Pulsar Y15W User manual
INSTRUCTION MANUAL FOR WATCH CALIBRE
Y15W
THIS PRODUCT CONTAINS A BUTTON BATTERY
If swallowed or placed inside any part of the body, the battery can
cause severe or fatal injuries within 2 hours or less.
Button batteries are hazardous whether new or used. Keep batteries
out of reach of children.
If you think the battery may have been swallowed or placed inside
any part of the body, seek immediate medical attention. Contact the
Australian Poisons Information Centre immediately on 13 11 26
(New Zealand 0800 764 766) for 24 / 7 fast, expert advice.
ENGLISH
ANALOGUE WATCHES
n
SCREW DOWN CROWN
[for models with screw down crown]
1 Turn Crown counterclockwise until you no
longer feel the threads turning.
2 Crown can be pulled out.
Unlocking the crown
1 Push Crown back in to normal position.
2Turn Crown clockwise while pressing it lightly
until tight.
Locking the crown
* When using the watch in water:
Before using the watch in water, be sure the crown is screwed in completely.
Do not operate the crown when the watch is wet or in water.
English
2
n
HOW TO START THE MECHANICAL WATCH (Cal. Y621)
1 Pull out to the rst click.
2 Turn to show the previous day’s date.
3 Pull out to the second click.
n
TIME/CALENDAR SETTING FOR MODELS WITH
DATE CALENDAR
To initially start your watch, swing it from side to side in a horizontal arc
for about 30 seconds.
* If the watch is worn daily, PULSAR's automatic mechanism will wind the mainspring
automatically through normal wrist movement.
n
TIME SETTING FOR MODELS WITHOUT CALENDAR
CROWN
1 Pull out.
2 Turn to set the time.
3 Push back.
10
CROWN
English
3
4 Turn until the desired date appears.
* Turn Crown to advance Hour and Minute hands.
5 Turn to set the time.
6 Push back in to normal position.
n
TIME/CALENDAR SETTING FOR MODELS WITH DAY AND DATE CALENDAR
1 Pull out to the rst click.
2 Turn to show the previous day’s date.
3 Turn in the opposite direction to show
the previous day of the week.
For Cal. PC33, turn clockwise to set
the date only.
4 Pull out to the second click.
WED
8
CROWN
5 Turn until the desired date and day appears.
* Turn Crown to advance Hour and Minute hands.
6 Turn to set the time.
7 Push back in to normal position.
English
4
Notes on time setting:
1 When setting Minute hand of a quartz watch, advance it a few minutes
ahead and then turn it back to the exact time.
2 If your watch has three hands, pull out Crown all the way when Second
hand points at 12 o’clock. After adjusting the time, push Crown back in to
normal position in accordance with a time signal for "00" seconds.
Notes on calendar setting:
1The date will change gradually between 9:00 P.M. and 4:00 A.M. Therefore, do
not change the calendar during this time period. Otherwise, it may not change
properly. If it is necessary to set the calendar during that time period, first
change the time to any time outside it, set the calendar and then reset the
correct time.
2 If your watch has a bilingual day calendar, choose the desired language.
When the day shifts automatically to the next day, the other language will
appear temporarily.
3 When setting the hour hand, check that AM/PM is correctly set.
The watch is so designed that the calendar changes once in 24 hours.
Turn the hands past the 12 o’clock marker to determine whether the time is
set for the A.M. or P.M. period. If the calendar changes, the time is set for
the A.M. period. If it does not change, the time is set for the P.M. period.
English
5
l As the battery is inserted at the factory to check the function and performance
of the watch, its actual life once in your possession may be less than the
specied period.
l When the battery expires, be sure to replace it as soon as possible to prevent
any malfunction.
l We recommend that you contact an AUTHORIZED PULSAR DEALER for
battery replacement.
Day setting for Cal. PC33
At the second click position, turn the hands clockwise and counter-
clockwise repeatedly between 11:15 p.m. and 3:45 a.m. to select the
desired day and language.
English
6
l Loss/gain (monthly rate) is less than 15 seconds (20 seconds for some
calibres) at normal temperature range (5°C ~ 35°C)(41°F ~ 95°F).
lThe battery is not rechargeable. Never attempt to recharge it, as this
may cause battery leakage or damage to the battery.
CAUTION
lDo not remove the battery from the watch.
lIf it is necessary to take out the battery, keep it out of the reach of
children. If a child swallows it, consult a doctor immediately.
lNever short-circuit, tamper with or heat the battery, and never expose
it to re. The battery may burst, become very hot or catch re.
WARNING
English
7
WATER RESISTANCE
lNon-water resistant
lWater resistance (5 bar)*
If “WATER RESISTANT 5
BAR” is inscribed on the
case back, your watch is
designed and manufactured
to withstand up to 5 bar and
is suitable for swimming, yachting and
taking a shower.
I f “ WATER RESISTANT 10
BAR”, “WATER RESISTANT 15
BAR” or “WATER RESISTANT
20 BAR” is inscribed on the
case back, your watch is
l
Water resistance (10 bar/15 bar/20 bar)*
designed and manufactured to with-
stand up to 10 bar/15 bar/20 bar and
is suitable for taking a bath, shallow
diving, but not for scuba diving.
We recommend that you wear a PULSAR
Diver’s watch for scuba diving.
If “WATER RESISTANT” is
not inscribed on the case
back, your watch is not water
resistant, and care should
be taken not to get it wet
If “WATER RESISTANT” is
inscribed on the case back,
your watch is designed and
manufactured to withstand up
to 3 bar, such as accidental
lWater resistance (3 bar)
contact with splashes of water or rain, but
it is not designed for swimming or diving.
as water may damage the movement. If
the watch becomes wet, we suggest that
you have it checked by an AUTHORIZED
PULSAR DEALER or SERVICE CENTER.
English
8
* Before using the water resistance 5, 10, 15 or 20 bar watch in water, be sure the
crown is pushed in completely.
Do not operate the crown when the watch is wet or in water. If used in sea water,
rinse the watch in fresh water and dry it completely.
* When taking a shower with the water resistance 5 bar watch, or taking a bath with
the water resistance 10, 15 or 20 bar watch, be sure to observe the following:
•Do not operate the crown when the watch is wet.
•If the watch is left in warm water, a slight time loss or gain may be caused.
This condition, however, will be corrected when the watch returns to normal
temperature.
NOTE:
Pressure in bar is a test pressure and should not be considered as corresponding to
actual diving depth since swimming movement tends to increase the pressure at a
given depth. Care should also be taken on diving into water.
TEMPERATURES
and 35°C (41° F and 95°F).
Temperatures over 60°C or 140°F
(50°C or 122°F for some calibres)
[for analogue quartz watch
only]
Your watch works with
stable accuracy within a
temperature range of 5° C
may cause battery leakage or shorten
the battery life.
Do not leave your watch in very low
temperatures below –10° C (+14° F)
for a long time since the cold may
cause a slight time loss or gain.
However, the above conditions will
be corrected when the watch returns
to normal temperature.
