Polygroup TG90P4474P00 User manual

1. Choose a level surface near a wall outlet.

2. Assemble the tree stand (See Fig. A).

MODEL #: TG90P4474P00 SKU: 094-213

3. Identify all tree sections (See Fig. B) by the sticker on them, and start assembling from bottom to top.

4. Open the protective cap of pole, and insert the pole into the stand. Allow all branches fall down into place. Check to make sure

that all wires are free from branch hinges.

5. Shape the tree section one branch at a time. Start with the tips closest to the pole and move outwards. Fan all the tips out in

alternating directions, and slightly upsweep them for a natural look (See Fig. C).

Top view Side view

Fig. C

TREE ASSEMBLY INSTRUCTIONS

Thank you for purchasing your new tree from Polygroup®!

This tree comes with Quick Set® technology - allowing you to set up your tree and light it up in minutes!

Carefully follow the instructions below on how to set up your tree quickly and easily.

Fig. B - Tree and Lights Assembly *Electrical Rating For The Tree

(For Indoor Use Only)

Input: 120V, 60Hz, 0.83A

Output: 24V DC 2A

Tree Top

Section 2

Section 1

Plug Adapter

Into Wall

Outlet

Insert Green

Label Extension

Cord into Adapter

Align both arrows

in a straight line

before sliding

down to insert

Open the

cap cover

Do Not Tamper

Internal Parts

DO NOT RETURN TO STORE. PLEASE VISIT US AT:

www.polygroupstore.com OR 1-888-919-0070

NEED HELP?

Fig. A - Tree Stand Assembly

Unfold the legs and lay the

stand in a flat area.Then slide

the locking disc downward and

snap into place.

This tree includes sets of hinge pins & washers, and spare bulbs.

If extra parts are needed, please contact our customer service center.

SPARE PARTS

STORAGE INSTRUCTIONS

TROUBLESHOOTING TIPS

1. Unplug from power source, and detach plug from adapter. Remove all ornaments and decorations.

2. Disassemble the tree from top to bottom. Gently lift pole straight up to remove from the lower

section, and fold all branches toward the pole.

3. Close the protective caps on the poles to avoid damaging the internal parts (See Fig. D).

4. Place the disassembled tree into the shipping box and tape it shut.

5. Store your tree in a cool, dry place away from sunlight.Exposure to excessive heat or humidity

may damage your tree.

If Tree Does Not Illuminate / Some Bulbs Do Not Light or Flicker

1. Please check to make sure that all plugs are properly connected and adapter is plugged into the wall outlet.

2.Turn the poles gently to make sure pole to pole sections are connected properly

3. Check for loose connection between light string plugs and extension cords.

4. Check for loose, broken or missing bulbs, and replace as needed (See LAMP REPLACEMENT).

1. Place the branch into the hinge bracket (See Fig. E).

2. Insert a new hinge pin all through the holes of bracket,

and secure with a washer (See Fig. E - close up).

Loose Hinge Pin

Fig. E

6. Repeat Step 4 and 5 for the upper tree section(s) until tree top is installed and shaped.

7. Connect plug with adapter, and plug it in to the wall outlet as indicated in Fig. B.

8. Step back and view your tree. Shift branches to fill any gaps.Your Christmas tree is now ready to be decorated.

For any questions, assistance, or missing parts, Do Not Return To Place Of Purchase. Please contact us at 1-888-919-0070

or visit our website at www.polygroupstore.com.One of our customer service representatives will be happy to assist you.

CUSTOMER SERVICE FOR CHRISTMAS TREES

Tree ID#:

Tree UPC#:

Store Purchased:

Specify Problem:

Customer Name:

Address:(No P.O. Boxes)

City & State:

Zip Code:

Day Phone:

Date Purchased:

TREE ID# IS LOCATED ON END PANEL OF BOX. TREE ID# IS REQUIRED WHEN REQUESTING REPLACEMENT PARTS.

CAUTION:

To reduce the risk of fire and electric shock:

a) Use only the power supply that was provided with this product.Using a different adapter will damage the lights and may cause

fire, or electrical shock hazards.

b) Do not install on trees having needles, leaves or branch covering of metal or materials which look like metal.

c) Do not mount or support strings in a manner that can cut or damage wire insulation.

Lamp Replacement

Step 1.

Unplug from power source, by pulling out the adapter itself - do not pull on the power cord.

Step 2. Lift up the lamp lock tab, and

pull the bulb and its plastic base

straight out from the lampholder.

(For reference only)

Step 3. Replace with a new

spare LED lamp (included).

Fig. D

REMOTE CONTROL INSTRUCTIONS

Multi Color Steady Glow

Color Wheel

Faster Light Effect For

Preset Motion

Slower Light Effect For

Preset Motion

Previous Preset Motion Effect

Tap or to select from the

10 preset motion effects:

• Warm White Twinkle

• Color Twinkle

• Fading

• Multi Ball

• Color Switching

• Collision

• Wave

• Waterfall

• Rainbow Shower

• Rainbow

Customizable color selection

1. Slide open the battery cover.

2. Replace with a new CR2032 button cell battery with

correct polarities (+/-) as indicated.

3. Slide the battery cover closed.

In case the light motion effects keep switching to the next one every 30 seconds

and continues to cycle, this means the Demo mode is on.

To cancel the Demo mode, simply press and hold the (Brightness Down) button

and the (Slower Speed) button together for 10 seconds.

Battery Replacement

NOTE:

ON/OFF

Warm White Steady Glow

Brightness Up

Next Preset Motion Effect

Brightness Down

Remove insulation

tab before use.

Battery Cover

WARNING

1. Small parts, keep away from children.

2. Do not expose the product to moisture.

3. Remove batteries when not used for an extended period of time,

or when depleted.

4. Dispose of used batteries properly, and local laws and

regulations regarding the disposal of hazardous waste.

5. Use only CR2032 batteries for the remote controller.

6. Clean the battery contact surfaces gently prior to battery installation.

7. Do not dispose of batteries in fire. Batteries may explode or leak.

8. This product is powered by a lithium battery. Due to their small size,

lithium batteries can easily be swallowed by children. Ingestion of

such batteries has been known to cause death.

9. This is a lithium battery which if swallowed has been known to cause death.

WARNING: This product may potentially trigger seizures for people with photosensitive epilepsy when using the motion

effect light modes.

Tap to display all lights in

multi color steady glow

Tap to display all lights in

warm white steady glow
