Philips DECT1112S/05 User manual

The meaning of the symbols is the following :

The handset is within range of the base station.When the

symbol is blinking the handset is almost out of range. Move closer to

the base station.The symbol disappears if handset out of range.

The phone is in programming mode.

The line is engaged. The phone is in use.

An internal call is in progress.

The microphone is muted.

The ringer is OFF.

The phonebook is open.

The Baby call is ON.

The keypad is locked.

There are unanswered calls in the call log list*.

There are messages on your voice mailbox.

Batteries charge status : full or low.

* subject to subscription to the Caller Display service.

Note: The call duration appears on the display at the end of the call.

http://www.philips.com/faqs/dect

Handset display

Some symbols appear at the top of the display, according to the

status of the phone.

On first use it is sometimes necessary to wait for a few minutes of

charge before seeing icons on the display.

DECT111 UK master.qxd 07/07/2004 15:28 Page 1

2http://www.philips.com/faqs/dect

Contents

Handset display 1

Installing the DECT 111 3

DECT 111 handset & base 5

DECT 111 keys 6

Using the DECT 111 7

To answer a call 7

To end a call 7

To make an external call 7

Predialling 7

To store a number in the

phonebook 8

To make a call from the

phonebook 8

To delete all the numbers 8

To transfer a call to another

handset (DECT 111 Duo) 9

To redial 9

To call from the Call log 9

To delete all the Call log 10

To mute the handset 10

To program & use the voice mailbox

short cut key 10

To programm & activate Baby call 11

Programming the DECT 111 12

To set the ring tone 12

To set the ring tone volume 12

To change the earpiece volume 12

To select the recall type

(Key “R” setting) 13

To select dialling mode 13

To restore the default settings 13

To change the PIN 14

To activate/deactivate key tones 14

To lock/unlock the keypad 14

Troubleshooting 15

Environment & Safety 16

Philips has marked the battery

and packaging with standard symbols

designed to promote the recycling and

appropriate disposal of your eventual waste.

Batteries should not be disposed of

with general household waste.

A financial contribution has been paid

to the associated national recovery &

recycling system.

The marking certifies

compliance with technical regulations in

accordance with the Directive 1999/5/EC

for the safety of the user, electromagnetic

perturbations and for radio spectrum.

Hereby, Philips, declares that

this DECT 111 is in compliance with the

essential requirements and other relevant

provisions of Directive 1999/5/EC

DECT111 UK master.qxd 07/07/2004 15:28 Page 2

http://www.philips.com/faqs/dect

Installing the DECT 111

The DECT 111 package contains :

One DECT 111 base station , One DECT 111 handset ,

One user guide , one warranty leaflet .

2 dowels/2 screws, 2 rechargeable batteries, 1 line cord, 1 power supply

If anything is missing, please contact your place of purchase immediately.

PLEASE CHARGE THE DECT 111 FOR 24 HOURS BEFORE USE.

ONLY USE RECHARGEABLE BATTERIES.

Unpacking your DECT 111

In the DECT 111 Duo packs you will also find one additional handset, one charger

and 2 additional rechargeable batteries.

Wall mounting

DECT 111 is suitable for wall mounting.

Place vertically the dowels at a distance of 90 mm from each other. Insert the

screws.

Leave a little space (3 mm) between the screw head and the wall.

You can now hang the base station on the screws and connect the power

supply and line cord.

90 mm

3 mm

DECT111 UK master.qxd 07/07/2004 15:29 Page 3

4http://www.philips.com/faqs/dect

Installing your DECT 111

Plug the power supply

& line cord into the base station

Plug the power supply &

line cord into the wall socket.

Always use the cables provided in the box.

Slide open the battery

compartment cover.

Place the 2 batteries as

indicated. Respect polarity.

Slide the battery

compartment cover back.

When replacing the

batteries, only use rechargeable NiMH.

Optimal battery life is reached after

3 cycles of full charge / discharge.

Standby time : around 100 hours

Talk time : around 10 hours

Put the handset on the

base and charge for 24 hours.

If you have a broadband DSL internet Installation,

please make sure you have one DSL filter plugged

directly on each line socket used in the house and

check the modem and the phone are plugged in

the correct filter slot (one specific for each)

DECT111 UK master.qxd 07/07/2004 15:29 Page 4

DECT 111 handset & base

http://www.philips.com/faqs/dect

Paging key

The paging key enables to locate

a missing handset. Press the key

until the handset starts to ring.

Once retrieve, press the call key

on the handset.

Earpiece

Call log key

Redial key

Programming key

Microphone

Inquiry key

Numerical keypad

Talk key

Correction key

Phonebook

Display

DECT111 UK master.qxd 07/07/2004 15:29 Page 5

DECT 111 keys

6http://www.philips.com/faqs/dect

Handset keys

Activate/deactivate the baby call.

Long press to dial voice mailbox number.

Programming key.To start & end a setting.

Flash programming.

- Long press to make an internal call (DECT 111 Duo).

Dial #

- Long press to activate/deactivate the keypad lock.

Dial *

- Long press to activate/deactivate the ring tone.

Open Call log. Press several times to browse the list.

Talk key. Press to answer, make & end a call.

Open Redial list. Press several times to browse the list.

Phonebook. Press several times to browse the list.

Correction key.

- To delete one digit ;

- To return to idle mode ;

- A long press to delete the display number (call log, phonebook,

redial list) ;

- To mute the microphone during a call.

Set the earpiece volume.

Set the ring tone.

Set the ring tone volume.

DECT111 UK master.qxd 07/07/2004 15:29 Page 6

http://www.philips.com/faqs/dect

Using the DECT 111

To answer a call

Press the Talk key to answer the call.

To end a call

Press the Talk key.

Note:With your DECT 111 you can dial up to 18 digits.

To make a call

Press the Talk key.

Dial the number.

To make an internal call (DECT 111 Duo)

Long press on Rkey.

The other handset rings.

Answer the call on the called handset.

Predialling

Dial the phone number.

Press the Correction key to delete incorrect digits.

Press the Talk key.

DECT111 UK master.qxd 07/07/2004 15:29 Page 7

http://www.philips.com/faqs/dect

To make a call from the phonebook

Press the Phonebook key .

The first number is displayed.

Press the key as many times as necessary to reach the entry.

Enter the memory number to reach the desired number.

Press the Talk key to make the call.

Press the Correction key to exit without dialling

To store a number in the phonebook

You can save 10 numbers in your phonebook.

Press the Programming key.

Press the Phonebook key.

The memory number 0 appears. Press again to choose another

memory.

Enter the number.

Press the Programming key to save the number

If you make a mistake press the Correction key to delete

incorrect digits.

To delete all the numbers at once

Press the Programming key.

Press 0

Press the Phonebook key.

Press the Programming key to confirm.

DECT111 UK master.qxd 07/07/2004 15:29 Page 8

http://www.philips.com/faqs/dect

To transfer a call to another handset

(DECT 111 Duo ONLY)

You can forward an external call to the other handset.

During a call :

Long press on the Rkey.

The other handset will ring.

The call is put on hold.

Both internal parties can talk together.

Press the Talk key to transfer the call.

Press Ragain if there is no answer from the other handset.

Press the Redial key.

Display shows the last number dialled.

Press again this key to see the next number.

Press the Talk key to make the call.

Press the Correction key to exit the list.

A long press on the C key deletes the number.

To redial the last 10 dialled numbers

Press the Call log key.

Display shows the newest entry.

Press the Talk key to make the call.

Use the key to scroll through the list of unanswered calls.

Press the Correction key to exit the call log.

A long press erase the current entry and the next is shown

on the display.

Note: the oldest entry is deleted when the memeory is full.

To dial from the call log

To use the call log function you must first subscribe to the Caller Display

(CLI) Service.

Your DECT 11stores the numbers of 20 unanswered calls.

The symbol on the display informs you of unanswered calls.

DECT111 UK master.qxd 07/07/2004 15:29 Page 9
