Philips Lytecaster 2000P1 User manual

Lightolier is a Philips group brand

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details of design, materials and finish.

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

Lytecaster®Recessed Downlighting 2000P1

Page 1 of 1 3 3/4" Aperture Incandescent Standard Frame-In Kit

Features

1. Housing: .032” aluminum. Access door for inspection of junction box.

2. Mounting Frame: .036” (#20 ga.) galvanized steel. Accommodates all

ceilings up to 1” thick. Push-in/twist-out rotoclips hold reflector flush to

ceiling.

3. Junction Box: 4” x 3 1/2” x 2”; .063 (#14 ga.) galvanized steel. U.L. listed

for maximum of 8 No. 12 ga. 75º C through branch circuit conductors. Access

door inside of housing allows easy inspection of wiring without removal of

housing. Integral cable clamps permit attachment of nonmetallic Romex®or

armored cable without need of additional connectors.

4. Mounting Bars: .059 (#16 ga.) galvanized steel. 13” long bars extend

to 27" with integral nailing tabs. Attaches to wood joist without need of

accessories.

5. Socket Spring: .030” steel.

6. Socket: Porcelain medium base; nickel plated screw shell. Pre-wired with

#18 ga. SF1 leads to junction box.

7. Thermal Protector: Meets NEC and UL requirements. Insulation must be

kept 3" away from fixture sides and wiring compartments and must not be

placed above fixture in a manner which will entrap heat.

Options & Accessories

Mounting Bars: 1964 - 20” set of (4)

T-Bar Ceiling Clips: 1956 - set of (4)

Plaster Ceiling Ring: 1959 - 7/8" depth for wet plaster ceilings

277V Remote Step 7997 - 277V down to 120V

Down Transformer: 300W max. load.

Labels

UL (Suitable for Damp Locations), I.B.E.W.

Complete Fixture consists of Reflector Trim & Frame-In Kit. Select each separately.

Frame-In Kit Reflector Trims — See Individual Reflector Trim Specification Sheets

Open Downlight Recessed Enclosed

Aperture Cone Satin Cone Baffles Pinhole Adjustable Eyeball Diffuser

2000P1 2012 2008 2005 2011 2027 2022 2090

2012NM 2008NM 2005BNM 2022WH 2022WH

2013 2010 2005NM 2027NM

2013BKNM 2010NM 2005WH 2027WH

2013CD 2029BK

2013CDNM 2029BKNM

2013NM 2029CD

2013BK 2029CDNM

2013WH 2029CL

2013WD 2029CLNM

2013WDP 2029GD

2029GDNM

2029WH

2027BNM

Romex® is a registered trademark of General Cable Industries Inc.
