Philips G4 User manual

7.5 min.

∅9.3 max.

∅9 max.

4 ±0.25

23.5 ±0.25

33 max.

7.5 min.

∅12 max.

6.35 ±0.25

30 ±0.25

44 max.

8.5 ±0.5

∅9.3 max.

∅9 max.

4 ±0.25

22.5 ±0.25

31 max.

Universal

Dimensions in mm

Burning position

GY6.35 CL GY6.35 FR

Low voltage

capsules

Silver low pressure/UV-Block,

Super low pressure/UV-Block G4

Silver low pressure/UV-Block,

Super low pressure/UV-Block GY6.35

Standard G4 Low pressure UV-Block

Halogen lamps Low-voltage capsules

CAPSULEline Pro

CAPSULEline Pro capsules are

the most compact halogen lamps

and can be used for a wide range

of applications.The Philips range

of low-voltage capsules consists of

the following groups:

-LOW-PRESSURE SUPER

(incl. UV-Block glass): lamps in

accordance with IEC 357 with

special operating fillgas pressure

of ≤2.5 bar to be used in

luminaires without front glass in

accordance with IEC 598.

They have an axial filament for

high centre-beam intensities.

The lamps are available with

both clear and frosted glass.

- LOW-PRESSURE STANDARD

5W lamp with a transversal

(bow) filament and UV-BLOCK

glass.

-UV Block (24V): with special

UV-Block (quartz) glass to

considerably reduce the

UV output and with axial

filament.

Burning position: universal.

Halogen CAPSULEline Pro

capsules also offer the following

benefits to luminaire

manufacturers:

- Opportunity to design compact

luminaires for a variety of

applications.

-Value-adding possibilities for

total lighting system (lamp and

reflector).

- Low-pressure technology to

design luminaires without front

glass.

- Strong reduced pinch

temperatures

Applications

- Task lighting

- Decorative applications in

homes, shops, and

hotels/restaurants

shoplighting

300 400 500 600 700

500

400

300

200

100

13102 (12V 50W excluding UV-block "normal glass")

Wavelength in nm

µW per 5 nm per lumen

Halogen lamps Low-voltage capsules

CAPSULEline Pro

Commercial Type Voltage Wattage Cap/ Finish Lumen Correlated Lamp EOC

name base output colour life

temperature 50%

V W lm K h

SILVER (LOW PRESSURE/UV-BLOCK)

CAPSULEline Pro 13691 12 20 G4 FROSTED 315 3000 3000 404466

CAPSULEline Pro 13756 12 20 GY6.35 FROSTED 300 3000 3000 402455

CAPSULEline Pro 13755 12 35 GY6.35 FROSTED 600 3000 3000 402448

CAPSULEline Pro 13754 12 50 GY6.35 FROSTED 950 3000 3000 402431

SUPER (REF:24V) (UV-BLOCK)

CAPSULEline Pro 13091 24 20 G4 CLEAR 300 3000 2000 409621

CAPSULEline Pro 13090 24 50 GY6.35 CLEAR 850 3000 2000 409638

CAPSULEline Pro 13089 24 100 GY6.35 CLEAR 2200 3000 2000 409645

STANDARD (LOW PRESSURE/UV-BLOCK)

CAPSULEline Pro 13283 12 5 G4 CLEAR 60 2800 2000 409690

SUPER (LOW PRESSURE/UV-BLOCK)

CAPSULEline Pro 13284 12 10 G4 CLEAR 140 2850 3000 409706

CAPSULEline Pro 13078 12 20 G4 CLEAR 320 3000 3000 402103

CAPSULEline Pro 13104 12 20 GY6.35 CLEAR 300 3000 3000 402196

CAPSULEline Pro 13103 12 35 GY6.35 CLEAR 600 3000 3000 402189

CAPSULEline Pro 13079 12 50 GY6.35 CLEAR 935 3000 3000 402110

CAPSULEline Pro 13102 12 50 GY6.35 CLEAR 950 3000 3000 402172

CAPSULEline Pro 13101 12 75 GY6.35 CLEAR 1575 3000 3000 402165

CAPSULEline Pro 13100 12 100 GY6.35 CLEAR 2200 3000 3000 402158

Spectral power distributions

300 400 500 600 700

500

400

300

200

100

13102 (12V 50W low pressure including UV-block)

Wavelength in nm

µW per 5 nm per lumen
