Planet IAP-2000PE User manual
Industrial 802.11n
Wireless PoE Access Point
IAP-2000PE
Presentation Outline
Product Position
Product Overview
Product Features
Application
Management –Web UI
Comparison –External
Appendix
Product Position
Product Categories of IAP-2000PE
Wireless
LAN
Industrial
Ethernet
Industrial
Wireless
Product Position
New Category of PLANET Product Line
5 / 8
10/100TX LAN
Product Position
Compare with PLANET Indoor Wireless Access Point /
Range Extender Product Line
Low Performance High
11n
300Mbps
11n
150Mbps
WNAP-1110
WNAP-1120PE WNAP-3000PE
10/100/1000T LAN
IAP-2000PE WNAP-C3220
Industrial Grade
Product Position
Why IndustrialIndustrial Wireless Access Point ?
Model IAP-2000PE WNAP-1120PE
Wireless Interface
Wireless Spec. 802.11b/g/n, 2T2R
Max. Speed 300Mbps
Antenna 5dBi 3dBi
Hardware Specification
10/100TX LAN 4 1
Input Power Dual 12~48V DC
24V AC, PoE
5V DC
PoE
Installation DIN-Rail / Wall Mountable Desktop
Operating Temp. -10~60 Degree C 0~40 Degree C
Application Manufactory, Transportation,
Building Automation
Home User, SOHO, SMB,
Enterprise
Product Position
Transportation
Manufactory
Building
Heavy Industry
Application Environments of Industrial Products
Product Overview
5 dBi5 dBi High GainHigh Gain
Antenna x 2Antenna x 2
Wireless
4 x 10/100TX4 x 10/100TX
RJRJ--45 LAN45 LAN
LAN
DINDIN--RailRail KitKit
Installation
RuggedRugged
IP30IP30 AluminumAluminum
metal housingmetal housing
Protection
Product Overview
Reset ButtonReset Button
PoE PD PortPoE PD Port
SMASMA
ConnectorsConnectors
WPS ButtonWPS Button
Front Panel of IAP-2000PE
6-Pin Terminal Block
•Redundant Power Input
•12~48V DC or 24V AC
2 x antenna connectors
•SMA type
•Detachable
4 x RJ-45 ports
•1 x PoE Port (PD)
•10 / 100Base-TX
•Auto MDI / MDI-X
•Auto Negotiation
Buttons
•WPS button
•Reset button (Reboot and Factory Default)
Terminal BlockTerminal Block
Three View Drawing
Product Overview
