Prestigio MultiPhone 3404 DUO User manual
Prestigio MultiPhone 3404 DUO has a two-year warranty. You may find detailed
warranty information at: www.prestigio.com/support/warranty-terms.
© Copyright 2014 Prestigio. All rights reserved.
MultiPhone 3404 DUO
www.prestigio.com
Unboxing
Inside your package
• Prestigio
MultiPhone
• USB cable
• Battery
• Adapter
• Quick start guide
• Legal & safety
notices
• Warranty card
Your phone at a glance
1
2
3
4
5
6
7
8
9
10
1. Earpiece
2. Microphone
3. Micro USB port
4. Front camera
5. Volume button
6. Power button
7. Speaker
8. Earphone jack
9. Rear camera
10. Flash
Inside your package
Your phone at a glance
Buttons
www.prestigio.com
Inside your package
Your phone at a glance
Buttons
Do not cover the antenna area with
your hands or other objects. This may
cause connectivity problems or drain the
battery.
Please read the "Legal and safety
notices" in your package before use.
Buttons
The back, start and search keys help you navigate
your phone.
• Tap to open a list of options available on the
current screen. To open the list of recent apps,
tap and hold .
• Tap to return to the home screen.
• Tap to return to the previous screen.
www.prestigio.com
Getting started
Installation
Power on your phone
Home screens
List menu
Take out the battery.
2
Insert the SIM card.
Nano SIM
Standard SIM
Micro SIM
SIM2
SIM1
3
Congratulations on your purchase and welcome to
Prestigio. To get the most from your product and
enjoy all that Prestigio has to offer, please visit:
www.prestigio.com/catalogue/MultiPhones
For more details about your product, please visit:
www.prestigio.com/support
Installation
Follow the steps below to prepare your phone for
using. Remember to turn off your mobile phone
before removing the rear panel.
Remove the rear panel.
1
www.prestigio.com
Installation
Power on your phone
Home screens
List menu
Put the rear panel back.
6
• The use of incompatible SIM cards,
manually cut SIM cards, or SIM card
adapters may damage the cards or
the device, and it may corrupt the
data stored on the cards.
• Scratching or bending of the SIM
cards may result in the loss of
contacts and information, so be
careful when handling, inserting, or
removing the cards.
Frequent writing and erasing of data
shortens the lifespan of memory cards.
Insert a memory card.
4
Insert the battery into the
battery compartment.
5
www.prestigio.com
Installation
Power on your phone
Home screens
List menu
When turning on the device for the first time, follow
the on-screen instructions to set up your device.
To turn off your phone, press and hold
the power key, and and then tap Power
off on the pop-up screen.
1
2
Dual SIM standby
The device supports two SIM cards for
voice calls and data connection. During
a voice call or data transfer via one
SIM card, the other SIM card becomes
inactive (not registered with your mobile
network operator). This means that you
cannot receive incoming calls or use
data connection via the inactive SIM
card. When the call or data transfer
ends, both SIM cards will become
active and show on the list of registered
networks.
Power on your phone
Press and hold the power
button for a few seconds.
7
www.prestigio.com
Installation
Power on your phone
Home screens
List menu
Personalise your wallpaper
Pick your favourite photo as your Home wallpaper.
Choose from the available wallpapers, or use any
photo you have taken with the camera.
1. On the home screen, tap > Wallpaper.
2. Select an image and tap Set wallpaper.
Add an app icon to home screen
1. On the home screen, tap to open the list
menu.
2. Tap and hold an application icon.
3. Drag it into a panel preview.
Remove an item on home screen
1. Tap and hold an item to remove.
2. Drag the item to the Remove option.
3. When the Remove option turns red, release
the item.
Home screens
Your home screen is the starting point to access
all of your phone’s features. The home screen can
have multiple panels. To view other panels, swipe
left or right.
Tap to return to the home screen.
Your phone’s home screen consists of the following:
Status bar
Applications and
widgets
Shortcut
www.prestigio.com
Installation
Power on your phone
Home screens
List menu
List menu
All your apps' icons can be found on the list menu.
On the home screen, tap to open the list menu.
Tap or to return to the home screen. Your
phone’s list menu consists of the following:
Applications
www.prestigio.com
Basics
Finger tips
Charge the battery
Connect to your PC
Rotate the screen
Lock and unlock the screen
Use the notications panel
Enter text
System update
Status icons
Swipe
Slide or scroll
• Quickly swipe your finger vertically or
horizontally across the screen to go to other
home pages, scroll through documents, and
more.
• Slide your finger vertically across the screen
to open drop-down menu. Drag up or down to
scroll.
Finger tips
Only use your fingers to use the touch screen.
Tap
Tap and hold
• To open an application, to select a menu item,
to press an on-screen button, or to enter a
character using the on-screen keyboard, tap it
with a finger.
• Tap and hold an item for more than 2 seconds
to access available options.
www.prestigio.com
Finger tips
Charge the battery
Connect to your PC
Rotate the screen
Lock and unlock the screen
Use the notications panel
Enter text
System update
Status icons
Flick
• Flick left or right on the home screen or the
applications screen to see another panel. Flick
up or down to scroll through a web page or a
list, such as contacts.
Zoom in
Zoom out
• Spread two fingers apart on a web page, map,
or image to zoom in a part.
• Pinch two fingers together on a web page, map,
or image to zoom out a part.
