Phonak Roger AudioHub User manual

This product may be purchased from Connevans Limited

secure online store at www.DeafEquipment.co.uk

DeafEquipment.co.uk

Offering you choice

Helping you choose

Connevans.info

Solutions to improve the quality of life

School:

Roger contact:

Date:

Teacher:

Phone:

Serial number:

1. Plug Roger AudioHub into power source.

2. Hold Roger microphone within 4 inches (10 cm) of Roger

AudioHub. Press Connect.

3. Connect Roger AudioHub to the audio source by plugging

the audio cable into Audio IN on the back of the Roger

AudioHub.

If plugging in only one source, use socket #1. Plug the

other end of the cable into the audio source, such as MP3,

TV, PC, etc.

4. Press and hold the Roger AudioHub’s power button for

2 seconds. Then start the audio source signal.

5. Volume should be adjusted first on the audio source’s, and

then on the Roger AudioHub.

Roger AudioHub indicator light

Solid red – Roger AudioHub is off

Solid blue – Standard operation mode

Blinking blue – Roger microphone is off or out of range

Solid green – Microphone is muted

Green to red – Volume is adjusting +/–

Blinking yellow – Software update

Blinking red – Call your Roger Contact

Alternating red/yellow – Cable is not correctly plugged in

www.eschooldesk.com

Connecting

Connecting Roger AudioHub

to Roger inspiro

Reference Sheet

3

5

2

4

1

V1.00/2013-06/na ©Phonak AG All rights reserved

MAX
