Plantronics Discovery 975 User manual
Ingeniously Simple
Plantronics Discovery®975
User Guide
ii
Contents
Welcome
Thank you for purchasing the Plantronics
Discovery®975 earpiece. This guide
contains instructions for setting up and using
your new earpiece.
Before using this product, please refer
to the For Your Safety guide for important
product safety and charging information.
Getting Assistance
The Plantronics Technical Assistance Center
is ready to assist you. Visit www.plantronics.
com/support or call 1-866-363-BLUE
(2583).
Registering Your Product
Visit www.plantronics.com/
productregistration to register your product
online so we can provide you with the best
service and technical support.
iii
en
Contents
Earpiece Features and Accessories...........................................iv
Charging Your Earpiece.............................................................. 2
Recharging Your Charging Case ................................................ 6
Pairing Your Earpiece ................................................................. 7
Using More Than One Bluetooth Phone .................................... 8
Adjusting the Fit ......................................................................... 9
Earpiece Controls and Indicators............................................. 10
Hands-Free Features................................................................ 13
Range ....................................................................................... 13
Troubleshooting........................................................................ 14
Product Specifications ............................................................. 15
Limited Warranty ...................................................................... 16
iv
Earpiece Features and Accessories
Volume Control Button:
Volume up/down
Mute on/off
Online indicator on/off
Eartip
Vents and screens
for microphones
Charging Jack
Call Control Button:
Call answer/end/
reject/redial
Power on/off
Pairing to phone
Transfer call
to/from phone
Reconnect when
back in range
1
en
To order accessories, please contact your Plantronics supplier or go to www.plantronics.com.
Mobile Charging Kit:
Vehicle Power Charger and
USB Charger
#81291-01
USB Lanyard
#74948-01
Earpiece Features and Accessories
2
Your new earpiece performs best when fully
charged. While your earpiece is charging, the
indicator light slowly flashes red. When your
earpiece is fully charged, the indicator light turns off.
This applies to all charging options.
Never charge the battery where the temperature
may fall below 0°C (32°F) or rise above 40°C
(104°F). Do not use your earpiece while it is
connected to the charger.
Option A: Using the AC Charger
1 Plug the AC charger into a power outlet.
2 Connect the AC charger to the charging
jack on the earpiece.
CHARGING TIME
1.5 hours ...... Full charge using
AC or case
30 minutes.... Minimum charge
before first use
Charging Your Earpiece
1
2
Option A
3
en
Option B: Using the Charging Case
1 Open the cover of the case. Align the
charging jack on the earpiece with the
micro USB connection in the case.
2 Gently push the earpiece onto the micro
USB connection until you feel it click into
place.
3 Once charged, gently press the ejection
button with your thumb to release the
earpiece.
Charging Your Earpiece
1
2
Insert
Eject
Option B
4
Charging Your Earpiece
Checking the Battery Level of Your Earpiece
Option A: The LCD display on the charging
case will indicate battery level of the earpiece
when earpiece is inserted into case.
NOTE The Bluetooth icon on the case indicates
the earpiece is connected to your phone. You can
receive calls when charging.
Option B: With the earpiece powered on,
simultaneously press and hold the call control
button and the volume button for about 2
seconds. The indicator light flashes red to show
the charge level.
Volume Button
Call Control Button
Option B
Option A
5
en
OPTION B
Red Flashes Battery Level
SMore than 2/3 full
S S 1/3 to 2/3 full
S S S Less than 1/3 full
OPTION A
Bars Battery Level
3 Full battery
2 1/3 to 2/3 full
1 Less than 1/3 full
Charging Your Earpiece
LOW BATTERY WARNINGS
Battery Level Tone Voice Prompt
30 minutes of
talk time remaining
(this alert only
occurs during
an active call)
Double high
tone every
15 minutes
“Battery Low”
repeats every
30 minutes
10 minutes
of talk time
remaining
Triple high
tone every
30 seconds
“Recharge
Battery” repeats
every 3 minutes
Automatic Battery Status Alerts
When the battery charge is very low, a tone and
voice prompt in English will automatically occur.
6
Recharging Your Charging Case
Recharging the Battery Inside the Case
The charging case provides two full charges to
your earpiece before the battery within the case
requires recharging.
1 To check the battery status of the case,
refer to the LCD display.
If the battery icon is flashing, or the display is
blank, you have to recharge the case before
you can use it to charge your earpiece.
2 Plug the AC charger to power source
before connecting to the charging jack on
the side of the case.
While the case is recharging, the LCD battery
icon (above the case image) flashes to indicate
charge level.
CHARGING TIME
1.5 hours..... Full charge
using AC
2
1
