RASOR DS503MT Mounting instructions

ELECTRIC SCISSORS

USE MANUAL

DS503MT

COMPANY

ACKNOLEDGEMENT

Dear Customer,

thank you for choosing a Rasor®Elettromeccanica S.r.l. product.

Rasor®has been a reference point in the field of cutting systems in the textile, clothing,

furniture, tailoring, sport, chemical, automotive, nautical and insulating material sectors for

years. Its production has been always synonymous with reliability attested by many of

satisfied customers.

Rasor®quality system supervises all the company activities in order to provide the Customer

with a service that meets its needs and expectations in terms of product quality, delivery

reliability and stock of finished products.

All the parts of the devices have been planned and produced to guarantee an optimum

performance. In order to keep the high quality level and the long reliabilty of the Rasor®

products, it is recommended using only original spare parts and to contact the head office

for any maintenance work.

Rasor®Elettromeccanica S.r.l. was established in Milan in 1946 by Luigi Spinelli. For more

than sixty years it has been producing automatic cutting systems, cutting units for textile

applications and electric and pneumatic cutters.

Initially considered as a point of reference for cutting systems in the

textile applications, the Rasor®products are nowadays widely used in

other fields: chemical, automotive, nautical and sport sectors and in

furniture manufacturing.

Rasor®can rely on the professional continuity of three generations,

thanks to the precious support of the promoting partner, to his passion, dedication and great

experience of seventy years.

The main characteristicof Rasor®is that each working phase, startingfrom the manufacturing

of the product up to its packing and delivery is carried out in Rasor®premises by qualified

operators who have professionaly grown up following the spirit of the company and of its

founders. This ensures the high quality which Rasor® has always considered as essential since

the beginning of its activity.

Following the innovative spirit mentioned above, our company is constantly focused on the

improvement of the product quality, on the study and development of new materials and

technologies.

1. GENERAL SAFETY RULES

This manual is an integral part of electric scissors DS503MT and must be carefully

read before using it since it gives important indications with regards to its safe

installation, use and maintenance. Keep it with care.

Before using electric scissors DS503MT, read carefully the following general

safety rules.

• PACKAGING.

After taking off the packaging make sure that the machine is intact. In case of

doubt do not use it and contact an authorized service centre. Do not leave

pieces of packaging (plastic bags, foam polystyrene, boxes, etc.) within the

reach of children or disabled persons since they are potential sources of danger.

• AVOID DANGEROUS ENVIRONMENTS.

Prevent the electric scissors DS503MT components from coming in contact

with damp or wet surfaces.

•KEEPCHILDRENAWAY.

Unauthorized persons, in particular children, must be kept away fromthe working

area.

•FEEDCABLE.

Prevent the feed cable from coming in contact with hot objects, pointed surfaces

or sharp edges. Never pull the feed cable of the machine. It must never be

replaced by the user. If necessary contact professionally qualified staff.

• KEEP THE WORKING AREA ALWAYS IN ORDER.

The workplace must always be kept in order and well lightened; liquids or oil

traces must not be present.

• ALWAYS USE ELECTRIC SCISSORS DS503MT PROPERLY.

Use the scissors only to carry out the works they have been designed for; do

not use them improperly.

• OBSERVE THE USE OF THE TOOLS.

Do not cut excessively thick materials and always check blade conditions.

• AVOID ACCIDENTAL STARTINGS.

Before connecting electric scissors DS503MT, make sure that everything is

installed properly.

•CLOTHING.

Do not use large clothes or accessories that might get stuck in the moving

parts.

• GOGGLES AND PROTECTIVE METAL MESH GLOVES.

Always use goggles, protective metal mesh gloves approved by Rasor®during

use and maintenance operations (according to UNI EN 388:2004 standard).

• SPARE PARTS.

During maintenance and replacement operations use only original spare parts.

Blade maintenance must be only performed by Rasor®technicians.

• INSTALLATION.

Any installation that is not in conformity with these specifications could jeopardize

your safety and cancels the warranty.

ALL RIGHTS ARE RESERVED ACCORDING TO THE

INTERNATIONALCOPYRIGHTCONVENTIONS,

The reproduction of any part of this manual, in any form, is forbidden without the

prior written authorization of Rasor®Elettromeccanica S.r.l.

The content of this guide can be modified without prior notice. Great care has

been taken in collecting and checking the documentation contained in this

manual to make it as complete and comprehensible as possible.

Nothing contained in this manual can be considered as a warranty, either

expressed or implied - including, not in a restrictive way, the suitability warranty

for any special purpose. Nothing contained in this manual can be interpreted as a

modification or confirmation of the terms of any purchase contract.

Rasor®Elettromeccanica S.r.l. machines have not been conceived to work in areas at risk of

explosions and at high risk of fire and they cannot cut wet or damp materials. Moreover,

they cannot work in case of rain.

In case of damage or malfunction, electric scissors DS503MT must not be used until the

Customer Care Technical Service has repaired them.

The original configuration of the electric scissors must not be changed at all.

On receiving the machine make sure the supply corresponds to what has been ordered.

In case of non-compliance immediately inform Rasor®.

Also make sure the scissors have not been damaged during transport.

Customer CareTechnical Service

WARNING

The installer and the maintenance man must know the content of this manual. Although

the main features of the machine described in this manual are not subject to change,

Rasor®Elettromeccanica S.r.l. reserves the right to modify the components, details

and accessories it deems necessary to improve the machine or to meet manufacturing or

commercial requirements at any time and without being obliged to update this manual

immediately.

Informative letter

For any information, please contact

RASOR®ELETTROMECCANICAS.r.l.

Via V. Caldesi, 6; 20161,MILANO (MI) - ITALY

Phone: +39.02.66221231; Fax: +39.02.66221293

e-mail: [email protected]

web: www.rasor-cutters.com

WARNING

2. TRANSPORT AND PACKING

The electric scissors are delivered in a carrying case, inside which there are various options.

The code of the ordered product and its serial number are indicated outside the package (see

picture 1). The following accessories are contained in a bag inside the package:

1) Heptagonal blade (7 sides);

2) Hexagonal wrench for grinding wheel nut tightening;

3) Greasetube;

4) Brushes for electric motor;

5) Fuse;

6) Drift for blade disassembly;

7) Butterfly wrench for blade nut disassembly.

3. PLATE DATA

The manufacturer's identification and EC STANDARD 2006/42/EC conformity plate (see picture

below) is located on the front part of the electric scissors.

The plate must not be removed at all, even if the machine is resold. Always refer to

the serial number written on the plate itself when contacting the manufacturer.

Several safety warnings are printed on a card which is applied to the electric scissors feeding

cable; such warnings must be strictly followed by everyone dealing with the machine. The

company is not to be held responsible for damage to property or accidents to

people which might occur if the above-mentioned warnings are not observed. In

such a case, the operator is the only person responsible.

READ THE

INSTRUCTION

MANUAL

DO NOT

REMOVE

THE

SAFETY

DEVICES

HIGH

VOLTAGE

SHEARING

RISK

USE

METAL

GLOVES

USE

GOGGLES

Class II double insulation

Serial number

Year of production

Model

Electric

data

DS503MT

220 230 50 60 0.25 60

1800

4. PRODUCT DESCRIPTION

12 7

The fixture described in this manual are electric scissors model DS503MT which are used in

order to quickly cut composite materials, in particular the fiber glass. They are extremely

versatile, light and precise in the cutting operation. Thanks to the use of a thin foot and an

effective cutting system with heptagonal, circular or decagonal blade, it is possible to use the

electric scissors for the precise trimming of molds, stuffed materials, leathers and laminated

materials. One special feature of electric scissors DS503MT is their ability to sharpen the blade

in each moment without disassembling it by means of a grinding wheel mounted on the

scissors head. After carrying out this operation, it is possible to start cutting again.

The electric scissors DS503MT are extremely light (they weight only 900g) and handy and

allow carrying out quick and precise cuts, even with curve profiles. A high power motor,

perfectly balanced, with ahigh number of revolutions and totallyfree of maintenance, reduces

the vibrations to the minimum. For this reason the electric scissors comply with European

Directive No. 2002/44/EC concerning the risks deriving from mechanical vibrations.

The mechanical parts are made of high-quality steel and bronze and require lubrication after

several working hours.

1 Enabling push button 9 Emery grinding wheel

2 Spiral cable gland 10 Sharpening button

3 Spiral electrical cable 11 Blade protection guard

4 Two-pole Contur plug 12 Motor support

5 Supporting foot 13 Motor casing

6 Polygonal blade 14 Worm screw adjustment

7Greaser15Referencepoint

8 Brush holder cap 16 Carbide counterblade

Device components

7. FIELD OF APPLICATIONS

6. RUMOR LEVEL

NOTE

It is advisable for electric scissors owners to verify the compliance with the standard concerning

safety of workers: Italian legislative decree 81/08.

The use of ear protecting devices is compulsory.

The maximum acoustic pressure level emitted by electric scissors DS503MT is about 60 dB (A).

Noise tests have been carried out in compliance with Standard UNI EN ISO 11202:2010.

The device noise levels, measured at different distances (without any sound wave filtering

system), vary in the extent of few db (A).

Electric scissors DS503MT have been designed, manufactured and assembled to cut every

kind of fabrics or materials, with the exception of metal, plastic or wood, by means of rotary

circular, decagonal or heptagonal blades.

This equipment must not work:

- in areas prone to explosions;

- in presence of fine dust or corrosive gases;

- on wet or damp materials;

- to cut plastic, metal and wooden materials.

It is forbidden to use electric scissors DS503MT for purposes different from the

above-mentioned ones.

5. TECHNICAL FEATURES

The technical data are only indicative and they can be changedwithout notice.

50 mm with carbide counterblade

1.800 rev./min

about 8 mm

60 W

0,5 A

900 g

1300 g

1,5 m

LUX 200

< 2,5 m/s2

0 ~ 55°C

10 ~ 95% without condensate

Temperature

Humidity

Weight (with package)

Electrical cable length

Minimum luminosit

for workin

erations

Vibrations at the start up

Cutting working depth

Motor power

Weight (with feeding cable)

Electric scissors DS503MT features

Blade diameter

Blade speed

Max. absorption

K190 steel circular blade

Extra steel heptagonal blade

HSS Germany steel heptagonal blade

HSS steel heptagonal blade

HSS steel heptagonal blade covered with

Teflon

Extra steel Germany heptagonal blade

HSS steel heptagonal blade

Solid carbide heptagonal blade

HSS steel decagonal blade

50SEXT

50SEXT G

50SHSS

Features of the available blades

50CK

50DHSS

50SGHSS

50CHSS

50SHSSTF

50SMD

9. RESIDUAL RISKS

Even though the electric scissors are safe, operators must pay attention to preserve their and

other people’s safety.



At the end of the working operations, the motor could be very hot.



The cutting blade can work even when the protective device is disassembled.

8. USE WARNINGS

We recommend following the indications below in order to always work in safety conditions.

•All the operations must be carried out complying strictly with the safety rules of the

country where the machine is to be installed.

•It is STRICTLY FORBIDDEN to smoke during the installation or adjustment operations of

the electric scissors.

•The Customer undertakes to comply with and make his staff observe all the rules and

regulations in force concerning safety, prevention of accidents and health in the work

place. Therefore, the Customer assumes the responsibility to strictly follow all the rules

and regulations in force, as well as the special provisions in force in sport and public

installations the Customer declares to know after receiving all the relative necessary

information.

•The electric scissors work also without their safety protective device. This

protective device must NEVER be removed.

•Always check the resistance of the material to be cut and the kind of blade which is being used.

•The Customer shall equip his own personnel with all the individual safety protections for

the execution of the works, as well as with the ones which might be prescribed by the

Manufacturer due to specific danger conditions of the plant or of the area where the

personnel must work.

•Only one operator must use the electric scissors always standing behind the guide handle.

Do not make any adjustment while the blade is working or while the electric plug is

connected.

•Always pay attention to the electric cable position to prevent it from being cut or damaged

by the blade.

•It is allowed to assemble electric scissors DS503MT on machines O.E.M. on condition

that their original structure is not modified. Otherwise, the intervention must be certified

by Rasor®.



10. USE

To use the electric scissors manually, proceed as follows:

1) Lay the material to be cut on a table;

2) Connect the scissors to the power supply;

3) Put the material on the cutting foot;

4) Enable the enabling push button (see picture 3);

5) Push the electric scissors in the desired direction,

being careful to keep the material in front of them

as stretched as possible and preventing it from

curling in the front part of the scissors.

NOTE

The thrust on the electric scissors must be as uniform as

possible. To carry out linear cuts with precision (and to

follow predetermined paths), we also recommend using

the arrow point (see point “A” in figure 4).

11. MOTOR FUSE REPLACEMENT

In order to replace the motor fuse, proceed as follows:

1) Disconnect the scissorsfrom the powersupply;

2) Remove the screw from the fuse cover (see

point “A” figure 5);

3) Take out the glass fuse by means of the proper

pliers supplied (see figure 6);

4) Verify its integrity (see figure 7) and, in case, install a new

fuse checking the correct amperage;

5) Close the cover and tighten the screw.

WARNING

Never use the scissors when the fuse cover is open.

Risk of electric shock.

13. EMERY GRINDING WHEEL ADJUSTMENT

After using the machine for some hours without

interruption, or if the machine cutting capacity is reduced,

it is necessary to sharpen the blade. To carry out this

operation, start the blade and press emery grinding wheel

“2” on the blade itself (by means of push button “1”, as

shown in figure 9) for 3-4 seconds.

Repeat this operation 2-3 times.

The emery grinding wheel can slide along its seat (see

figure 10) in order to vary the sharpening angle. If the

blade, aftervarious sharpening operations, hasa chamfer

(sharp perimeter) with an excessive length (higher than

1.5 mm), it is necessary to slightly move the emery

grinding wheel away from the blade. In order to do this,

it is sufficient to slightly loosen the screws without

removing them, making the emery grinding wheel slide

toward direction A, and then tighten the two screws

again.

12. REPLACEMENT OF THE MOTOR BRUSHES

Electric scissorsDS503MT are provided with a high power

permanent magnet motor and torque. For this reason it

is necessary to check periodically if the carbon brushes

are worn in order not to jeopardize the motor operation

and its duration period. Unscrew the caps located on the

cover by means of a slotted screwdriver; withdraw the

carbon brushes, check if they are worn and, if needed,

replace them. Assemble the two caps again, being careful

to hold them in a perfectly vertical position, and screw

them completely only when you are sure that the mouth

is the correct one.

Note: The brush must be inserted with its black part

directed inside the motor.

Note: A slight difference in the wear of the two brushes is absolutely normal in a permanent

magnet motor. Nevertheless, in the event that the difference between them is excessive, it is

necessary to apply to a technical center for a complete check of the fixture.

Before carrying out any operations on the electric scissors, make sure that the supply plug is

not connected to the mains.

WARNING



Table of contents

Other RASOR Cutter manuals

RASOR

RASOR GRT86 Quick setup guide

RASOR

RASOR FORZA Operation instructions

RASOR

RASOR GRT-MINI Mounting instructions

RASOR

RASOR DS503 Mounting instructions

RASOR

RASOR SW12SM Mounting instructions

RASOR

RASOR DD120RC User manual

RASOR

RASOR GRT12SM Mounting instructions

RASOR

RASOR FP861A2 Mounting instructions

RASOR

RASOR FP120SM User manual

RASOR

RASOR DD120ML User manual

RASOR

RASOR D86P2 Mounting instructions

RASOR

RASOR D86PS2 Mounting instructions

RASOR

RASOR FP120DT Mounting instructions

RASOR

RASOR SW12S Mounting instructions

RASOR

RASOR SW100 Mounting instructions

RASOR

RASOR DD120 User manual

RASOR

RASOR D 100 Mounting instructions

RASOR

RASOR SW12M Mounting instructions

RASOR

RASOR D 86PS User manual

RASOR

RASOR FP861V2 Mounting instructions

RASOR

RASOR FP862MT Mounting instructions

RASOR

RASOR DD120DT User manual

RASOR

RASOR NERAPRO Operation instructions

RASOR

RASOR FP100 Mounting instructions

Popular Cutter manuals by other brands

Milwaukee

Milwaukee HEAVY DUTY M12 FCOT Original instructions

Makita

Makita DCS552 instruction manual

SignWarehouse.com

SignWarehouse.com Bobcat BA-60 user manual

Makita

Makita 4112HS instruction manual

GEISMAR STUMEC

GEISMAR STUMEC MTZ 350S manual

Hitachi

Hitachi CM 4SB2 Safety instructions and instruction manual

Dexter Laundry

Dexter Laundry 800ETC1-20030.1 instruction manual

GCC Technologies

GCC Technologies AFJ-24S user manual

DeWalt

DeWalt XR LI-ION DCS350N manual

Baudat

Baudat ES1 instruction manual

Mafell

Mafell ZAF 200 Operating instructions and spare parts list

Makita

Makita 4100NH instruction manual

Formax

Formax FD 574 Operator's manual

EINHELL

EINHELL TE-MA 1500 Original operating instructions

Husqvarna

Husqvarna Cut-n-Break K 760 Operator's manual

CLEAN ROOM DEVICES

CLEAN ROOM DEVICES CRD130SS Operator's manual

TRI tool

TRI tool 301A user manual

Roller

Roller King 1 1/4 operating instructions
