PROAIM P-18-JS User manual
1
What’s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
Central
Post
LCD Mounng Arm
Tools
18 Camera Crane Jib with Stand for Gimbals
Pan-Tilt & Fluid Head (P-18-JS)
A s s e m b l y M a n u a l
Jib Stand
Secon 1st
Secon 2nd
Secon 3rd
Secon 4th
Secon 5th
Weight Closer
Weight Rod
Accessory Wire Tensioner Knob
2
Slide Central Post of Jib onto the Jib Stand
and ghten knob-2 to secure it.
Jib Stand Setup
Open shank from central post. Leave the
black washers at one side help of wrench.
Insert the secon 4 inside central post then
Align holes of secon with central post to
screw in the shank back.
Then ghten the bolt properly with the help
of a wrench, and to aach secon 5 to 4,
loosen the bolt from secon 4.
Knob 2
Jib Secon Setup
Secon-5 has connecng bars aached with
secon-4 on both ends and then ghten
them together using provided allen key.
3
Connue the Arm build by sliding in secon 3
onto secon 4 as shown in the image.
Loosen the bolt from the connecng bar with
the help of a 6mm Allen key and wrench, and
then insert the bolt using the holes provided.
Then ghten them together using provided
allen key.
Connue the Arm build by sliding in secon 2
onto secon 3, and nally secon 1 onto sec-
on 2.
Connect the Wire/Cable Tensioner with
cable. Simply rotate the mid-secon handle
to ghten the cable adding required amount
of strength to the system.
Connecng Bar
Tighten Bolt
Then ghten them together using provided
allen key. As shown in the image.
4
Secure your camera setup with weight
closers as shown.
NOTE: Once you discover correct balance,
consider marking the weights for that parcu-
lar camera; facilitang an easier set up the next
me.
Aach LCD mounng arm onto central fork
then ghten the knob.
Lock the pin for keeping your camera in a
xed angle to take stable shots.
Insert weight rod of secon 5 then with a 1”
hole, according to your camera setup
requirements. Secure them with Weight
Closers.
NOTE: The Central Fork has provision to attach
LCD Monitor (Not Included) via LCD Mounng
Arm.
5
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon
and evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our
utmost support and care unl you use our product.
YOUR PROAIM 18 CAMERA CRANE JIB WITH STAND FOR GIMBALS, PAN-TILT & FLUID HEAD
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
