INSTRUCTIONS FOR USE

Pro-Ject Xtension 12 Evolution

Pro-Ject Xtension Ortofon RS/AS

Speed Change

45.0

Pro-Ject Xtension 12 Evolution / Ortofon RS/AS

Controls, features and connections

1 Low voltage cable and power supply socket

2 Stepped drive pulley

3 Drive belt * 3a Hook *

4 Platter *

5 ON/OFF switch, speed selector

6 Arm board 6a Spirit level

7 Adjustable feet *

8 Lid hinges

9 Lid *

Pulley cover (not shown) *

Record weight (not shown) *

Pro-Ject Connect it connection cable (not shown) *

Single adapter (not shown) *

Power supply (not shown) *

Gloves (not shown)

Dear music lover,

thank you for purchasing a PRO-JECT AUDIO record player.

In order to achieve maximum performance and reliability with this record player you should study these instructions

for use carefully.

Warning of a hazard for the user, the unit or possible misuse.

Important notice.

During assembly and adjustment of the deck small parts could be lost if not carefully placed in a suitable

receptacle.

Before starting assembly make yourself acquainted with the parts listed above and correspondingly numbered

in the technical drawings above. Separately packed items are marked with an asterisk *.

Safety instructions

AC outlet voltages vary from country to country. Before connecting to the mains, make sure that the

voltage in your area meets the voltage requirements printed on the power supply.

The power supply is used to disconnect the unit from the mains. Make sure that the power supply is

easily accessible at all times. Never handle the power supply while your hands are wet or damp.

Avoid letting liquids enter the device. Never place any item containing liquid, such as a flower vase

on or near the device. Never spill any liquid on the device. Never place any naked flame sources,

such as lighted candles on or near the device. The product shall not be used in damp or wet locations,

next to a bathtub, sink, swimming pool or any other similar conditions.

Keep plastic bags away from children to prevent any risk of suffocation.

Useful tips

The base and the record player should be positioned on a low-resonance surface such as wood or multiple

layer ply board to avoid structural vibrations disturbing replay.

Set-up

The deck is supplied partially disassembled and carefully packaged for safe transport. Carefully remove all

parts from the transport packaging.

Screw the four feet (7) onto the threaded bolts located on the underside of the plinth. Make sure the surface

you wish to use the turntable on is level (use a spirit level) before placing the turntable on it.

Carefully place the platter bearing housing over the bearing axle. Put the record weight on the platter and

level the plinth using the spirit level (6a) and the adjustable feet (7).

To adjust the feet, hold (A) and turn (B). Turning (B) clockwise decreases the height, turning anticlockwise

increases the height of the feet.

Fit the drive belt (3) around the platter (4) and the smaller diameter part of the motor pulley (2).

Avoid getting sweat or grease on the belt as these will deteriorate the performance and reduce the belt's

lifespan. Use absorbent kitchen paper to remove any oil or grease from the outer edge of the hub and the belt.

Put the pulley cover on its rests.

Please note: We recommend to use the record player without a mat on the platter.

Fitting the lid

Fit the lid (dust cover 9) carefully over the hinge prongs and adjust the screws (8) until the lid stays open

where you want it to without being too stiff to open or close.

Mains power connection

The turntable is supplied with a power supply suitable for your country's mains supply. Check the label before

connecting to ensure compliance with the mains rating in your house.

Connect the low voltage plug from the power supply to the socket (1) on the rear of the record player before

connecting the power supply to the mains.

Starting the motor, Stand By

Pressing the button Speed Change will switch on the player from stand by. Press and hold the push button

Speed Change to put the unit into stand by.

Changing replay speed

The belt must be on the smaller (50Hz models) larger (60Hz models) diameter part of the motor pulley.

Press the button Speed Change to switch between 33 and 45 r.p.m.. The selected speed will be displayed

digitally.

To replay records at 78 r.p.m. perform the following steps: Remove the pulley cover. Using the tool (3a), fit

the belt (3) around the larger (50Hz models, for 60Hz models the smaller diameter has to be used) diameter

step of the pulley (2). Start the turntable by pressing the button Speed Change and switch the speed to

45 r.p.m., the platter will then revolve at 78 r.p.m.. The display still shows 45 r.p.m..

Speed Change +

45.0

Pitch control

Repeatedly pressing the +or -buttons increases or decreases the replay speed in twenty steps of 0,1 r.p.m.

respectively. The adjusted speed is displayed digitally.

Technical specifications Pro-Ject Xtension 12 Evolution / Ortofon RS-309D/AS-309S

* Electronic speed change * 33/* 45 and 78 r.p.m.

Speed variance ±0,09 %

Wow and flutter ±0,01 %

Signal to noise 73dB

Power consumption 2W

Outboard power supply 16V/1.000mA AC, suitable for your country's mains supply

Dimensions (W x H x D) 550 x 250 x 450mm, dust cover open 550 x 550 x 560mm

Weight 20kg

Pro-Ject Evolution tonearms

Cartridge downforce adjustment (Pro-Ject Evolution tonearms)

Remove the transport lock (3) from the tonearm. Store it in the original packaging so they are available for

any future transportation.

Pushing carefully, turn the counterweight (7) onto the rear end of the tonearm tube (2), and so that the

downforce scale (7a) shows towards the front of the player. Lower the armlift and position the cartridge in the

space between arm rest and platter. Carefully rotate the counterweight (7) until the armtube balances out.

The arm should return to the balanced position if it is moved up or down. Do not forget to remove the

cartridge protection cap if fitted.

Once the arm is correctly balanced return it to the rest (3). Hold the counterweight (7) without moving it, and

gently revolve the downforce scale ring (7a) until the zero is in line with the anti-skating prong (8). Check

whether the arm still balances out.

Rotate the counterweight counter clockwise (seen from the front) to adjust the downforce according to the

cartridge manufacturer's recommendations. One mark on the scale represents 1 mN (= 0,1g / 0,1 Pond) of

downforce.

Tonearm Pro-Ject 12cc Evolution: The counterweights (7) supplied are suitable for cartridges weighing

between 4 - 7g (counterweight no. 27), 6 - 9g (counterweight no. 31), 8 - 12g (counterweight no. 32) or

10 - 14g (counterweight no. 33).

Please note: Adjust the downforce prior to installing the anti-skating weight.

1 Headshell with finger lift

2 Tonearm tube

3 Tonearm rest and removable transport lock

4 Tonearm lift lever

5 Anti-skating weight *

6 Anti-skating weight wire support

7 Tonearm counterweight * 7a Downforce scale

8 Anti-skating weight adjustment scale

9 Tonearm base

Adjusting the azimuth (Pro-Ject Evolution tonearms)

The cartridge needle must be vertical in the record groove in order to trace the

groove wall modulations correctly.

A small screw at the bearing end of the arm allows incorrect azimuth to be

corrected if your needle is not mounted exactly perpendicular to the cartridge

body (which is often the case).

Slacken off the screw just enough to be able to revolve the arm tube without

applying force. Note! Do not remove the screw completely!

Screw

With the aid of a good magnifying glass adjust the needle until it is vertical in the groove (i.e. perpendicular

to the record's surface). Ideally this should correspond to the top surface of the cartridge body being parallel

to the record surface, but in practice this is often not the case.

When you are satisfied that the needle is vertical retighten the screw carefully.

Please note: Under no circumstances should the arm tube be adjusted with the needle still in the

record groove! Irreparable damage may be caused to the cantilever suspension! The arm must be

lifted to make each adjustment and lowered afterwards to check it.

Anti-skating force adjustment (Pro-Ject Evolution tonearms)

The anti-skating force must be adjusted corresponding to the downforce as follows:

Downforce Groove in the stub (8)

10 - 14mN 1st from bearing rings

15 - 19mN 2nd " " "

20mN and bigger 3rd " " "

Hang the loop of the thread of the anti-skating weight (5) in the groove of the anti-skating stub (8) corresponding

to the downforce applied to your cartridge and hang the thread in the groove of the wire support (6).

Adjusting the vertical tracking angle -vta- (Pro-Ject Evolution tonearms)

Put a record on the platter. When the needle is lowered into the record groove and the tonearm is not resting

on the tonearm rest (3), the tube (2) of the tonearm should be parallel to the surface of the record.

If it is not loosen both hexagon screws in the tonearm base (9) just enough to allow vertical movement of the

arm pillar without force and slide the arm up or down until it is parallel.

Carefully retighten the hexagon screws without applying excessive force (which would deform the arm pillar)

– finger tight is quite sufficient.

Ortofon RS tonearms

Cartridge downforce adjustment (Ortofon RS tonarms)

Remove the transport lock (3) from the tonearm. Store it in the original packaging so they are available for

any future transportation. Set the knob (5) to 0.

Place the counterweight (7) halfway along the counterweight support rod at rear of arm, being sure to have

the counterweights (7) securing screw uppermost. Lower the armlift and position the cartridge in the space

between tonearm rest (3) and platter. Carefully move the counterweight (7) along the support rod, until the

armtube (2) balances out. The arm should return to the balanced position if it is moved up or down. Do not

forget to remove the cartridge protection cap if fitted.

With the power off, and the platter static, place the supplied stylus pressure gauge onto the platter.

Carefully lower the armlift and position the tip of the stylus on the pressure gauges measuring tongue. The

downforce will be displayed digitally.

Adjust the Downforce, using the knob (6), to the cartridge manufacturer's recommendations. This adjustment

must be done with the tonearm resting on the tonearm rest (3). Finally secure the counterweight with the

securing screw (7).

The counterweight (7) supplied is suitable for cartridges weighing between 18 - 40g.

Please note: Adjust the downforce prior to setting the anti-skating compensation.

Anti-skating force adjustment (Ortofon RS and AS tonearms)

The anti-skating force must be adjusted corresponding to the downforce. Rotate the knob (5) to adjust the

Anti-skating force. One mark on the scale represents 5 mN (= 0,5g / 0,5 Pond) of downforce.

Adjusting the vertical tracking angle -vta- (Ortofon RS and AS tonearms)

Put a record on the platter. When the needle is lowered into the record groove and the tonearm is not resting on

the tonearm rest (3), the surface of the cartridge body should be parallel to the surface of the record.

If it is not loosen the hexagon screw in the tonearm base (8 RS tonearms or 7 AS tonearms) just enough to

allow vertical movement of the arm pillar without force and slide the arm up or down until it is parallel.

Carefully retighten the hexagon screw without applying excessive force (which would deform the arm pillar) –

finger tight is quite sufficient.

1 Detachable headshell with finger lift

2 Tonearm tube

3 Tonearm rest and removable transport lock

4 Tonearm lift lever

5 Anti-skating force adjustment knob

6 Downforce adjustment knob

7 Tonearm counterweight with securing screw*

8 Tonearm base

Stylus pressure gauge (not shown) *

Ortofon AS tonearms

Cartridge downforce adjustment (Ortofon AS tonearms)

Remove the transport lock (3) from the tonearm. Store it in the original packaging so they are available for

any future transportation. Set the knob (5) to 0.

Pushing carefully, turn the counterweight (6) onto the rear end of the tonearm tube (2), so that the downforce

scale (6a) shows towards the front of the player. Lower the armlift and position the cartridge in the space

between arm rest and platter. Carefully rotate the counterweight (6) until the armtube balances out. The arm

should return to the balanced position if it is moved up or down. Do not forget to remove the cartridge

protection cap if fitted.

Once the arm is correctly balanced return it to the rest (3). Hold the counterweight (6) without moving it, and

gently revolve the downforce scale ring (6a) until the zero is in line with the black line at the rear end of the

tonearm tube (2). Check whether the arm still balances out.

Rotate the counterweight counter clockwise (seen from the front) to adjust the downforce according to the

cartridge manufacturer's recommendations.

The counterweight (6) supplied is suitable for cartridges weighing between 18 - 25g. An alternative weight

for cartridges weighing between 26 - 38g is available as an accessory part.

Please note: Adjust the downforce prior to setting the anti-skating compensation.

Anti-skating force adjustment and Adjusting the vertical tracking angle -vta-

See Ortofon RS tonearms

Connection to the amplifier

Connect the tonearm cables to the Phono input (sometimes labelled gram, disc or RIAA) on your amplifier.

Make sure that the phono input offers correct matching and amplification for the type of cartridge used. Line

inputs (such as CD, Tuner, Tape or Video) are not suitable.

Take care to connect the left and right channels correctly. The right channel is usually marked red, the left

channel black or white. Check the manual supplied with your amplifier for relevant information. An earthing

wire may be connected to the screw terminal on your amplifier if you encounter hum problems when using

the record player.

If your amplifier does not have an input suitable for phono cartridges you will require a separate phono

amplifier stage for MM or MC cartridges which is then connected between the record player and a free line

level input of the amplifier.

For detailed product information regarding Pro-Ject Audio phono amplifiers please refer to the Pro-Ject web

site www.project-audio.com.

1 Detachable headshell with finger lift

2 Tonearm tube

3 Tonearm rest and removable transport lock

4 Tonearm lift lever

5 Anti-skating force adjustment knob

6 Tonearm counterweight * 6a Downforce scale

7 Tonearm base

Fitting and connecting the cartridge

All cartridges with half inch mounting holes can be fitted. Leaving the needle's protection cover on, fit the

cartridge to the headshell using the screws supplied with the cartridge by passing one screw through each

slot in the headshell (1). Do not tighten the nuts yet.

Connect the tonearm wires to the cartridge pins as follows:

white left channel positive (L+)

red right channel pos. (R+)

green right channel return (R -)

blue left channel return (L -)

The full sound quality of the record player can only be achieved if the cartridge is correctly adjusted. Particular

tools like the Pro-Ject alignment tool are required to accomplish this job properly.

If you are not well acquainted with the adjustment of cartridges you are advised to call upon the willing help of

your Pro-Ject dealer to accomplish this task for you.

Please note: Adjusting a cartridge and tonearm calls for the greatest care in order to avoid damaging

the cartridge or tonearm bearings. Leave this work to your dealer if you are in any way unsure of the

necessary steps and precautions to be taken.

Technical specifications Pro-Ject 12cc Evolution

Tonearm medium mass

Supplied counterweights cartridge weight 4 - 7g, 6 - 9g, 8 - 12g or 10 - 14g

Downforce range 10 - 35mN

Effective tonearm mass 10,5g

Effective tonearm length 12 " (304,8mm)

Overhang 13,2mm

Weight 271g (without counterweight)

Lenght Connect it connection cable 123cm

Capacity tonearm cable 65pF/meter

Technical specifications Ortofon RS-309D

Tonearm medium mass

Supplied counterweight cartridge weight 18 - 40g (including headshell)

Downforce range 0 - 50mN

Effective tonearm mass 6g

Effective tonearm length 326mm

Overhang 15mm

Offset angle 19 degrees

Weight 725g (plus headshell and cartridge)

Lenght Connect it connection cable 123cm

Capacity tonearm cable 65pF/meter

Technical specifications Ortofon AS-309S

Tonearm medium mass

Supplied counterweight cartridge weight 18 - 25g (including headshell)

Optional counterweights cartridge weight 26 - 38g (including headshell) weight D

Downforce range 0 - 50mN

Effective tonearm mass 5g

Effective tonearm length 326mm

Overhang 15mm

Offset angle 19 degreess

Weight 535g (plus headshell and cartridge)

Lenght Connect it connection cable 123cm

Capacity tonearm cable 65pF/meter

Potential incorrect use and fault conditions

Pro-Ject turntables are manufactured to the highest standards and undergo strict quality controls before

leaving the factory. Faults that may possibly occur are not necessarily due to material or production faults but

can sometimes be caused by incorrect use or unfortunate circumstances. Therefore the following list of common

fault symptoms is included.

The platter doesn't turn although the unit is switched on:

The unit is not connected to the mains power supply.

No mains at the socket.

Drive belt is not fitted or has slipped off.

No signal through one or other channel or both channels:

No signal contact from the cartridge to the internal tonearm wiring or from that to the arm lead or

from that to the phono box or between that and the amplifier. This could be due to a faulty plug,

broken wire or solder joint or simply loose plug/socket connection.

Phono input not selected at amplifier.

Amplifier not switched on.

Amplifier or speakers defective or muted.

No connection to the loudspeakers.

Strong hum on phono input:

No earth connection from cartridge or arm or arm cable to amplifier, or earth loop.

Distorted or inconsistent sound from one or both channels:

Record player is connected to wrong input of amplifier, or MM/MC switch incorrectly set.

Needle or cantilever damaged.

Wrong r.p.m., drive belt overstretched or dirty, platter bearing without oil, dirty or damaged.

Maintenance and cleaning

Your record player requires little or no regular maintenance. Remove dust with the supplied antistatic cloth.

It is recommended to fit the needle cover before cleaning or maintenance is carried out to avoid damage.

If the player is not used over a long period of time the drive belt can be removed to prevent unequal stretching.

Always disconnect the record player from the mains power supply as a precaution before maintenance!

Service

Should you encounter a problem which you are not able to alleviate or identify despite the above information,

please contact your dealer for further advice. Only when the problem cannot be resolved there should the

unit be sent to the responsible distributor in your country.

Guarantee repairs will only be effected if the unit is returned correctly packaged. For this reason we recommend

keeping the original packaging.

Never return a record player without making sure that is it safely disassembled and correctly packaged in the

original packaging according to the supplied diagram. Please remove these parts and pack them separately:

feet, counterweight, platter, cartridge and belt. Fit the cartridge protection cap. Insert the transport lock for

the tonearm prior to carefully packaging the record player.

Warranty

The manufacturer accepts no responsibility for damage caused by not adhering to these instructions

for use and/or by transportation without the original packaging. Modification or change to any part

of the product by unauthorized persons release the manufacturer from any liability over and above

the lawful rights of the customer.

PRO-JECT is a Registered Trademark of H. Lichtenegger.

This guide was produced by: Audio Trade GmbH

The information was correct at the time of going to

press. The manufacturer reserves the right to make

changes to the technical specification without prior

notice as deemed necessary to uphold the ongoing

process of technical development.

This manual suits for next models

Table of contents

Other Pro-Ject Audio Systems Turntable manuals

Pro-Ject Audio Systems

Pro-Ject Audio Systems Debut Carbon RecordMaster HiRes User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems Essential II User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems RPM 5.1 User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems 6 PerspeX User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems Pro-Ject VC-S User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems RPM 9.2 User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems 1 Xpression III User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems VC-S Firmware update

Pro-Ject Audio Systems

Pro-Ject Audio Systems Pro-Ject Debut SE II User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems Primary User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems Pro-Ject RPM 5 SuperPack User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems Pro-Ject Debut III E User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems Pro-Ject RPM 5 User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems Pro-Ject VC-S User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems Essential User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems X1 User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems Debut Carbon Phono/USB User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems Remote Box S2 User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems SIGNATURE 10 User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems RPM 6.1 SB SuperPack User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems Pro-Ject 1 Xpression III Comfort User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems Pro-Ject 6 PerspeX SuperPack User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems X1 User manual

Pro-Ject Audio Systems

Pro-Ject Audio Systems Essential II/Phono USB User manual

Popular Turntable manuals by other brands

Gemini

Gemini CDT-05 MKII product manual

Rotel

Rotel RP-820 owner's manual

Shuman

Shuman MC-250BT user manual

Stanton

Stanton STR8-150 owner's manual

Audio Technica

Audio Technica AT-LPW40WN user manual

Crosley

Crosley McQueen CR7011-GY instruction manual

Reloop

Reloop SMP-1 Operation manual

auna

auna TT-Classic Plus instruction manual

COMO AUDIO

COMO AUDIO Turntable Analog user manual

Dual

Dual 1009 F owner's manual

REED

REED Muse3C user manual

AXIOMTEK

AXIOMTEK OPS883-H Series Quick installation guide

Pioneer

Pioneer PL-71 operating instructions

Vestax

Vestax PDX-a1 owner's manual

Denon

Denon DP-400 owner's manual

Dual

Dual 504 Service manual

Audio-Techica

Audio-Techica AT-LP60XBT user manual

Goldring

Goldring G99 instruction manual
