS

TO A FIREPLACE OR STOVE, INSTALL

AN ADJUSTABLE SAFETY GATE TO

KEEP TODDLERS, YOUNG CHILDREN

AND OTHER AT RISK INDIVIDUALS OUT

OF THE ROOM AND AWAY FROM HOT

SURFACES.

Regency Bellavista™ B36XT Gas Fireplace 9

INSTALLATION

This includes:

1) Clockingtheappliancetoensurethecorrect

ﬁring rate (rate noted on label 31,000 Btu/h,

after burning appliance for 15 minutes.

2) Ifrequired,adjustingtheprimaryairtoensure

that the ﬂame does not carbon. First allow

the unit to burn for 15-20 min. to stabilize.

CAUTION: Any alteration to the product that

causes sooting or carboning that results

in damage is not the responsibility of the

manufacturer.

LOCATING YOUR

GAS FIREPLACE

A) Flat on Wall

B) Flat on Wall Corner

C) Recessed into Wall/Alcove

D) Corner

Diagram 1

1) When selecting a location for your ﬁreplace,

ensure that the clearances are met.

2) The appliance must be installed on a ﬂat,

solid, continuous surface For example a

wood,metalorconcreteﬂoororinaraised(on

thewall)application.Theappliancemust be

installedonametalorwoodpanelextending

the full width and depth of the appliance.

3) The B36XT Gas Fireplace can be installed

in a recessed position or framed out into the

room as in A, B, C and D. See Diagram 1.

INSTALLATION

CHECKLIST

1) Locate appliance

a) Room location (Refer to "Locating Your

Gas ﬁreplace" section)

b) Clearances to Combustibles (Refer to

"Clearances" section)

c) MantleClearances(Referto"Combustible

Mantel Clearances" section)

d) Framing&FinishingRequirements(Refer

to "Framing & Finishing" section)

e) VentingRequirements(Referto"Venting"

section)

2) Assemble Top Standoffs and Top Facing

Support and Side Nailing Strips (Refer to

"UnitAssemblyPriortoInstallation"Section).

NOTE: Must be done before installing unit

into place.

3) Install vent (Refer to "Venting" sections).

4) Make gas connections. Test the pilot. Must

beasperdiagram(Referto"PilotAdjustment

" section).

Converttopropaneifdesired(Referto"Gas

Line Installation" and "Conversion Kit from

NG to LPG" sections).

5) Make electrical connections to receptacle

supplied with unit (recommended).

6) Installstandardandoptionalfeatures. Refer

to the following sections:

a. Inner/Brick Panels (Optional)

b. Log Set Installation

c. Standard Flush Door

d. Remote Control (Optional)

e. Wall Switch

f. Wall Thermostat (Optional)

g. Fan Installation (Optional)

h. Light Installation (Optional)

7) Final check.

4) This appliance is Listed for bedroom

installations using the standard Remote

(millivolt thermostat system). Some areas

may have further requirements, check local

codes before installation.

5) The B36XT Gas Fireplace are approved for

alcoveinstallations,see"Clearances"section

for details.

6) We recommendthatyouplanyourinstallation

on paper using exact measurements for

clearances and floor protection before

actually installing this appliance. Have an

authorized inspector, dealer, or installer

review your plans before installation.

Note: For vent terminations refer to

"ExteriorVent TerminationLocations"

section.

10 Regency Bellavista™ B36XT Gas Fireplace

INSTALLATION

Alcove

Caution Requirements

The top, back and sides of the ﬁreplace are deﬁned by

standoffs. The metal ends of the standoff may NOT be

recessed into combustible construction.

WARNING

Fire hazard is an extreme risk

if these clearances (air space) to combustible materials are not

adhered to. It is of greatest importance that this ﬁreplace and vent

system be installed only in accordance with these instructions.

CLEARANCES

The clearances listed below are Minimum distances unless otherwise stated:

Amajorcauseofchimney related ﬁresisfailureto maintain requiredclearances(air space) tocombustiblematerials.It is ofthegreatestimportance

that this ﬁreplace and vent system be installed only in accordance with these instructions.

B36XT Clearance Requirements

Minimum Vent Clearances

to Combustibles

Clearance: Dimension Measured From:

A: Mantel Height (min.) 13" (330mm) Top of Fireplace Opening

B: Sidewall 12" (304mm) one side

only Side of Fireplace Opening

C: Ceiling 36-3/4" (933mm) Top of Fireplace Opening

D: Mantel Depth (max.) 12" (304mm) 21 " (533mm) from

Top of Fireplace Opening

E: Alcove Width 84" (2134mm) Wall to Wall (Minimum)

F: Alcove Depth 36" (914mm) Front to Back Wall (Maximum)

Notes: 0" No Hearth Required

Horizontal Top 2" (51mm)

Horizontal Side 1-1/2 " (38mm)

Horizontal Bottom 1-1/2" (38mm)

Vertical Vent 1-1/2" (38mm)

Table of contents

Other Regency Indoor Fireplace manuals

Regency

Regency Gi29L Series User manual

Regency

Regency Classic I1200S Quick start guide

Regency

Regency Plateau PTO30CFT User manual

Regency

Regency Excalibur P90 User manual

Regency

Regency P121-NG2 Quick start guide

Regency

Regency Cardinia F150B-1 Quick start guide

Regency

Regency Sunrise E33S User manual

Regency

Regency classic i2400m Quick start guide

Regency

Regency City Series San Franciso Bay 50 User manual

Regency

Regency Panorama P42 Quick start guide

Regency

Regency HZ33CE-NG Quick start guide

Regency

Regency GF900L-NG Quick start guide

Regency

Regency Bellerive I200B Quick start guide

Regency

Regency CV72EPV-NG Quick start guide

Regency

Regency Bellavista B36X Quick start guide

Regency

Regency Sunrise P33SE-NG4 Quick start guide

Regency

Regency Liberty L900 Gas Fireplace L900-NG1 Quick start guide

Regency

Regency Sunrise P33S-NG4 User manual

Regency

Regency P33-NG4 Quick start guide

Regency

Regency HZ54E-NG10 Quick start guide

Regency

Regency 510-994 User manual

Regency

Regency P36D-NG2 Quick start guide

Regency

Regency CV40E-NG Quick start guide

Regency

Regency classic fp90 Quick start guide

Popular Indoor Fireplace manuals by other brands

Brigantia

Brigantia 35-DVRS31N-2 User's installation, operation and maintenance manual

Nordpeis

Nordpeis Bergen Installation and user manual

Superior

Superior BCT2536TMN Installation and operation instructions

Quadra-Fire

Quadra-Fire 5100I-GD-B owner's manual

Renaissance

Renaissance RUMFORD 1000 user manual

Lacunza

Lacunza IV-800 Instruction book

Baxi

Baxi 940 Installer and owner guide

Dru

Dru Maestro 60/2 Tall RCH installation manual

Diamond Fireglass

Diamond Fireglass SS-O22 General assembly, installation, and operation instructions

HearthStone

HearthStone Windsor Bay 8830 Owner's manual and installation guide

Napoleon

Napoleon ASCENT B42 quick start guide

Enviro

Enviro E33GI owner's manual

Smeg

Smeg L30 FABE Installation & user's instructions

KEDDY

KEDDY K700 Installation instructions care and firing instructions

Godin

Godin 3451 manual

Jøtul

Jøtul Jotul GI 535 DV IPI New Harbor Installation and operation instructions

Austro Flamm

Austro Flamm Heidi Back 2.0 945048 operating manual

Desa

Desa CCFPDFT Owner's operating & installation manual
