WGSW-24010

24-Port + 1 Mini GBIC Managed Gigabit Ethernet Switch

Key Feature

Data Sheet

The WGSW-24010 is a powerful, high-performance 24G + 1 Mini-GBIC

10/100/1000Mbps Fast Ethernet and Gigabit managed switch with twenty-

four 10/100/1000Mbps ports and 1-SFP Mini-GBIC interfaces. The SFP Mini-

GBIC interfaces for fiber extension is ideal for backbone connection to other

workgroup products.

All RJ-45 copper interfaces support 10/100/1000Mbps Auto-Negotiation for

optimal speed detection through RJ-45 Category 6, 5 or 5e cables.Also, all

the ports support Auto-MDI/MDI-X that can detect the type of connection

to any Ethernet device without requiring special straight or crossover cables.

The powerful management capabilities of the device can be managed using

the console, telnet or the web. SNMP MIB-II. Entity MIB and RMON are

supported to provide maximum management functionality, providing a

useful platform for system managers to monitor and administer the system

efficiently. A complete set of diagnostic LED's are provided to simplify

troubleshooting and provide a visible operating status. The IEEE 802.1Q

VLAN tagging feature makes logically separating nodes easier with up to

256 VLAN groups allowed. Port trunking is also supported with up to 8

trunk groups on single switch. To simplify network troubleshooting when

using sniffer software, the WGSW-24010 also supports port mirroring to

duplicate up to 2 ports' transmitting and receiving packets to a specified

sniffer port.

• Complies with IEEE 802.3, 10Base-T, IEEE 802.3u, 100Base-TX

and IEEE 802.3ab, 1000Base-T and IEEE 802.z 1000Base-SX/LX

Ethernet standard

• 24 10/100/1000Mbps Ethernet ports, Auto MDI/MDI-X, Virtual

Cable Test Support

• 1 Mini-GBIC for 1000Base-SX/LX fiber-optic interface with

various connection media and distances

• Features Store-and-Forward mode with wire-speed filtering and

forwarding rates

• Hardware based 10/100Mbps, half/full duplex and 1000Mbps

full duplex mode, flow control and auto-negotiation

• IEEE 802.3x flow control for full duplex operation and

backpressure for half duplex operation

• Integrated address look-up engine, support 4K absolute MAC

addresses, automatic address learning and address aging

• 400KB on chip frame buffer

• 9K Jumbo packet size support

• IEEE 802.1q VLAN, up to 256 VLANS, IEEE 802.1p four priority

with Weight Round Robins

• LACP Link aggregation, port mirroring support

• IGMP Snooping, Storm control

• IEEE 802.1d, IEEE 802.1w, classic Spanning Tree Algorithm or

Rapid Spanning Tree support

• Web, Telnet / Console Command Line management, SNMP v1,

v2C

• RMON Group 1, 2, 3, 9

• Virtual Cable Test (VCT) technology provides the mechanism to

detect and report potential cabling issues, such as cable opens,

cable shorts, etc. on Copper Links.

PLANET reserves the right to change specifications without prior notice. All brand names and trademarks are property or

03-06 C-WGSW24010-2

PLANET Technology Corporation

11F, No. 96, Min Chuan Road, Hsin Tien, Taipei, Taiwan R.O.C.

Tel: 886-2-2219-9518  Fax: 886-2-2219-9528

Email: [email protected] www.planet.com.tw

VoIP Gateway: vip.planet.com.tw

24-Port + 1 Mini GBIC Managed Gigabit Ethernet Switch

WGSW-24010

24-Port + 1 Mini GBIC Managed Gigabit Ethernet Switch

Product

Specification

Applications

Ordering Information

Data Sheet

WGSW-24010

Model

Hardware Specification

Network Ports

Switch Processing Scheme

Switch fabric

Throughput (packet per second)

Address Table

Share data Buffer

Flow Control

Dimensions

Weight

Power Requirement

Temperature

Humidity

Management

Management Interface

Features

Standards Conformance

Regulation Compliance

Standards Compliance

WGSW-24010

24 10/100/100 Base-T STP Ports

1 Mini-GBIC for 1000Base-SX / LX fiber-optic interface (shared with port 12)

Store-and-Forward

48Gbps

35.7Mbps

4K entries

512KB

Back pressure for half duplex, IEEE 802.3x Pause Frame for full duplex

440 x 200 x 44 mm (1U height)

2.64 kg

100~240 VAC, 50-60 Hz

Operating: 0~50 Degree C, Storage -20~70 Degree

Operating: 10% to 90%, Storage: 5% to 95% (Non-condensing)

Web, Console, Telnet and SNMP

RFC 1157 SNMP v1/v2

RFC 1213 MIB II

RFC 1493 Bridge MIB

RFC 1643 Ethernet MIB

RFC 1757 RMON 4 groups: stats, history, Alarms & Events

FCC Part 15 Class A, CE

IEEE 802.3 Ethernet

IEEE 802.3u Fast Ethernet

IEEE 802.3z / 802.3ab Gigabit Ethernet

IEEE 802.3x Flow Control

IEEE 802.1p QoS priority

IEEE 802.1Q VLAN tag

IEEE 802.1D Spanning Tree Protocol

IEEE802.1w Rapid Spanning Tree

RFC 768 UDP

RFC 783 TFTP

RFC 791 IP

RFC 792 ICMP

RFC 826 ARP

RFC 854 Telnet

RFC 2068 HTTP

RFC 2236 IGMPv2

Backbone Switch

With up to 48 Gigabits per second of non-blocking switch fabric, the WGSW-24010 can easily provide the high bandwidth required

both now and in the future.

Server Farm Switch

Providing up to 24 Gigabit Ethernet ports, it is ideal for use as a server farm switch connecting servers. With its port trunking

function, a 2Gb fat pipe is provided for connecting to the backbone if required.
