Rancilio Classe 8 DE User manual

[1] - [2] TALL (DE version)

The Classe 8 DE Tall features the drip-

tray in the lowered position to accom-

modate larger cups – up to 32 oz.

A swing-away demitasse cup holder,

placed close to the group-head, ena-

bles up-close Italian-style extraction.

Steam-wand extensions (for use with

lowered drip-tray) allow for comforta-

ble steaming.

[3] TSC - Technological Steaming

Control (DE version)

The TSC is an innovative, completely

automatic steam wand that makes it

possible to heat milk while obtaining

creamy soft, thick foam. The TSC

wand features ergonomic keys which

allow the user to select “cappuccino”

or “latte”. Each selection is fully

customizable, with 12 froth levels and

an adjustable temperature setting.

The TSC wand stops automatically

upon reaching your programmed

temperature. Furthermore, thanks to

the use of non-stick material, cleaning

is fast and easy.

The TSC is patented by Rancilio.

CLASSE 8 TALL

[2][1] [3]

Available versions

- 1,2,3 and 4 groups

- DE: version with electronic control and automatic dosage

Reliability

- ideal for establishments with a mid-to-high volume of espresso consumption

- body made of stainless steel

- optional TSC available for Class 8 DE

Innovative image

- avant-garde design

Easy to use

- On-board computer (DE version) controls the main functions of the machine, optimizing ﬂavor and

performance: automatic cleaning program, programmable electronic pre-infusion, SEQ (Standard

Espresso Quality) notiﬁes barista of variances in extraction time

- swing-away demitasse cup holder allows for hands-free extraction

- large working space

Coffee machines

CLASSE 8 TALL

CLASSE 8 DE TALL

Rancilio

macchine per caffè s.p.a.

Viale della Repubblica 40

20010 Villastanza di Parabiago

Milano - Italy

tel. +39 0331 408200

fax +39 0331 551437

[email protected]

www.rancilio.com

Rancilio North America Inc.

8102 S.Lemont Rd. #1200

Woodridge, IL 60517 - USA

ph. +1 630 427 1703

fax +1 630 427 1713

[email protected]

www.rancilio.com

Rancilio España s.a.

Gran Vía de Carlos III, 84 3ª

Ediﬁcio Trade

08028 Barcelona - Spain

tel. +34 902 884 275

Fax +34 93 496 57 01

[email protected]

www.rancilio.com

TECHNICAL FEATURES CLASSE 8 TALL

independent heat exchangers

electric heating

built-in volumetric pump

pump and steam pressure gauge

automatic water level control

on-board computer with multifunctional display

electronic boiler pressure/temperature control

STANDARD MODEL

1 filter holder for two cups per group // 1 filter holder for one cup // 2 steam wands // 1 hot water dispenser, with programmable dosage quantity

// coffee tamper, measuring scoop and disks for cleaning // feet extensions

OPTIONAL

TSC Technological Steaming Control // electric cup warmer

ACCESSORIES

DP water softener with automatic or manual control// MD dosing grinder

COLORS

stainless steel

TECHNICAL DATA

STANDARD MODEL - OPTIONAL - ACCESSORIES

low voltage (24V) operation controls

stainless steel machine body

weightgroups dimensions* WxDxH (in) boiler (lt) volts element (W)

1 27 x 20 x 19 inch 5 110/230 116 lb

2700/3000

2 34 x 20 x 19 inch 11 230 167 lb

6000

3 43 x 20 x 19 inch 16 230 207 lb6000

4 52 x 20 x 19 inch 22 246 lb230 6000

R.E.M. Asia Paciﬁc

138 Peel St.

North Melbourne 3051

Australia

Tel +61 39 329 8838

Fax +61 39 329 8832

[email protected]

www.rancilio.com

*Without side drain-tray extensions, decrease the total width by 5”
