INSTRUCTIONS FOR USE

Pro-Ject Jukebox S2

Jukebox S2

Controls, features and connections

(1) TURNTABLE MOTOR SWITCH

(2) AMPLIFIER ON/OFF SWITCH

(3) REMOTE CONTROL

(4) INPUT SELECTOR, VOLUME CONTROL

(5) PLATTER

(6) DRIVE BELT

(7) STEPPED DRIVE PULLEY

(8) TONEARM COUNTERWEIGHT

(9) TONEARM TUBE

(10) TONEARM REST AND REMOVABLE TRANSPORT LOCK

(11) TONEARM LIFT LEVER

(12) HEADSHELL WITH FINGER LIFT

(13) TURNTABLE DISPLAY

(14) EARTH CONNECTION

(15) PHONO OUT

(16) LINE IN

(17) VAR OUT

(18) FIX OUT

(19) BT ANTENE

(20) SPEAKERS OUTPUT

(21) POWER SUPPLY SOCKET

(22) LID

(23) LID HINGE

(24) HINGE FASTENERS

POWER SUPPLY (NOT SHOWN) *

Dear music lover,

Thank you for purchasing a record player from Pro-Ject Audio Systems.

In order to achieve maximum performance and reliability with this record player you should study these instructions

for use carefully.

Warning of a hazard for the user, the unit or possible misuse

Important notice

The following instructions for adjusting the cartridge are provided in case the cartridge is replaced by a

different model at a later date.

During assembly and adjustment of the deck small parts could be lost if not carefully placed in a suitable

receptacle. Before starting assembly make get fwqmiliar with the parts listed above and correspondingly

numbered in the technical drawings above. Separately packed items are marked with an asterisk *.

Safety instructions

The power supply is used to connect and disconnect the unit from the mains. Make sure that the plug

is easily accessible at all times. Hold the plug when unplugging the power cord. Never handle the

power cord while your hands are wet or damp.

Avoid letting liquids enter the device. Never place any item containing liquid, like a flower vase, on

or near the device. Never spill any liquid on the device. Never place any naked flame sources, like

lighted candles, on or near the device. The product shall not be used in damp or wet locations, next to

a bathtub, sink, swimming pool or any other similar conditions.

Keep plastic bags away from children to prevent any risk of suffocation.

Platter and drive belt installation

Please remove brown paper insert which holds the platter in transport position. Put the felt mat on the top of

the platter. Install the drive belt as shown in the following illustration.

Cartridge downforce adjustment

The counterweight (8) supplied is suitable for cartridges weighing between 3 - 7g (weight no. 81). The

counterweight is pre-set perfectly from the factory.

In case you need to set the tracking force, please read following instructions:

Place the stylus pressure gauge onto the platter. To adjust the amount of pressure, carefully move the

counterweight along the support rod, until the stylus pressure is sufficient to raise the pressure gauge to the

level position. Moving the counterweight away from the cartridge will reduce pressure and towards will

increase pressure. Finally secure the counterweight using hexagonal key provided.

If the stylus gauge becomes level, then the correct pressure has been achieved. However if the there is

insufficient or excessive pressure the gauge will either not move or tilt down.

Connectors

Take care to connect the left and right channels correctly. The right channel is usually marked red,

the left channel black or white.

The red speaker terminals carry the positive signal (+), the black speaker terminals the negative

signal (–). Make sure the polarity of the connection is correct at each end of the cables.

Connection to the speakers

The output terminals accept loudspeaker cables terminated with 4mm Banana plugs, spades connectors

or naked wire.

Variable output (Line output)

A power amplifier or active loudspeakers can be connected to the output sockets marked Var Out (17).

Fixed output (Record output, connecting a headphone amplifier)

Fix Out (18) connects an analogue record device or a Pro-Ject Head Box headphone amplifier.

Phono output

To use an external phono preamplifier, connect the RCA sockets marked Phono OUT (15). The earthing wire

may be connected to the screw terminal if you encounter hum problems when using the turntable.

Line input

Line level sources such as CD player, radio or TV can be connected to the input sockets marked Line IN (16).

Mains power connection

Connect the low voltage plug from the power supply to the 24V socket (21) before connecting the power

supply to the mains.

Switching ON and OFF (turntable motor)

The rocker switch (1) on the bottom turns the motor of the turntable

To switch on from standby or to standby (amplifier)

The rocker switch (2) on the bottom turns the unit on or back into standby.

Control of the unit using the knob on the front

Standby

After the unit is powered on by the rocker switches on the bottom, pressing the knob for 3 seconds, turns the

unit on. For turn the unit back to standby press the knob again for 3 seconds

It is important to turn the unit to standby before it´s powered off by the switch on the bottom. To not

follow this step may cause damage to the speakers.

Input selector

After the unit is turned on, pressing the button in the middle selects desired input. After start BT input is

always selected. Pressing input button changes inputs in following order: BT > Turntable > Line In. BT input

gives a “beep” sound when selected. Selected input is indicated on the top line of the display.

Volume

Adjust the volume to the desired level rotating the knob. Volume can be set in 33 steps (0-32) and is

indicated on the bottom line of the display

Remote control

red button turns the unit on or back into standby

Mute activate/deativate mute

Bass+/Bass-/Treble+/Treble- tone control

Loudness activate/deactivate Loudness

BT/Turntable/Line in direct access to input

Volume+/Volume- adjust volume

BT connection

BT is active only when BT input is selected.

Juke Box E remembers last paired unit and reconnects automatically when available and if the BT

device allows automatic reconnections.

Juke Box E doesn´t request any pairing code confirmation.

Only one active BT connection is possible at a time. If the unit can’t be found in BT search window

in mobile device, make sure that there is no other active BT connection.

BT input gives 2 different “beeps”,

First appears when BT input is selected. And in case of BT device disconnects.

Second appear when BT device is found and connected.

Pairing with Android devices

Open Settings and tap on BT. Turn on BT and tap on Scan. Searched devices will show up. Tap on "Juke Box

E".

Pairing with Apple devices

Tap on Settings, tap on BT, turn on BT. Your device will automatically start searching for available devices.

Tap on "Juke Box E".

Fitting the lid

Fit the lid (dust cover) carefully over the lid hinges (23) and adjust the screws (24) until the lid stays open

where you want it to without being too stiff to open or close.

Changing replay speed

Put the belt (6) over the larger diameter part of the motor pulley (7). To revert to 33 r.p.m. repeat the

proceedings using the smaller step on the pulley.

For detailed product information please refer to the Pro-Ject web site www.project-audio.com.

Maintenance and cleaning

Your record player requires little or no regular maintenance. Remove dust with a slightly moistened antistatic

cloth. Never use a dry cloth because this will create static electricity which attract more dust! Antistatic

cleaning fluids are available at specialist stores but must be applied sparingly to avoid damage to rubber

parts. It is recommended to fit the needle cover before cleaning or maintenance is carried out to avoid damage.

If the player is not used over a long period of time the drive belt can be removed to prevent unequal stretching.

Always disconnect the record player from the mains power supply as a precaution before maintenance!

Mounting and connecting the cartridge

** All cartridges with half inch mounting holes can be fitted. Leaving the needle's protection cover on, fit the

cartridge to the headshell (12) using the screws supplied with the cartridge by passing one screw through

each slot in the headshell (12). Do not tighten the nuts yet.

Connect the tonearm wires to the cartridge pins as follows:

white left channel positive (L+)

red right channel pos. (R+)

green right channel return (R -)

blue left channel return (L -)

The full sound quality of the record player can only be achieved if the cartridge is correctly adjusted. Particular

tools like the Pro-Ject alignment tool “Align IT” are required to accomplish this job properly.

If you are not well acquainted with the adjustment of cartridges you are advised to call upon the willing help of

your Pro-Ject dealer to accomplish this task for you.

Please note: Adjusting a cartridge and tonearm calls for the greatest care in order to avoid damaging

the cartridge or tonearm bearings. Leave this work to your dealer if you are in any way unsure of the

necessary steps and precautions to be taken.

Useful tips

The record player should be positioned on a low-resonance surface such as wood or multiple layer ply board

to avoid structural vibrations disturbing replay.

Technical specifications Pro-Ject Jukebox S2 / Pro-Ject 8.6 E

Turntable

Nominal speeds

333/45 r.p.m.

Speed variance

333: ±0,80% 45: ±0,70%

Wow and flutter

333: ±0,29% 45: ±0,27%

Signal to noise

--65dB

Effective tonearm mass

88,0g

Effective tonearm length

8 8,6" (218,5mm)

Overhang

222,0mm

Amplifier

Power output 2 x 50W at 4 ohms

SNR -75dB

Volume control 32 step

THD +N 0,5% at 1kHz, RL = 8 ohms, P = 1W

Crosstalk -80 dB

Phono amplifier Moving magnet (MM)

Phono gain: 43dB

Line level inputs 2 pairs RCA

Amplifier gain 32 dB

BT 2.1 + EDR

Treble equalizer +- 12dB

Bass equalizer +- 12dB

General

Replacement battery remote control 2 x AAA

Power consumption

4,5W

Outboard power supply

24V/4A DC

Dimensions (W x H x D)

415 x 118 x 334mm

Weight

5,0kg

Dimensions packaging (W x H x D)

488 x 235 x 393mm

Weight incl. packaging

7kg

Potential incorrect use and fault conditions

Pro-Ject turntables are manufactured to the highest standards and undergo strict quality controls before

leaving the factory. Faults that may possibly occur are not necessarily due to material or production faults but

can sometimes be caused by incorrect use or unfortunate circumstances. Therefore the following list of common

fault symptoms is included.

The platter doesn't turn although the unit is switched on:

The unit is not connected to the mains power supply.

No mains at the socket.

Drive belt is not fitted or has slipped off.

No signal through one or other channel or both channels:

No signal contact from the cartridge to the internal tonearm wiring or from that to the arm lead or

from that to the phono box or between that and the amplifier. This could be due to a faulty plug,

broken wire or solder joint or simply loose plug/socket connection.

Phono input not selected at amplifier.

Amplifier is not switched on.

Amplifier or speakers are defective or muted.

No connection to the loudspeakers.

Strong hum on phono input:

No earth connection from cartridge or arm or arm cable to amplifier, or earth loop.

Distorted or inconsistent sound from one or both channels:

Record player is connected to wrong input of amplifier, or MM/MC switch incorrectly set.

Needle or cantilever damaged.

Wrong r.p.m., drive belt overstretched or dirty, platter bearing without oil, dirty or damaged

Service

Should you encounter a problem which you are not able to alleviate or identify despite the above information,

please contact your dealer for further advice. Only when the problem cannot be resolved there should the

unit be sent to the responsible distributor in your country.

Guarantee repairs will only be affected if the unit is returned correctly packaged. For this reason we recommend

keeping the original packaging.

Never return a record player without making sure that is it safely disassembled and correctly packaged in the

original packaging according to the diagrams on the last page of this user guide. Please remove these parts

and pack them separately: lid, counterweight (4), anti-skating weight (10) and belt (22).

Fit the cartridge protection cap and the transport lock for the tonearm tube (66), prior to carefully packaging

the record player.

Warranty

The manufacturer accepts no responsibility for damage caused by not adhering to these instructions

for use and/or by transportation without the original packaging. Modification or change to any part

of the product by unauthorized persons, release the manufacturer from any liability over and above

the lawful rights of the customer.

Pro-Ject Audio Systems is a Registered Trademark of

H. Lichtenegger.

This guide was produced by: Pro-Ject Audio Systems

The information was correct at the time of going to press.

The manufacturer reserves the right to make changes to

the technical specification without prior notice as deemed

necessary to uphold the ongoing process of technical

development.

Other manuals for Remote Box S2

Table of contents

Other Pro-Ject Audio Systems Turntable manuals

Pro-Ject Audio Systems

Pro-Ject Audio Systems Xtensions 9 S-Shape User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems Debut Carbon DC Esprit SB User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems Debut RecordMaster II User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems Pro-Ject RPM 1.3 Genie User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems Essential II DIGITAL User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems Debut PRO User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems 1 Xpression Classic User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems Debut III User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems RPM 5.1 User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems Essential II Demon User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems A2 User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems Debut III SE User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems RPM 6.1 SB SuperPack User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems RPM 1.3 Genie User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems Pro-Ject 2 Xperience Comfort User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems SIGNATURE 10 User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems Juke Box Series User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems Juke Box Esprit User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems Primary E Phono User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems 1 Xpression III User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems T1 Phono SB User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems Align it DS3 User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems Pro-Ject DEBUT III PHONO SB User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems Pro-Ject RPM 3 Carbon User manual

Popular Turntable manuals by other brands

Gemini

Gemini CDT-05 MKII product manual

Rotel

Rotel RP-820 owner's manual

Shuman

Shuman MC-250BT user manual

Stanton

Stanton STR8-150 owner's manual

Audio Technica

Audio Technica AT-LPW40WN user manual

Crosley

Crosley McQueen CR7011-GY instruction manual

Reloop

Reloop SMP-1 Operation manual

auna

auna TT-Classic Plus instruction manual

COMO AUDIO

COMO AUDIO Turntable Analog user manual

Dual

Dual 1009 F owner's manual

REED

REED Muse3C user manual

AXIOMTEK

AXIOMTEK OPS883-H Series Quick installation guide

Pioneer

Pioneer PL-71 operating instructions

Vestax

Vestax PDX-a1 owner's manual

Denon

Denon DP-400 owner's manual

Dual

Dual 504 Service manual

Audio-Techica

Audio-Techica AT-LP60XBT user manual

Goldring

Goldring G99 instruction manual
