Qilive Q1588 User manual
True Wireless Earbuds
Q.1588
FR
Véritables écouteurs
sans fil
HU Vezeték nélküli
fülhallgató
ES
Auriculares
verdaderamente
inalámbricos
RO Căști true wireless
PT
Auscultadores sem
fios
RU Беспроводные
наушники
PL
Prawdziwie
bezprzewodowe
słuchawki douszne
UA
Повністю
бездротові
навушники
User manual P. 4
Manuel d’utilisation P. 14
Manual del usuario P. 25
Manual do utilizador P. 36
Instrukcja użytkownika S. 47
Használati útmutató 58. o.
Manual de utilizare P. 67
Руководство пользователя C. 78
Посібник користувача C. 90
EN
FR
ES
PT
PL
HU
RO
RU
UA
EN
FR
ES
PT
PL
HU
RO
RU
UA
1
2
3
4
4
EN
1. SAFETY INFORMATION
Before using this product, carefully read these instructions and
keep the user manual for future reference.
1. High sound pressure. Hearing damage risk. Do not
listen at high volume levels for long periods.
2. WARNING: KEEP OUT OF REACH OF CHILDREN. Small
parts! May cause choking if ingested. This product is not a
toy – never allow children to play with the appliance. Always
store the product out of reach from children and pets.
3. No naked flame sources, such as lighted candles, should
be placed on the apparatus. Do not place in direct sunlight
or in the near of heat sources (e.g. heaters, stoves, water
heater, etc.).
4. The apparatus shall not be exposed to dripping or splashing
and that no objects filled with liquids, such as vases, shall
be placed on it. Do not use it outdoors or in the bathroom.
Keep away from water and high humidity along with high
temperatures, direct sunlight, dusty smokey, and steamy
places.
5. This appliance should be used in temperate climates only.
6. Never wear the earbuds while showering or bathing, or when
participating in water sports, e.g., swimming, surfing, etc.
7. Stop using the device immediately in case of an abnormality
or failure.
8. Use of earbuds will impair your ability to hear other sounds.
Use caution while using your earbuds when you are
engaging in any activity that requires your full attention. Using
the earbuds while operating a motor vehicle, motorcycle
or bicycle may be dangerous. Surrounding sounds may
not be heard clearly, which may cause traffic accidents
or injuries. Do not use the device in places where when
surrounding sounds cannot be heard may cause danger,
such as roadways, station platforms, railroad crossing, or
construction sites.
9. When using the product while walking, turn down the volume
until surrounding sounds can be also heard clearly.
10. This product contains magnetic material. If you have a
pacemaker or other electrical medical devices, consult your
physician before using this product.
5
EN
11. Avoid dropping. Dropping or hitting the device may damage
it.
12. Do not use the earbuds without installed ear tips.
13. The earbuds are only to be charged with the charging case
provided.
14. Do not tamper with the product. Never attempt to service,
dismantle the product yourself, or push objects of any kind
into the products, as this may result in fire, electric shock,
or equipment damage and will also invalidate the warranty.
15. Never handle the earbuds and their charging case with damp
or wet hands.
16. Batteries shall not be exposed to excessive heat such as
sunshine, fire, or the like.
17. Do not continue charging the battery if it does not reach full
charge within the specific charging time. Overcharging may
cause the battery to become hot, rupture, or ignite.
18. Observe the following temperature limits for this product:
• Normal operation: 0 to 35°C
• Storage: 0 to 45°C
• Transportation: 0 to 45°C
19. WARNINGS: Both earbuds and charging case contain non-
replaceable batteries. Used batteries must not be disposed
of in the household rubbish. The batteries must be removed
from the appliance before it is scrapped. To remove the
batteries from both the charging case and two earbuds,
take them to a designated disposal/collection site. For your
safety, do not attempt to remove the batteries yourself. If the
batteries are not properly removed, they may lead to damage
to the batteries and device, cause personal injury, and/or
result in the device being unsafe.
20. WARNING: Do not ingest the earbuds! Chemical burn
hazard. This product contains batteries. If the earbud with
its battery is swallowed, it can cause severe internal burns in
just 2 hours and can lead to death. If you think earbuds might
have been swallowed or placed inside any part of the body,
seek immediate medical attention.
21. Disposal of a battery into fire or a hot oven, or mechanically
crushing or cutting of a battery,that can result in an explosion;
6
EN
22. Leaving a battery in an extremely high temperature
surrounding environment that can result in an explosion
or the leakage of flammable liquid or gas; and a battery
subjected to extremely low air pressure that may result in an
explosion or the leakage of flammable liquid or gas.
23.
Batteries must not be disposed of with normal
household waste. Recycle them at the collection
points provided for this purpose. Contact the local
authorities or your dealer for recycling advice.
Correct disposal of old batteries helps protect the
environment and human health.
24. This marking indicates that this product should not
be disposed of with other household wastes. To
prevent possible harm to the environment or human
health from uncontrolled waste disposal, recycle it
responsibly to promote the sustainable reuse of
material resources. To return your used device, please use
the return and collection systems or contact the retailer
where the product was purchased. They can take this
product for environmentally safe recycling.
2. TECHNICAL DATA
Bluetooth version Bluetooth 5.3
Frequency Range 2402 - 2480 MHz
Sensitivity 105±3dB
Impedance: 16 ohm ±15%
Input DC 5V 500mA
Earphones Battery Capacity 40 mAh x 2
Charging Pod Battery Capacity 250 mAh
Charge Time 1.5 hours
Max transmission power 4.77dBm
7
EN
3. DESCRIPTION
1. Battery Level of
Charging Case
2. Charging Port of
Charging Case
3. MFB of Earphone
4. Charging Pin of
Earphone
4. USE
4.1 Charging for Earphones:
Fully charge the battery for 2-3 hours before using the earphones
for the first time, or when they have been unused for extended
periods.
Put the earphones into the charging case, they will charge
automatically, the indicators of case will stay on light. Once the
earphones are fully charged, it will be light off.
4.2 Charging for charging Case
When the charging case is connected with charger (or computer
USB port) by included charging cable, the indicator will display the
battery level. When the charging case is fully charged, the indicator
will show “100”.
NOTE:
When the charging case is out of battery, the earphones will not
turn on/off automatically when removed from or placed back into
the charging case. In this case, turn the earphones on/off manually.
4.3 First Use & Pairing
Auto Power-On & Pairing Manual Power-On & Pairing
2S
2S
8
EN
Open the lid of charging
case, take out earphones
from the case, and they will
automatically power on and
enter into pairing mode.
Touch the MFB for 2 secs on
both earphones to turn on the
earphones. (You will hear the
prompt tone).
The earphones will
automatically enter pairing
mode
4.3.1 Connect
LED flash in
blue & red LED flash and
then off
Paring Mode
When earphones are into pairing mode, one earphones will flash into blue
and red,and the rest will not flash when earphones are connected.
Connect
BLUETOOTH
Bluetooth
Connected
Q.1588
Turn on the device’s Bluetooth setting .Search for and choose Q.1588 to pair,
your device will show “connected”.
4.4 Power-Off
Auto Power-Off
9
EN
Put L&R earphones into charging pod, and close the lid, the earphones will
automatically power off.
Manual Power-Off
5S
5S
1. Touch the MFB for 5 secs on both earphones to power off the earphones.
2. The earphones will automatically turn off when without paring for 10mins.
4.5 Wearing
Insert the earphones directed towards your ear canal. Twist gently until the
earphones fit comfortably and get better sound experience.
4.6 Control
ICON FUNCTION OPERATION
Answer call Tap the MFB button of L/R
earbud once
End call Tap the MFB button of L/R
earbud 2 times
Reject call Touch the MFB button of L/R
earbud for 2s
Play / Pause Tap the MFB button of L/R
earbud 2 times
Play next track Touch the MFB button of R
earbud for 2s
Play previous track Touch the MFB button of L
earbud for 2s
10
EN
ICON FUNCTION OPERATION
SIRI / Voice assistant Tap the MFB button of L/R
earbud 3 times
volume up Tap the MFB button of R
earbud once
volume down Tap the MFB button of L
earbud once
4.7 Reset
If you have problem to connect the earphones with your device,
don’t worry about it, please follow the step as below:
1. Make sure all devices have turned off Bluetooth Function.
Clean all the paring records if need.
2. Take the earphones out of the case, tap either earphones
by 5 times quickly, prompt sound will be actived, then follow
the pairing step as instruction.
5. MAINTENANCE AND CLEANING
1. Never immerse the earbuds or any accessories in water or
other liquids!
2. Do not spray or pour water or any other liquid on or inside
the charging case.
3. Do not use any abrasive cleaners, chemicals, glass
cleaners, universal cleaners or oil-based maintenance
agents!
5.1 Cleaning the ear buds
If the volume is lower than it should be with the current setting,
clean the earbuds.
1. Remove the ear tips from the earbuds.
Note: Do not pull the ear tips excessively when attaching or
detaching them. The ear tips are very delicate and may tear.
2. Remove any earwax or debris from the earbuds with the
soft brush, soft cotton swab, or other soft and dry tools.
Note: Do not use excessive force while removing earwax or debris.
The earbuds may be damaged.
3. Cover the earbuds with the ear tips.
5.2 Cleaning the charging contacts
If the batteries do not charge properly, wipe gold-coloured contacts
on both earbuds with a dry, soft cloth.
