24MHT45RS

Lytespan, Mini HID T4.5 Spot Reflector

Page 1 of 2

Features

1. Spot reflector: Aluminum, faceted, specular,

anodized and sealed.

Finish

Specular anodized and sealed.

Labels

UL, cUL

Ordering Information

Catalog No. Finish Lamps For Use With Luminaires

24MHT45RNF

24MHT45RNFCCZ

24MHT45RNFWRM

Anodized

Champagne Bronze

Incandescent Warm

T4.5 8114, 8115

3 5/32 in

[80.0 mm]

5/8 in

[16.3 mm]

2 11/16 in

[68.6 mm]

1 17/32 in

[39.2 mm]

Philips Lightolier

e: [email protected]

t: (508) 679-8131

w: www.lightolier.com

24MHT45RS January 20, 2011

Specifications are subject to change without notice.

Job Information Type:

24MHT45RS

Lytespan, Mini HID T4.5 Spot Reflector

Page 2 of 2

L Beam length D Distance

W Beam Width A Aiming Angle

C Distance to FC Footcandles

center beam

L and W are the outer points where the candle

power drops to 50% of the maximum. FC are

the initial footcandles at the center of the beam.

Lamp data shown is typical. Consult lamp

manufacturers for availability and performance.

CBCP = Center Beam Candle Power.

Aiming angle: 0° 30° Horizontal 30° Vertical 45° Vertical

Lamp

Beam Spread CBCP Rated

(To 50% CBCP) Life (Hrs.)

D FC L W D C FC L W D C FC L W D C FC L W

Lamp

Beam Spread CBCP Rated

(To 50% CBCP) Life (Hrs.)

D FC L W D C FC L W D C FC L W D C FC L W

29706 10000

24MHT45RS

39W T4.5 9°

8114

56441 10000

24MHT45RS

70W T4.5 9°

8115

12 6.9 134 2.5 2.2

14 8.1 98 2.9 2.5

16 9.2 75 3.4 2.9

18 10.4 60 3.8 3.3

14 8.1 187 2.9 2.5

16 9.2 143 3.4 2.9

18 10.4 113 3.8 3.3

20 11.5 92 4.2 3.6

4 6.9 232 2.6 1.3

5 8.7 149 3.2 1.6

6 10.4 103 3.8 1.9

7 12.1 76 4.5 2.2

6 10.4 196 3.8 1.9

7 12.1 144 4.5 2.2

8 13.9 110 5.1 2.5

9 15.6 87 5.8 2.8

6 6.0 292 1.9 1.3

7 7.0 214 2.2 1.6

8 8.0 164 2.5 1.8

9 9.0 130 2.9 2.0

8 8.0 312 2.5 1.8

10 10.0 200 3.2 2.2

12 12.0 139 3.8 2.7

14 14.0 102 4.4 3.1

14 152 2.2 2.2

16 116 2.5 2.5

18 92 2.8 2.8

20 74 3.1 3.1

16 220 2.5 2.5

18 174 2.8 2.8

20 141 3.1 3.1

22 117 3.5 3.5

Note: For Champagne Bronze (CCZ), multiply FC values by 0.64.

For Incandescent Warm (WRM), multiply FC values by 0.85
