Philips Essence 5000 Series User manual
DAB+ radio
Your FM/DAB radio
the main unit
Adjust the volume level
Kitchen Timer
Sleep Timer
Your FM/DAB radio
FM/DAB radio
Warranty leaflet
Quick start guide
Overview of the main unit
INFO/MENU
SCAN/SELECT
Preset stations (1, 2, 3)
Press to display information in
FM/DAB mode.
In working mode, press and hold
to access the top menu.
In Bluetooth mode : Press to skip to
the previous track .
In Tuner mode :Tune to a radio station
Navigate through the menu list .
In Bluetooth mode : Press to skip to
the next track .
In Tuner mode :Tune to a radio station
Navigate through the menu list .
auto scan
Connect to the supplied power adaptor .
Store /directly access preset 1, 2, or 3.
Display and select preset stations.
Option 1:AC power
You can use this radio player on AC power
or battery power.
Turn -VOL + repeatedly to adjust volume.
To increase battery life, you can turn off the unit
completely by press and hold button . Press and
hold button again to turn on the set again.
Adjust the volume level
Switch to standby mode
Turn on
Option 2: Battery power
Caution
• Batteries (battery pack or batteries installed) shall not
be exposed to excessive heat such as sunshine, or
the like.
• Danger of explosion if battery is incorrectly replaced.
Replace only with the same equivalent type.
• Do not mix batteries (old and new or carbon and
alkaline, etc.).
• Remove batteries if they are exhausted or if the unit is
not to be used for a long time.
1 Open the battery compartment at the
back of the unit.
2 Insert four R14/UM-2/C size batteries
(not supplied) with correct polarity
(+/-) as indicated, then close the battery
compartment.
The unit is ready to operate.
Caution
• A 'Battery low' Icon is shown when the battery
power is low. Replace batteries or connect to AC
power to ensure normal operation.
Note
•
•
•
•
Batteries contain chemical substances, so they should
be disposed of properly.
You can store a maximum of 20 preset DAB radio
stations.
At step 2, you can also press and hold preset key 1, 2 or
3 to save the current station to the corresponding
position directly.
To remove a preset DAB radio station, store another
station in its place.
Press the numeric key 1-3 directly.
set kitchen timer.
[ Clock ] : set time/date, select 12/24 hour,
and set time synchronization.
set sleep timer.
adjust backlight settings
adjust system settings:
Radio mode
Kitchen timer
Sleep timer
Dynamic Label Segment (DLS)
Signal strength
Program type (PTY)
Ensemble name
Frequency
Signal error rate
Bit rate and audio status
Time
Date
(3 options :Time out/ On level/ Dim level)
[ Language ] : set system language
(English/ Deutsch/ Italiano/ Francais/
Nederlands/ Norwegian)
[ System ] :
[ Backlight ] :
[ Sleep ] :
[ Prune ] :
[ DRC ] :
[ Manual tune ] :
[ Full scan ] :
[ Kitchen Timer ] :
[ Factory Reset ] : reset the unit.
[ SW version ] : view software version.
To store FM radio stations automatically
In FM mode, you have two ways to select a
preset radio station.
Option B:
Press the numeric key 1-3 directly.
Option A:
Radio mode
Kitchen timer
Sleep timer
Radio text messages
Program type
Frequency
Time
Date
While listening to FM radio, press
set kitchen timer.
[ Clock ] : set time/date, select 12/24 hour,
and set time synchronization
set sleep timer.
adjust backlight settings
adjust system settings:
(3 options :Time out/ On level/ Dim level)
[ Language ] : set system language
(English/ Deutsch/ Italiano/ Francais/
Nederlands/ Norwegian)
[ System ] :
[ Backlight ] :
[ Sleep ] :
[ Scan setting ] :
[ Kitchen Timer ] :
s
[ Factory Reset ] : reset the unit.
[ SW version ] : view software version.
