Planet WGSW-48040HP User manual

48-Port 10/100/1000Mbps 802.3at PoE

Managed Switch with 4 Shared SFP Ports

WGSW-48040HP

Quick Installation Guide

Table of Contents

1. Package Contents ....................................................................................... 3

2. Requirements ............................................................................................. 4

3. Terminal Setup ........................................................................................... 5

4. Logon to the Console .................................................................................. 6

5. ConguringIPAddress................................................................................ 7

6. Starting Web Management .........................................................................10

7. SavingConguration..................................................................................13

8. RecoveringBacktoDefaultConguration.....................................................14

9. Customer Support .....................................................................................15

1. Package Contents

ThankyouforpurchasingPLANET48-Port10/100/1000Mbps802.3atPoEManaged

Switch with 4 shared SFP ports, WGSW-48040HP. “Managed Switch” mentioned

inthisGuidereferstotheWGSW-48040HP.

Open the box of the Managed Switch and carefully unpack it. The box should

contain the following items:

TheWGSW-48040HPManagedSwitchx1l

User’s Manual CD x 1l

QuickInstallationGuidex1l

RJ-45toRS232Cablex1l

RubberFeetx4l

TwoRack-mountingBracketswithAttachmentScrewsx1l

PowerCordx1l

SFPDustCapx4l

If any item is found missing or damaged, please contact your local reseller for

replacement.

2. Requirements

Workstations running Windows XP/2003/Vista/7/8/2008, MAC OS X or later,l

Linux,UNIX,orotherplatformsarecompatiblewithTCP/IPprotocols.

WorkstationsareinstalledwithEthernetNIC(NetworkInterfaceCard)l

Serial Port Connectionl(Terminal)

The above Workstations come with COM Port (DB9) or USB-to-RS-232

converter.

The above Workstations have been installed with terminal emulator, such as

HyperTerminalincludedinWindowsXP/2003.

Serial cable -- one end is attached to the RS-232 serial port, while the other

endtotheconsoleportoftheManagedSwitch.

Ethernet Port Connectionl

Networkcables--Usestandardnetwork(UTP)cableswithRJ-45connectors.

The above PC is installed with Web Browser and JAVA runtime environment

plug-in.

Note

It is recommended to use Internet Explore 8.0 or above to access

the Managed Switch. If the Web interface of the Managed Switch

is not accessible, please turn off the anti-virus software or firewall

andthentryitagain.

3. Terminal Setup

Tocongurethesystem,connectaserialcabletoaCOM port on a PC or notebook

computerandtoRJ-45typeofserial(console)portoftheManagedSwitch.

PC / Workstation with

Terminal Emulation Software

RJ-45 Type Serial Port

115200,N,8,1

RJ-45 DB9 RS-232 Cable

Managed Switch

Serial Port

Console

115200,N,8,1

Figure 3-1 Managed Switch Console Connectivity

A terminal program is required to make the software connection to the Managed

Switch. Windows’ Hyper Terminal program may be a good choice. The Hyper

TerminalcanbeaccessedfromtheStart menu.

1. Click START,thenPrograms,AccessoriesandthenHyper Terminal.

2.When the following screen appears, make sure that the COM port should be

conguredas:

Baud :115200

Data bits : 8

Parity :None

Stop bits : 1

Flowcontrol :None

Figure 3-2 Hyper Terminal COM Port Conguration

4. Logon to the Console

Once the terminal is connected to the device, power on the Managed Switch, and

the terminal will display “running testing procedures”. Then, the following message

asks to log-in user name and password. The factory default user name and

passwordareshownasfollowsandtheloginscreeninFigure4-1appears.

Username: admin

Password:admin

Figure 4-1: Managed Switch Console Login Screen

Theuser cannow entercommandstomanage the ManagedSwitch.Foradetailed

descriptionofthecommands,pleaserefertothefollowingchapters.

Note

1. For security reason, please change and memorize the new pass-

wordafterthisfirstsetup.

2.Only accept command in lowercase letter under console inter-

face.

5.ConguringIPAddress

TheManagedSwitchisshippedwithdefaultIPaddressshownbelow.

IPAddress:192.168.0.100

Subnet Mask: 255.255.255.0

Tocheckthe currentIPaddressormodify a newIPaddressforthe Switch,please

usetheproceduresasfollows:

Show the current IP Address

1.Atthe“#”prompt,enter“show ip interface brief”.

2.ThescreendisplaysthecurrentIPaddressasshowninFigure5-1.

Figure 5-1: IP Information Screen

 ConguringIPAddress

3.At the “#” prompt, enter the following command and press <Enter> as shown

inFigure5-2.

# congure terminal

(cong)# interface vlan 1

(cong-if-vlan)# ip address 192.168.1.100 255.255.255.0

ThepreviouscommandwouldapplythefollowingsettingsfortheManagedSwitch.

IPAddress:192.168.1.100

Subnet Mask: 255.255.255.0

Figure 5-2: Conguring IP Address Screen

4.Repeatstep1tocheckiftheIPaddressischanged.

 Storecurrentswitchconguration

5.Atthe“#”prompt,enterthefollowingcommandandpress<Enter>.

# copy running-cong startup-cong

Figure 5-3: Saving Current Conguration Command Screen

If the IP is successfully congured, the Managed Switch will apply the new IP

address setting immediately. You can access the Web interface of the Managed

SwitchthroughthenewIPaddress.

Note

If you are not familiar with the console command or the related

parameter, enter “help” anytime in console to get the help

description.

6. Starting Web Management

The following shows how to start up the Web Management of the Managed

Switch. Note the Managed Switch is congured through an Ethernet connection.

Please make sure the manager PC must be set on the same IP subnet address.

For example, the default IP address of the Managed Switch is 192.168.0.100,

thenthemanagerPCshouldbesetat192.168.0.x(wherexisanumberbetween

1and254,except100),andthedefaultsubnetmaskis255.255.255.0.

PC / Workstation with

IE Browser

192.168.0.x

RJ-45/UTP-Cable

IP Address

192.168.0.100

Managed Switch

Figure 6-1: IP Management Diagram

Logging in the Managed Switch

1.Use Internet Explorer 8.0 or above Web browser and enter IP address

http://192.168.0.100(thefactorydefaultIPaddressortheonethatyouhave

justchangedinconsole)toaccesstheWebinterface.
