Philips LASERFAX 920 User manual
920
100
80
60
40
20
OFF
English page 4
Français page 16
Dansk side 28
Norsk side 40
Svenska sid 52
Suomi sivu 64
2
76
87
3
4
1Do not allow the shaver to become wet.
2Do not leave the appliance in a position
where it can become damaged by direct
sunlight or other heat source.
- Before first use or
- if the shaver has not been used for a
month or longer
it should be charged for a period of at
least 8 hours (irrespective of the reading
on the display).
If the batteries are completely empty, it may
take some time (3-5 minutes) before
information appears in the display.
• Please bear in mind that your skin may
need two to four weeks to become fully
accustomed to the Philishave shaving
system.
920
100
80
60
40
20
2
920
100
80
60
40
20
1
■■■ Important English
■■■ Switching on/off.
3 The slider switch has a locking
knob which prevents the shaver
from being switched on
accidentally.
Keeping the small knob on the
switch pressed-in slide the switch
upwards/downwards.
■■■ Charging
• Ensure that the shaver is switched off.
•It is advisable to charge the shaver at
temperatures between 5°and 35°C (41°and 95°F).
This guarantees maximum life from the
rechargeable batteries.
•If you keep the shaver in the case when
charging ensure that the lid is left open to
prevent overheating.
•Before first use (or if the shaver has not been
used for long time) it should be charged for a
period of at least 8 hours.
5
3
To protect the environment, this
rechargeable Philishave appliance is
equipped with nickel-hydride batteries.
These contain less than 0.01% cadmium.
Yet we advise you to ensure that the batteries
are separated from the normal household
refuse and that they are disposed of at an
officially assigned place when discarding your
appliance in due course. Please refer to section
“Protecting the environment”.
•Recharging: 60 minutes.
The shaver can also be charged from a 12 - 24 Volts
(DC) supply using cord connector type HP 1957.
(Available from Philips retailers or Authorised Service
Dealers.) Charging from a 12 - 24 Volts (DC) supply
requires approx. 24 hours.
• Regular cleaning of the shaver means that less
battery energy is consumed, so that more shaving
time becomes available.
• The shaver will not be damaged by leaving it
connected to the mains supply after it is fully
charged. However, it is not advisable to charge the
shaver permanently as this would shorten the life of
the rechargeable batteries.
4 Insert the small plug into the
shaver. Ensure that the plug is
pushed fully home. (Note the
indication mark.)
Mains voltages: 100 - 240 Volts.
(The shaver adjusts
automatically.)
5One of the blocks of the charge meter
will start flashing.
If the batteries are almost empty, the
first block will be red.
When it turns green, there is enough
energy in the rechargeable batteries for
one cordless shave (3 minutes).
6Each time when 20% of the full charge
has been accomplished the next block
of the energy meter will start to flash.
920
100
80
60
40
20
920
100
80
60
40
20
920
100
80
60
40
20
4
6
7After 60 minutes, block “100” comes on
flashing. This block stops flashing as
soon as the shaver is fully charged.
■■■ Cordless shaving
When switching on and off, the blocks of the energy
meter become visible for approx. 8 seconds.
You can then check how much charge is still
available in the rechargeable batteries, until the
reserve capacity will be reached.
8After shaving cordless with the fully
charged shaver for some time, the fifth
block will no longer be visible.
Thereafter, the other blocks will
disappear successively.
9When the last block turns red, the
reserve energy has been reached.
(You will be able to complete the
shave.)
As the shaver is switched off you will
hear a sound signal for 4 seconds
and the red block will start flashing.
This indicates that it is time to
recharge the shaver.
7
920
100
80
60
40
20
920
100
80
60
40
20
920
100
80
60
40
20
8
■■■ Have you missed out charging?
When the batteries are completely empty and the
shaver stops, you can give the shaver a quick
charge (sufficient for one cordless shave):
- Charge the shaver until the last block turns from red
into green.
■■■ Shaving directly from the mains supply
(wall socket)
- If you wish you can connect the shaver to a wall
socket using the mains cord and shave directly from
the mains supply.
■■■ Shaving
10 Switch on.
11 The comfort control can be adjusted to suit
skin sensitivity.
Start with the control set to position 1 (for sensitive
skin) and then try other positions to find the one
that suits you best.
12 Move the shaving unit quickly over the skin
and especially against the direction of the hair
growth, stretching the skin with your free hand to
bring the hairs into an upright position.
• Best results are obtained if the skin is dry.
Preferably shave before or some time after
washing.
• If required apply a pre-shave lotion. This can be
particularly helpful if the climate is warm and humid.
9
10
1 2 3 4 5 6 7 8 9
11 12
■■■ Trimmer
The trimmer can be engaged whilst the motor is
running.
13 To engage the trimmer push the slide
upwards.
To disengage move the slide downwards.
Brush the trimmer clean after each use.
14 The trimmer has been especially designed for
grooming sideburns, moustache and beard.
The trimmer is not required for long hairs in the
neck area; these hairs can easily be shaved off
with the shaving unit.
15 Maintenance (every six months)
Apply two drops of light machine oil to the teeth of
the trimmer.
10
14
13 15
OIL
