Prestigio Multipad pmp5080b User manual

PMP5080 EN - 1

USER MANUAL

Prestigio MultiPad

PMP5080

1. Packing List

1. Prestigio MultiPad

2. AC Adapter

3. Carrying Case

4. USB Cable

5. Quick Start Guide

6. Warranty Card

7. Legal and Safety Notices

2. Device Overview

Vol +\ Vol - Button

Adjust the volume level

Power

Turn on/off the device; Suspend/Activate

the device

Back

Return to the previous page

Display menu options

EN –2 PMP5080

USER MANUAL

Prestigio MultiPad

PMP5080

Home

Touch the home button to return to the

home screen. Touch and hold the home

button to display recently opened items.

Go to search dialog directly

Camera

Take photos

Reset

Reset the device if it fails to operate

correctly.

Micro SD Card

Slot

Insert Micro SD card.

DC Port

AC adapter connection.

Mini-HDMI video

output

HDMI cable connection.

Built-in Microphone

Record sounds.

USB port

USB connection.

Earphone Jack

Earphones connection.

Getting Started

3. Charging

Insert the AC connector to the DC port on the device and connect the

power adapter to the wall socket for charging.

Normally it takes approximately 4 hours to fully charge the device.

Operating the device while charging with the AC adapter may extend

the time of full charging.

4. Power on/Power off

Press and hold the Power Button to turn on the device. It will

automatically enter the Home screen after the several start-up steps.

Press the Power Button once to enter sleep mode and press it again

to awake the device.

Press and hold the Power Button, and then tap on Power

off/Standby to power off the device.

5．Inserting a Memory Card

The device supports micro SD/SDHC cards.

To insert a Micro SD card, place the card connector towards the front

PMP5080 EN - 3

USER MANUAL

Prestigio MultiPad

PMP5080

side of the device and the printing side of the card towards the rear

side of the device.

To remove the micro SD card, gently press the edge of the card to

release the safety lock and pull the card out of the slot.

To access the files on the memory card, select File icon and tap on SD

Card.

Notice:

When you are reading the file from micro SD card, please don’t

remove it, or the device could fail to operate correctly.

Home screen

6. Home screen bars

Your device has the capacitive sensitive screen. It is operated by

touching the screen surface with your finger.

Status bar

The status bar displays the time, battery status, WiFi, alarm, news status

and various notifications.

Status bar

Widgets

Applications drawer

Page scroll

Buttons

panel

EN –4 PMP5080

USER MANUAL

Prestigio MultiPad

PMP5080

RSS Reader updates

Notification of the RSS Reader, informing that the

news widget has updated the news feeds.

Time and WiFi area

Displays the current time and the alarm symbol,

when Alarm is activated.

Connected to a WiFi network.

Battery status

Displays the battery power or charging progress.

Battery is full

Battery is low and must be recharged

Battery is extremely low and must be

recharged immediately

Battery is charging

Buttons panel

Internet Explorer

button

Touch to open the Internet Explorer. By default

the device will attempt Google web search.

For more info regarding Internet Explorer

function, please, refer to section 15. Browsing

the web.

Applications

drawer

Open the list of all applications, folders and

shortcuts on the device.

EBookReader

Direct access to the eBook Reader application.

For more info regarding eBook Reader

PMP5080 EN - 5

USER MANUAL

Prestigio MultiPad

PMP5080

application, please, refer to section 10. eBook

Reader.

Page scroll dots

Touch to move to the desired room of the home

screen.

Widgets

Prestigio home screen contains news, weather forecast and clock

widgets, providing you with up-to-date information.

Weather widget

This widget displays temperature and cloudiness for a selected city.

To open the options, touch the weather widget. The following screen will

appear, showing the current temperature, cloudiness, humidity and wind

for the selected city, as well as cloudiness for the nearest 4 days:

To add a new city to the widget, touch Add City and enter the city

name. As you type the device will suggest most probable city names.

Choose the desired city and touch Add.

If you have selected more than one city, you can choose the one that

will appear on the home screen widget simply by pressing or

EN –6 PMP5080

USER MANUAL

Prestigio MultiPad

PMP5080

To delete a city from the widget, touch Delete. You will see the list of

all cities in the widget. Choose the desired city by touching it once,

and then touch OK.

You can update the weather forecast for the selected city by touching

Update Weather.

Note:

To obtain weather forecast your device must be connected to WIFI. For

instructions on how to establish a WIFI connection, please, refer to

section 14. Connecting to WIFI.

News widget

This widget displays news from selected RSS-feeds. To open the list of

available feeds and options, touch the RSS feed header. The following

screen will appear:

To add a news feed, touch Add feed and enter the search keyword or

a URL-address.

You can update the news feeds by touching Update feed.

To change the update settings, touch Preferences.

To open the list of news and options, touch the news panel. The following

PMP5080 EN - 7

USER MANUAL

Prestigio MultiPad

PMP5080

screen will appear:

Touch Update Feeds to update all news.

To read more info about certain news feed touch it once. To read the

news feed completely touch it and hold. The device will open the

source page in Internet.

To sort the news by newest or by oldest touch the Menu button

Sort by oldest (newest) first.

Note:

To obtain news feeds your device must be connected to WIFI. For

instructions on how to establish a WIFI connection, please, refer to

section 14. Connecting to WIFI.

Clock widget

The clock widget displays current time and date.

By touching the clock widget you can access several functions: Clock,

World clock, Alarm, Stopwatch and Timer.

The Clock tab displays current time and date.

The World clock option allows you to display current time in different

locations.

To add a location touch Add Timezone and enter the city name. As

you type the device will suggest most probable city names. Choose

EN –8 PMP5080

USER MANUAL

Prestigio MultiPad

PMP5080

the desired city and touch Add.

To delete a location from the widget, touch Delete. You will see the

list of all cities in the widget. Choose the desired city by touching it

once, and then touch OK.

In the Alarm tab you can set different alarms for any time, day and

date. To add an alarm touch Add Alarm, enter the necessary

parameters and touch Done. To delete an alarm from the widget,

touch Delete alarm. To change alarm settings, touch Settings.

The Stopwatch tab has 2 options: Start/Stop and Reset.

In the Timer tab enter the desired time by pressing the arrows.

7. Prestigio home screen

Prestigio home screen allows to adjust it according to the user’s

preferences.

Prestigio home screen is made up of five individual screens. Each

room fits the physical display border and can be set to have its own

shortcuts and widgets. You can move around the home screen in two

ways:

1. Flick the Home screen horizontally until the desired room is

displayed.

2. Touch the dots at the right top and bottom of the screen to

move to the desired room of the home screen.

All the space of the side screens can be used for installing applications,

widgets and shortcuts.

The home screen shortcuts are either direct shortcuts (by touching

them you are directed straight to the application), or have

second-level menus with a number of applications. You can add or

remove any applications.

For optimal viewing experience, the screen orientation changes

automatically to portrait or landscape depending on how you hold the

device.

Downloaded applications may not support automatic screen

orientation to portrait or landscape.

To modify the default behavior, open the orientation settings by

touching Menu button Settings DisplayAuto-rotate

screen. Check the box to allow automatic screen orientation or

PMP5080 EN - 9

USER MANUAL

Prestigio MultiPad

PMP5080

uncheck it to block it.

8. Customizing the home screen

To move an item to the home screen:

Touch the button, choose the desired item, touch it and hold,

until the home screen appears. Choose the desired shortcut on the

home screen (or a desired location on the side screen), and release

the item, or

Touch the Menu button, then Add, and choose the item you wish to

add from the list.

To create an item at the home screen:

Touch and hold on free space at the home screen. A pop-up menu will

appear. Select the desired item to add among the available list.

To change wallpapers:

Touch the Menu button, then Wallpaper, and choose the wallpaper

you wish to add from the list; or

Touch Menu button, then AddWallpaper, and choose the

wallpaper you wish to add from the list.

To move an item:

Touch and hold the item you want to reposition until it magnifies and

becomes movable.

With your finger remaining in contact with the item on the screen,

drag the item to another location on the screen.

Release the item in the desired location.

To remove an item:

Touch and hold an item such as a widget, shortcut, or folder that you

want to remove, until it magnifies and becomes movable.

Drag the item onto the top of the delete icon , and when the item

becomes red release it.

EN –10 PMP5080

USER MANUAL

Prestigio MultiPad

PMP5080

9. Pop-up menu

Touch the Menu button to open or close the pop-up menu that lists

available options for the current application, or actions that you can

perform on the current screen.

To select an option or item on the pop-up menu:

Touch the Menu button to open the pop-up menu.

Touch the desired item on the pop-up menu.

If the menu has a scroll bar on the right side, you can flick the menu

until the desired item is found.

Touch the Menu button again to close the pop-up menu.

10. eBook Reader application

Touch to open the eBook reader application.

A list of available books (My library) will appear on the screen.

Press History to view the last opened books.

Press to open the pop-up search window.

To search for an item press the search field once. The digital keyboard

will be displayed. Type the desired text and press the OK button to

perform the search.

Other manuals for multipad pmp5080b

Table of contents

Other Prestigio Tablet manuals

Prestigio

Prestigio MultiPad PMP3084B Use and care manual

Prestigio

Prestigio MultiPad PMT3047 3G User manual

Prestigio

Prestigio MultiPad PMP3170B User manual

Prestigio

Prestigio MultiPad PMP5588C DUO User manual

Prestigio

Prestigio PMP7170B3G DUO Operating manual

Prestigio

Prestigio MultiPad PMP5297C QUAD User manual

Prestigio

Prestigio MultiPad 2 PRO DUO 8.0 3G User manual

Prestigio

Prestigio MultiPad PMP5785C3G QUAD User manual

Prestigio

Prestigio MultiPad Visconte Quad PMP880TD User manual

Prestigio

Prestigio MULTIPAD PRO QUAD 8.0 3G PMP7380D3G_QUAD User manual

Prestigio

Prestigio PMP7079D Operating manual

Prestigio

Prestigio MultiPad PMT3017 User manual

Prestigio

Prestigio NODE A8 User manual

Prestigio

Prestigio PMP7079D User manual

Prestigio

Prestigio MultiPad PMP3084B User manual

Prestigio

Prestigio GRACE 3157 3G User manual

Prestigio

Prestigio MultiPad PMP7070C User manual

Prestigio

Prestigio Multipad Wize 3057 User manual

Prestigio

Prestigio PMP7170B3GCE Quick start guide

Prestigio

Prestigio PMP3370B User manual

Prestigio

Prestigio MultiPad 7.0 Ultra User manual

Prestigio

Prestigio WIZE 3618 4G User manual

Prestigio

Prestigio MultiPad PMP5597D DUO User manual

Prestigio

Prestigio MULTIPAD WIZE 3027 User manual

Popular Tablet manuals by other brands

Laser

Laser MID-1060 Quick operation guide

MUNBYN

MUNBYN IRT09J Easy setup guide

Motorola

Motorola MC3090R - Win CE 5.0 Professional 520 MHz quick start guide

Dell

Dell Latitude ST Setup and features information

Lenovo

Lenovo IdeaTab S6000L Hardware Maintenance Manual

Venturer

Venturer WT9L11 quick start guide

EDUGEAR

EDUGEAR UnoBook user guide

Philips

Philips PI3210G/58 user manual

ADLINK Technology

ADLINK Technology IMT-BT user manual

TwinMOS

TwinMOS TwinTAB-T102D1 user guide

Archos

Archos 9.7 xenon manual

Getac

Getac E100 user manual

HANNspree

HANNspree HANNspad SN70T3 quick start guide

Philips

Philips PI3105W2/55 user manual

LG LG-V935 user guide

Zeki

Zeki TBDB763B user guide

Ricoh

Ricoh eQuill user guide

DT Research

DT Research DT365CT Basic operation guide

Prestigio multipad pmp5080b User manual

Popular Tablet manuals by other brands
