Prestigio MultiPad PMP5100 User manual

PMP5100 EN - 1

1. Packing List

1. Prestigio MultiPad 2. AC Adapter

3. Earphone 4. USB Cable

5. Quick Start Guide 6. Warranty Card

2. Device Overview

Web-camera

Video-conferences and other applications

Vol+\Vol- Adjust the volume level

Power\Charge

Indicator On\off status; charging indicator

Power Button Turn on/off the device

Earphone Jack Earphones connection

USB Port USB connection

Micro SD Card

Slot Insert SD card

Micro USB Port USB connection

Mini HDMI Output

Connecting an optional HDMI cable

Reset Button Reset the device to default settings

DC Port AC adapter connection

Quick Start Guide

Prestigio MultiPad

PMP5100

EN – 2PMP5100

Getting Started

3. Charging

Insert the AC connector to the DC port on the device and connect the

power adapter to the wall socket for charging.

Normally it takes approximately 3 hours to fully charge the device.

Operating the device while charging with the AC adapter may extend

the time of full charging.

4. Power on/Power off

Press and hold the Power button to turn on the device. It will

automatically enter the Home screen after the start-up screen.

Press the Power Button once to enter sleep mode and press it again

to awake the device.

Press and hold the Power Button, and then tap on Power

off/Standby to power off the device or to enter sleep mode.

5. Resetting device to default settings

Press and hold the Reset button for a few seconds to reset the

device’s settings to default ones. All user settings will be lost

6. Startup wizard

When using the device for the first time (or after resetting all user’s

personalized settings) the device will automatically launch the

Startup Wizard.

The Startup wizard interface will offer to choose the system

language from the language list and the Time Zone.

During the Startup Wizard the device’s accelerometer will be

calibrated. To perform the calibration, please, follow the on-screen

instructions.

Quick Start Guide

Prestigio MultiPad

PMP5100

PMP5100 EN - 3

Main functions

7. Main menu

After the Startup Wizard the device will enter the Home screen,

containing installed and default applications. The basic applications are

detailed as follows.

By pressing the Guide icon the device will playback an

introductions video, which guides through its major

functions, the Prestigio graphic user interface and installed

applications useful in daily life, in the office and for games.

In the Gallery application the images can be viewed as a

photo wall, one-by-one, or as a running slideshow. Drag the

finger horizontally to jump from one image to another.

The Video application allows to playback AVI, MP4, MKV,

MOV, WMV, MPG, PS, TS, VOB, FLV, RM, RMVB, ASF and 3GP

file formats.

Hint:

Video playback can be stopped anytime and then recovered

by tapping on the “+” symbol, on the right of the file name.

The Browser application allows surfing the Internet using

the Android default browser.

Note:

For Internet connection, please, see 9. Connecting to

WiFi.

Hint: The Browser application can work with multiple pages

open at once.

The email application supports POP or IMAP e-mail

accounts.

Quick Start Guide

Prestigio MultiPad

PMP5100

EN – 4PMP5100

8. Shortcuts

On the Home screen the following shortcuts are available:

Back - returns to the previous screen.

Menu - offers menu options according to the current screen.

Home – press once: return to the Home screen. Press and

hold: jump to one of the recent applications.

Search - allows to search for an item on the device or in

Internet.

9. Connecting to WiFi

In the Home menu press the Settings icon to access the list of

options. Select Wireless & networks.

If the WiFi is off, tap on the Wi-Fi line to turn it on. Then select the

Wi-Fi settings.

The device will scan for available WiFi networks and display them at

the bottom of the screen.

Tap on the network you want to connect to. Then tap inside the

Wireless password field to make the virtual keyboard appear. Enter

the required network information, tap on Done, and then tap on

Connect.

Your device will now attempt to establish a connection to the WiFi

access point with the network parameters you entered.

Quick Start Guide

Prestigio MultiPad

PMP5100

PMP5100 EN - 5

Transferring content

10. Transferring content from PC

Connect the device to the PC with the USB cable provided. The device

will automatically enter the USB screen. Please, follow the on-screen

instructions to enable USB data transfer.

The device will be automatically recognized by the PC. Please,

transfer the necessary content using Windows Explorer.

11. Downloading content from AppsLib

You can download free or paid applications directly from your device

using the AppsLib application marketplace.

Before entering the AppsLib make sure the WiFi connection is

established.

With Internet connection established, press the icon on the

Home screen.

Upon entering the AppsLib you can view the list of free and

purchasable applications as well as install the preferred applications.

After pressing the Menu tab the device will offer the following

options:

My apps View the list of installed applications. Update or

uninstall apps.

Settings Change AppsLib account settings, Clear cache and

Clear search cache.

About Access the AppsLib End User Licence Agreement.

Exit Exit the program.

Quick Start Guide

Prestigio MultiPad

PMP5100

Quick Start Guide

Prestigio MultiPad

PMP5100

EN – 6PMP5100

Technical Specifications

Processor RockChip 2818

OS ANDROID™ 2.1 “Eclair”

Display 10.1” TFT LCD, Touch screen with virtual keyboard

Resolution High resolution, 1024 x 600 pixels, 16 million colors

Supported File

Formats

Video:

avi, .mp4, .mkv, .mov, .flv

Audio: MP3, WAV, APE, OGG, FLAC

Picture: JPEG, BMP, GIF, PNG

Storage capacity From 4 GB flash memory, Micro SDHC Slot

Interfaces Micro USB 2.0 Slave, USB Host, Micro SD

Communications WiFi (802.11 b/g)

Battery Lithium Polymer battery

Dimensions 272 x 152.3 x 13.5 mm (L x W x H)

Weight 570 g

Disclaimer

As the Prestigio products are constantly updated and improved, your

device’s software may have a slightly different appearance or modified

functionality than presented in this Quick Start Guide.

Quick Start Guide

Prestigio MultiPad

PMP5100
