Prorelax TENS Back Pain User manual
TENS Back Pain Relief System
Terapie TENS contra dolores de espalda
Terapia TENS para alívio das dores lombardes
OPERATING INSTRUCTION
INSTRUCCION PARA EL USO
MANUAL DE INSTRUÇÕES
TENS back pain relief system
Table of Content
Introduction 3
Safety Information 4-5
Package Contents 6
Parts Diagram 7
Inserting/Changing the batteries 8
Putting on the belt 9-10
Turning On the device 11
Turning O the Device 11
Selecting the Treatment Time 12
Selecting the Program 13
Selecting the Therapy Intensity Level 14
Special Features 14-15
Trouble Shooting 16
Care and Maintenance 17
Disposal 17
Technical Specications 18
Warranty 19
Contact
2
IMPORTANT INFORMATION
PRORELAX TENS UNITS ARE PARTICULARLY SAFE AND USER
FRIENDLY. THE INTENSITY CAN THEREFORE ONLY BE ADJUSTED
WHEN THE TREATMENT BELT IS FASTENED AND THE ELECTRODES
ARE IN CONTACT WITH THE SKIN.
Thank you for purchasing our TENS BACK PAIN RELIEF SYSTEM. This pro-
duct has been designed for people who suer from muscular tension in their lower
back. The TENS BACK PAIN RELIEF SYSTEM ghts back pain the natural way with no
side eects. We want you to be totally satised with this product, which should help
you reduce your pain.
Your TENS BACK PAIN RELIEF SYSTEM is a Transcutaneous Electric Nerve
Stimulation (TENS) device. It provides treatment in the low frequency range. When
using this method, weak electrical pulses are produced onto the skin using two or
more electrodes.
This stimulates muscles, nerve bres and acupuncture meridians in order to activate
your body’s own pain relief mechanisms.
Chronic pain can be treated with dierent methods such as medication or opera-
tions or with alternative treatment methods such as acupuncture or TENS.
The TENS treatment can block pain signals by interrupting the transmission of
impulses through the skin by means of electric impulses. As a result, the signal “pain”
is not transmitted to the brain and thus not felt as pain.
Furthermore, it will work with the body’s own pain inhibitors; gentle electric currents
from the TENS device stimulate the release of endorphins that function as a pain
reducer. The pain is therefore stopped, eased or removed by the body itself.
This electrical stimulation cannot remove the causes of, or cure of a disease, but it
could help ease or block pain in the body.
In order to achieve all the benets from the
TENS BACK PAIN RELIEF SYSTEM , we ask you to carefully read the following
safety information and warnings.
Introduction
Dear Customer,
3
Safety Information
4
Safety Information
Use this device only according to its intended purpose as specied in this in-
struction manual. The warranty will be invalidated if the device is used for other
than the intended purpose.
Do not use the device if it is not operating correctly, if it has been dropped, if it has
fallen into water or if it has been damaged.
Do not attempt to repair the device yourself in the event of a malfunction; this will
invalidate the warranty. Repairs should only be executed by an authorized service
centre.
Do not operate this device near high-frequency transmitters, such as e.g., micro-
waves, short wave transmitters or radio transmitters.
These may impair the device’s ability to function.
Do not switch the device on until the belt has been xed on the body.
Do not use the device while taking a bath or a shower.
Do not use this device while sleeping.
Do not use this device while driving a car or another kind of vehicle or while
operating machinery or heavy equipment.
Protect the device from moisture. If liquid should get into the device, remove the
battery immediately and discontinue use. Should this happen, contact your dealer
or contact our customer service
Never use the device in rooms where aerosols (sprays) are used or pure oxygen is
being administered.
Battery Safety Information
Keep away from children.
Do not recharge.
Do not short-circuit.
Do not throw into a re.
Please recycle. Do not dispose of old batteries with your household waste;
dispose of them safely at your recycling centre or business where the batteries
were purchased.
Safety Information
5
THE DEVICE SHOULD NOT BE USED BY PATIENTS WITH:
• PACEMAKERS, DEFIBRILLATORS OR EXTREME CARDIAC
IRREGULARITIES
• METAL IMPLANTS OR ELECTRONIC AUXILIARY DEVICES
• DIABETES OR ABNORMALLY HIGH BLOOD PRESSURE
• A TENDENCY TOWARD INTERNAL BLEEDING
• PREGNANT WOMEN
Therapy with the TENS BACK PAIN RELIEF SYSTEM is a proven and
natural way of ghting pain, however, it does not replace medical diagnosis or
treatment. If you are not sure, you may consult with your doctor before using this
device.
Consult your doctor always before use, if you suer from epilepsy or certain
disabilities.
Persons whose sensitivity is disturbed or impaired should only apply this device
under supervision of your physician.
Do not use this device if suering from menstrual pains.
Do not use this device if your skin burns or is numb.
Pain relief treatment following injury or an operation should only be carried out
under the careful supervision and instruction of a doctor or physiotherapist.
Do not treat parts of the body that swell, burn or iname or have peeling skin,
wounds or other sensitive points.
In case of doubt, always seek the advice of a doctor and follow his instructions for
treatment.
Keep the unit out of the reach of children. Medical products are not toys!
Treatment should be monitored if used on or near children or persons who are
handicapped and only have a limited capability to use this device.
The treatment should be pleasant. If you feel pain or have an unpleasant feeling,
stop treatment and consult your doctor.
Package Contents
Package Contents
Before using this device, make sure that you have all components.
The TENS BACK PAIN RELIEF SYSTEM includes:
1. 1 belt
2. 1 TENS CONTROL UNIT
3. Clipholder
4. 3 AAA batteries
5. 1 storage bag
6. 1 instruction manual
23
4 5
1
5
8
7
9
17 18
11
14
6
10
12151613
3
2 1
4 4 3
6
6
The packaging can be reused
or recycled. Please dispose
of properly if no longer
required. If you notice any
damage from shipping,
please contact customer
service immediately.
Parts Diagram
Parts Diagram
1 Integrated Connection Cables
2 Conductive Silicone Pads
3 Belt
4 Velcro
5 Power on/adjust, increase key
6 Power o/adjust/decrease key
7
Program Mode/ Therapy time selection
8 CH 1 (Channel 1) Key
9 CH 2 (Channel 2) Key
10 Program number
11 Therapy time remaining
12 CH 1 intensity level
13 CH 2 intensity level
14 Therapy duration status
15 Lock status indicator
16 Battery status indicator
17 Battery compartment
18 Battery cover
2
3 4
5 6 7
1
5
8
7
9
17 18
11
14
6
10
12151613
3
2 1
4 4 3
7
Inserting/Changing the Batteries
1. Open the battery compartment [17] at the back of the device by pushing the
battery cover [18] labelled “Open” downward (this area features raised marks for
easy identication).
2. Insert 3 AAA (1.5 V) batteries in the battery compartment; make sure to match
up the symbols (+/–).
3. Close the battery cover by carefully placing the stud into the slot in the rear
area and sliding it upward, applying slight pressure.
4. Follow the same procedure when replacing the battery at a later date.
Note:
Always use only 3 x 1.5V (AAA) batteries. Please refer to “Battery Safety Information”,
for important precautions regarding the batteries.
Inserting/Changing the Batteries
2
3 4
5 6 7
1
5
8
7
9
17 18
11
14
6
10
12151613
3
2 1
4 4 3
8
Putting on the Belt
Putting on the Belt
1. Before putting on the belt, remove any residue of skin cream or ointment and
make sure that your skin is clean and free of oil.
Do not place the belt on injured or in amed areas of the skin, such as wounds,
spots, rashes or reddening.
2. Before use, dampen the integrated silicon electrodes with water or a con-
ductive gel.
3. Position the electrodes on the area of the body to be treated. If your back aches
at waist level; you are su ering from pain in the upper treatment area. Position
the belt so that the middle of the belt is at waist level.
9
Caution: Subjective perception of the electric current may alter with changing fre-
quencies or pulse widths. Lower the intensity as soon as the application becomes
unpleasant or the pleasant prickling sensation is not felt for a long period of time.
4. If your back pain is in the lower treatment area, position the belt so that the
middle of the belt sits approximately 1 to 2 inches below the waist.
5. When the belt has been maneuvred into the correct position, bring the two
ends of the neoprene straps together and fasten with the built-in Velcro pads.
6. The belt may be tightened or loosened as shown by adjusting the Velcro
fastener ( See diagram below)
Putting on the Belt
10
