Pro-face GP4000 SERIES User manual

1/55

Easy! Smooth!

GP-477RE->GP4000 Series

Replacement Guidebook

4th Edition 2014.11

2/55

Preface

This manual introduces the procedures to replace a GP-477RE unit with a

GP-4501T/TW.

Model in use

Recommended Substitution

GP-477RE

GP-4501T*1

GP-4501TW*1

*1: A recommended substitution differs depending on a power supply type of the model you use.

When replacing AC power supply type

(GP477R-EG11);

When replacing DC power supply type

(GP477R-EG41-24VP);

Safety Information

HAZARD OF OPERATOR INJURY, OR UNINTENDED EQUIPMENT DAMAGE

Before operating any of these products, be sure to read all related manuals thoroughly.

Failure to follow these instructions can result in death, serious injury or unintended equipment

damage.

The power supply type is DC, but

the panel cutout dimensions

are different. The panel cutout

dimensions get larger.

We recommend GP-4501T

whose power supply type and the

panel cutout dimensions are

same as those of GP477R-EG11.

The power supply type and the

panel cutout dimensions are

same as those of

GP477R-EG41-24VP.

3/55

GP4000 Series Model Number

GP4000 series model number partly differs depending on a specification. Before

placing an order, please make sure of the model number.

GP-4200 series (3.5”)

GP-4300 series (5.7”)

GP-4400 series (7.5”/7.0”W)

GP-4500 series (10.4”)

GP-4600 series (12.1”)

RS-232C/422/485

RS-485 (isolation)

TFT color LCD

TFT color LCD (Wide Type)

Analog Resistive Film Touch Panel

Matrix Resistive Film Touch Panel

AC Type Power Supply

DC Type Power Supply

GP-4201TW/4301TW/4401WW/4501TW

Coated model

Coated model of GP-4301TW

4/55

Contents

PREFACE 2

SAFETY INFORMATION 2

HAZARD OF OPERATOR INJURY, OR UNINTENDED EQUIPMENT DAMAGE

GP4000 SERIES MODEL NUMBER 3

CONTENTS 4

CHAPTER 1 SPECIFICATION COMPARISON 7

1.1 SPECIFICATIONS OF GP-477RE AND GP-4501T 7

1.2 SPECIFICATIONS OF GP-477RE AND GP-4501TW 9

CHAPTER 2 COMPATIBILITY OF HARDWARE 11

2.1 LOCATIONS OF CONNECTOR 11

2.2 TOUCH PANEL SPECIFICATIONS 13

2.2.1 WHEN REPLACING GP-477RE WITH GP-4501T 13

2.2.2 WHEN REPLACING GP-477RE WITH GP-4501TW 13

2.3 DISPLAY COLORS 14

2.4 DISPLAY RESOLUTION 15

2.5 PANEL CUTOUT DIMENSIONS (ONLY WHEN REPLACING WITH GP-4501TW) 15

2.6 TRANSFER CABLE 15

2.7 INTERFACE 16

2.7.1 SERIAL INTERFACE 16

2.7.2 AUXILIARY I/O INTERFACE (AUX) 16

2.7.3 CF CARD INTERFACE (ONLY WHEN USING “MULTI UNIT”(GP077-MLTS11,

GP077-MLTE41)) 17

2.8 PERIPHERAL UNITS AND OPTION UNITS 17

5/55

2.8.1 BARCODE READER CONNECTION 17

2.8.2 PRINTER CONNECTION 18

2.8.3 EXPANSION UNIT 18

2.8.4 FRONT MAINTENANCE UNIT 18

2.8.5 ISOLATION UNIT 18

2.9 POWER CONNECTOR 18

2.9.1 AC POWER SUPPLY TYPE 18

2.9.2 DC POWER SUPPLY TYPE 19

2.10 BACKUP BATTERY 19

2.11 POWER CONSUMPTION 19

2.12 MATERIALS/COLORS OF THE BODY 20

2.13 OTHER NOTES 20

CHAPTER 3 REPLACEMENT PROCEDURE 21

3.1 WORK FLOW 21

3.2 PREPARATION 22

3.3 RECEIVE SCREEN DATA FROM GP-477RE 23

3.4 CONVERT SCREEN DATA WITH THE PROJECT CONVERTER 27

3.5 CHANGE THE DISPLAY UNIT TYPE 34

3.6 TRANSFER THE SCREEN DATA TO GP-4501T/TW 34

3.7 DIFFERENCES OF SOFTWARE 39

3.7.1 DIFFERENCES AFTER CONVERSION 39

CHAPTER 4 COMMUNICATION WITH DEVICE/PLC 41

4.1 DRIVERS 41

4.2 SHAPES OF COM PORTS 41

4.3 SIGNALS OF COM PORTS 42

4.3.1 SIGNALS OF COM1 42

4.3.2 SIGNALS OF COM2 44

4.4 MULTILINK CONNECTION 44

4.5 INTERNAL 2-PORT FEATURE FOR MITSUBISHI PLC 45

4.6 CABLE DIAGRAM AT THE TIME OF REPLACEMENT 46

4.6.1 WHEN USING A RS-232C CONNECTION CABLE 47

6/55

4.6.2 WHEN USING A RS-422 CONNECTION CABLE 49

CHAPTER 5 APPENDIX 53

5.1 CHANGING THE SETTING OF THE EXTERNAL MEDIA TO USE 53

7/55

Chapter 1 Specification Comparison

1.1 Specifications of GP-477RE and GP-4501T

GP-477RE

GP-4501T

Display Type

High-brightness EL display

UP! TFT color LCD

Display Colors,

Levels

Amber

UP!

65,536 colors (without blink)/

16,384 colors (with blink)

->See 2.3

Display Resolution

VGA (640×400 pixels)

VGA (640x480 pixels)

->See 2.4

Panel Cutout

Dimensions (mm)

259(W)x201(H)

External Dimensions

(mm)

274.0(W)x216(H)x56.5(D)

272.5(W)x214.5(H)x57(D)

Touch Panel Type

Resistive film (Matrix)

Resistive film (Analog/Matrix)

->See 2.2.1

Memory

Application

2MB

UP! 32MB

SRAM

96KB

UP! 320KB

Backup Battery

Secondary Battery

(Rechargeable Lithium

battery)

NEW!

Primary Battery

(Replaceable Lithium battery)

->See 2.10

Rated Input Voltage

AC 100 to 240V/ DC 24V

Serial

I/F

COM1

D-Sub 25 pin (socket)

RS-232C/422

D-Sub 9 pin (plug)

RS-232C

->See 2.7.1 and Chapter4

COM2

D-Sub 9 pin (plug)

RS-422/485

->See 2.7.1 and Chapter4

8/55

Ethernet I/F

NEW!

10BASE-T/100BASE-TX

SD Card I/F

NEW! ✔

USB

I/F

Type A

NEW! ✔

->See 2.6

Type mini B

Tool Connector I/F

✔

Printer I/F

Centronic-compliant

(parallel)

->See 2.8.2

Auxiliary I/O I/F

✔

- ->See 2.7.2

Expansion Unit I/F

✔

- ->See 2.8.3

9/55

1.2 Specifications of GP-477RE and GP-4501TW

GP-477RE

GP-4501TW

Display Type

High-brightness EL display

UP! TFT Color LCD

Display Colors, Levels

Amber

UP!

65,536 colors (without blink)/

16,384 colors (with blink)

->See 2.3

Display Resolution

VGA (640×400 pixels)

VGA (640×480 pixels)

->See 2.4

Panel Cutout

Dimensions (mm)

259(W)x201(H)

301.5(W)x227.5(H)

External Dimensions

(mm)

274.0(W)x216(H)x56.5(D)

315(W)x241(H)x56(D)

Touch Panel Type

Resistive film (Matrix)

NEW! Resistive film (Analog)

->See 2.2.2

Memory

Application

2MB

UP! 16MB

SRAM

96KB

UP! 128KB

Backup Battery

Secondary Battery

(Rechargeable Lithium

battery)

NEW!

Primary Battery

(Replaceable Lithium battery)

->See 2.10

Rated Input Voltage

AC 100 to 240V/ DC 24V

DC 24V ->See 2.9

Serial

I/F

COM1

D-Sub 25 pin (socket)

RS-232C/422

D-Sub 9 pin (plug)

RS-232C

-->See 2.7.1 and Chapter4

COM2

D-Sub 9 pin (plug)

RS-422/485

->See 2.7.1 and Chapter4

Ethernet I/F

NEW!

10BASE-T/100BASE-TX

10/55

SD Card I/F

NEW! ✔

USB

I/F

Type A

NEW! ✔

->See 2.6

Type mini B

Tool Connector I/F

✔

Printer I/F

Centronic-compliant

(parallel)

->See 2.8.2

Auxiliary I/O I/F

✔

- ->See 2.7.2

Expansion Unit I/F

✔

- ->See 2.8.3
