Philips Satinelle Ice Premium User manual

Satinelle Ice Premium

HP6503

4203.000.3683.1.indd 1 22-11-2006 14:48:18

4203.000.3683.1.indd 2 22-11-2006 14:48:19

4203.000.3683.1.indd 3 22-11-2006 14:48:21

4203.000.3683.1.indd 4 22-11-2006 14:48:21

HP6503

ENGLISH 6

FRANÇAIS 19

한국어 33

ภาษาไทย 46

繁體中文 56

简体中文 67

4203.000.3683.1.indd 5 22-11-2006 14:48:24

Introduction

With your new Satinelle ICE PREMIUM you can remove unwanted hairs

quickly, easily and effectively.The combination of the ceramic epilating

system with the contour-following skin cooler and the new

sonic massaging system constitutes a revolution in epilation.Thanks to the

natural numbing effect of ice and massaging, the new Satinelle ICE

PREMIUM makes epilation more comfortable and less painful than ever.

The result is a silky-smooth skin and a hair growth reduction of up to

50%, assuming you use the appliance regularly (every 4 weeks).

The Satinelle ICE PREMIUM is suitable for all body parts and comes with

a skin cooler that has been specially developed for epilating sensitive

areas (underarms, bikini line).These areas can be particularly sensitive to

pain, which this special skin cooler helps to diminish.

The rapidly rotating epilating discs catch even the shortest hairs (down to

0.5 millimetre!) and pull them out by the roots.As a result, your skin stays

smooth for up to four weeks and regrowth is soft and downy.

General description (Fig. 1)

AInsulating sleeve for skin cooler

BLeg skin cooler with pivoting cooling head

CSkin cooler for underarms and bikini line

DShaving head

EProtective cap of shaving head

FMassaging element

GEpilating head

HAppliance

ICharging light

JAdapter

KCleaning brush

LExfoliating body puff

MStand

Important

Read this user manual carefully before you use the appliance and save it

for future reference.

ENGLISH6

4203.000.3683.1.indd 6 22-11-2006 14:48:24

Check if the voltage indicated on the adapter corresponds to the

local mains voltage before you connect the appliance.

Only use the appliance in combination with the adapter supplied.

Do not use the appliance if the adapter or the appliance itself is

damaged.

If the adapter is damaged, always have it replaced with one of the

original type in order to avoid a hazard.

The adapter contains a transformer. Do not cut off the adapter to

replace it with another plug, as this causes a hazardous situation.

Keep the appliance and the adapter dry.

Keep the appliance out of the reach of children.

Do not expose the appliance to temperatures lower than 5°C or

higher than 35°C.

To prevent damage and injuries, keep the running appliance away

from your scalp hair, eyebrows, eyelashes, clothes, threads, cords,

brushes etc.

This appliance contains two NiMh rechargeable batteries that may

harm the environment if not disposed of properly.

Do not use the appliance on irritated skin or skin with varicose

veins, rashes, spots, moles (with hairs) or wounds without consulting

your doctor rst. People with a reduced immune response or people

who suffer from diabetes mellitus, Raynaud’s disease or

immunodeciency should contact their doctor rst.

Electromagnetic elds

This Philips appliance complies with all standards regarding

electromagnetic elds (EMF). If handled properly and according to

the instructions in this user manual, the appliance is safe to use based on

scientic evidence available today.

Charging

You can run the appliance directly from the mains or you can use it

without the cord when the batteries have been charged.

Charge the batteries at least 16 hours before you use the appliance for a

cordless operating time of up to 20 minutes.

Do not charge the appliance for more than 24 hours.

ENGLISH 7

4203.000.3683.1.indd 7 22-11-2006 14:48:24

1 Make sure the appliance is switched off while charging.

2 Insert the appliance plug into the bottom of the appliance and put

the adapter in the wall socket.

The charging light goes on and stays on to indicate that the appliance

is charging.

The charging light does not go out or change colour when the

appliance is fully charged.

3 For more convenient charging, you can put the appliance in

the stand (‘click’) (Fig. 2).

Optimising the lifetime of the batteries

After you have charged the appliance for the rst time, do not

recharge it between epilating or shaving sessions. Continue to use it

and only recharge it when the battery is (almost) empty.

Discharge the batteries completely twice a year by letting the motor

run until it stops.

Do not keep the appliance plugged into a wall socket all the time.

If the appliance has not been used for a long time, it must be

recharged for 16 hours.

Preparing for use

Freezing the skin cooler

1 Put the skin cooler WITHOUT the insulating sleeve in the freezer

or freezing compartment (***) at least 4 hours before you start to

epilate. When the uid has turned completely blue, the skin cooler

is ready for use.

Make sure the outside of the skin cooler is completely dry before you

freeze it.

Tip:You can store the skin cooler in the freezer permanently.

ENGLISH8

4203.000.3683.1.indd 8 22-11-2006 14:48:24

Using the appliance

General information about epilation

Epilation is easier just after a bath or shower. Make sure your skin is

completely dry when you start to epilate.

When you use the appliance for the rst time, we advise you to try

it out on an area with only light hair growth.This helps you get

accustomed to the epilation process.

For optimal epilating results, the hairs should not be longer than

10 millimetres (Fig. 3)

To epilate longer hairs: (Fig. 3)

shorten the hairs to a maximum length of 10mm with a trimmer. In

this case, you can start to epilate right away.

shave the hairs completely. In this case you can start to epilate after a

few days (the hairs must be at least 0.5mm long).

Your skin may become a little red and irritated the rst few times

you use the epilator.This phenomenon is absolutely normal

and quickly disappears.As you use the appliance more often, your

skin gets used to epilation, skin irritation decreases and

regrowth becomes thinner and softer. If the irritation has not

disappeared within three days, we advise you to consult a doctor.

We advise you to epilate before you go to bed at night, as this allows

any skin irritation that may develop to diminish overnight.

Corded use

Do not run the appliance from the mains when the battery is fully

charged.

1 To run the appliance from the mains, switch off the appliance and

connect it to the mains.Wait a few seconds before you switch on

the appliance.

Epilating with the leg skin cooler

Make sure your skin is clean, entirely dry and free from grease. Do not

use any cream before you start to epilate.

1 Slide the insulating sleeve onto the skin cooler. (Fig. 4)

ENGLISH 9

4203.000.3683.1.indd 9 22-11-2006 14:48:24

The insulating sleeve prevents an unpleasant sensation of coldness in your

hand while you use the appliance. It also keeps the skin cooler cold as

long as possible.

Sometimes the pivoting cooling head freezes onto the skin cooler and

does not move when you take the skin cooler from the freezer.The

pivoting cooling head starts to pivot again after you have passed it over

your leg a few times.

2 Snap the appliance onto the skin cooler (Fig. 5).

3 Insert the appliance plug into the bottom of the appliance and put

the adapter in the wall socket.

4 Select the desired speed to switch on the appliance (Fig. 6).

Select speed I for areas with little hair growth and for areas where bones

are located directly beneath the skin, such as knees and ankles.

Select speed II for larger areas with stronger hair growth.

5 Stretch your skin with your free hand to make the hairs stand

upright.

6 Place the appliance perpendicularly onto the skin with the epilating

head pointing forward. Move the appliance against the direction of

hair growth at a moderate speed. (Fig. 7)

Make sure both the epilating discs and the skin cooler are in proper

contact with the skin.

Press the appliance lightly onto the skin.

If you are not completely satised with the epilation result, try

moving the epilator more slowly over your skin.

7 Use the tab on the bottom end of the appliance to remove the

appliance from the skin cooler (Fig. 8).

Epilating with the skin cooler for underarms and bikini line

The special skin cooler for the underarms and the bikini line reduces the

number of active epilating discs. Combined with the large cooling surface,

this skin cooler makes epilating sensitive areas less painful.You get the best

results when the hairs are not too long (max. 1cm).

1 Slide the insulating sleeve onto the skin cooler. (Fig. 9)

ENGLISH10

4203.000.3683.1.indd 10 22-11-2006 14:48:25
