Philips AE2730 User manual

Favorite tunes from

a classic design

An analog portable radio that works on mains and batteries. Its convenient controls lets

you tune in to your favorite stations easily. Its wooden box design gives it a classic look

and improves sound quality.

Enjoy your favorite radio stations or MP3 music

• FM/MW analogue radio tuning

• Line-in connection for your MP3 portable music player

Excellent sound reproduction

• Bass Reflex speakers deliver a powerful, deeper bass

• Dynamic Bass Boost for deep and dramatic sound

• 2W RMS total output power

Philips

Portable Radio

AE2730

AE2730/12

Portable Radio

Specifications Product highlights

Sound

•Sound Enhancement: Dynamic Bass Boost

•Sound System: Mono

•Output power (RMS): 2W

•Volume Control: rotary

Tuner/Reception/Transmission

•Tuner Bands: FM, MW

Connectivity

•Headphone: 3.5 mm

•Audio Connections: 3.5mm Line in

Accessories

•Included Accessories: User Manual, Audio Cable,

AC-DC Adapter

Dimensions

•Product dimensions (W x H x D):

260 x 137 x 141 mm

•Product weight: 1.67 kg

Power

•Battery type: LR20

•Battery voltage: 1.5 V

•Number of batteries: 6

•Mains power: 220-240V

Loudspeakers

•Main Speaker: 3" full range woofer

•

Issue date 2008-04-04

Version: 2.0.4

12 NC: 8670 000 32579

EAN: 87 12581 35319 3

© 2008 Koninklijke Philips Electronics N.V.

All Rights reserved.

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips

Electronics N.V. or their respective owners.

www.philips.com

Bass Reflex Speaker System

Bass Reflex Speaker System delivers a deep bass

experience from a compact loudspeaker box system. It

differs from a conventional loud speaker box system in the

addition of a bass pipe that is acoustically aligned to the

woofer to optimize the low frequency roll-off of the

system. The result is deeper controlled bass and lower

distortion. The system works by resonating the air mass

in the bass pipe to vibrate like a conventional woofer.

Combined with the response of the woofer, the system

extends the overall low frequency sounds to create a

whole new dimension of deep bass.
