Pullman Holt E1200 Application guide

Save For Future Reference

Replacement Parts List

Portable Tank Extractor

Model E-1200

Vac Motors Replacement Parts

Ref.

No. Part No. Description Qty.

1 B703473 Cord Set 1

2 B703472 Cord Retainer 1

3 B703471 Switch 3

4 B703470 Switch Plate 1

5 B703469 Motor Strap 2

6A B703468 Motor A/C 1

6B B703522 Motor B/C 1

7 B703467 Exh. Hose Adapter 1

Body Replacement Parts

Ref.

No. Part No. Description Qty.

1 B703496 Lid Hinge 1

2 B703495 Lid 1

3 B703494 Lid Gasket 1

4 B703493 Hose Barb 1

5 B703492 Gasket 1

6 B703491 Elbow 1

7 B960941 Dump Valve 1

8 B980227 Gasket 1

Ref.

No. Part No. Description Qty.

9 B980228 Nut 1

10 B703490 Float Cage w/Ball 1

11 B703489 Filter 1

12 B703488 Coupler 1

13 B703487 Latch 1

14 B703486 Elbow 1

15 B703485 Screen 2

Component Parts

Ref.

No. Part No. Description Qty.

1 B703484 Handle 1

2 B703483 Caster 2

3 B703482 Bumper Guard 1

4 B703481 Bumper Insert 1

5 B703480 Filter Screen 1

6 B703479 Close Nipple 1

7 B703478 90° Elbow 1

Ref.

No. Part No. Description Qty.

8 B703477 Hose Barb 2

9 B700144 Hose Barb 1

10 B700144 Hose Barb 1

11 B703476 Pump 1

12 B703475 Spring 1

13 B703474 Wheel 2

14 B703521 Hub Cap 2

10702 N 46th Street •Tampa, FL 33617

(813)971-2223 •toll free (800) 237-7582

fax (813) 971-6090 •order entry fax (800) 833-8875

www.pullmanholtcorp. com B703607 1/04

WIRING DIAGRAM

2 Vacuum Motors, 1 Pump

WARNING

Any repairs to the electrical system should be preformed by

an Authorized Pullman-Holt Service Center or by a qualified

electrician.
