Philips DVP3800/55 User manual

TABLE OF CONTENTS

Page

Version 1.4

Service Manual

PHILIPS

transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise

without the prior permission of Philips.

CLASS 1

LASER PRODUCT

Service

DVD Player

Published by LLL - 1202BU AVM Printed in The Netherlands Subject to modification

3141 785 36984

DVP3800(X)

DVP3800/55

This service manual is for DVP3800

second generation model, which is different from the

first generation DVP3800 model.

For second generation model, the serial number begins

with KX 2Axxxxxxxxxx

Specification............................................................................1-2

Safety Instruction,Warning & Notes........................................1-3

Mechanical and Dismantling Instruction..................................2-1

Software Upgrades..................................................................3-1

Trouble Shooting ....................................................................4-1

Wiring Diagram........................................................................5-1

Electrical Diagram and Print-layout.........................................6-1

Mechanical Exploded View.....................................................7-1

Revision List............................................................................8-1

Second Generation

DVP3800/96/98

DVP3800/93

DVP3800/79

DVP3800X/77

Note

Speciﬁcations are subject to change without notice

•

DVD region code Countries

Playable media

Disc

DVD, DVD-Video, VCD, SVCD, Audio CD

DVD+R/+RW, DVD-R/-RW, DVD+R/-R DL (Dual

Layer), CD-R/-RW (Maximum number of ﬁles: 648)

File

Video: .avi, .divx, .mp4, .xvid

Audio: .mp3, .wma

Picture: .jpg, .jpeg

Video

Signal system: PAL, NTSC

Composite video output: 1 Vp-p (75 Ohm)

Component video output: 0.7 Vp-p (75 Ohm)

Audio

2-channel analog output

Audio Front L&R : 2 Vrms (47k Ohm)

Digital output: 0.5 Vp-p (75 Ohm)

Coaxial

Sampling frequency:

•

Specifications For DVP3800/55

1-2

Latin America

MP3: 8 kHz, 11 kHz, 12 kHz, 16 kHz, 22 kHz, 24 kHz, 32

kHz, 44.1 kHz, 48 kHz

WMA: 44.1 kHz, 48 kHz

Constant bit rate:

MP3: 8 kbps - 320 kbps

WMA: 64 kbps - 192 kbps

Main unit

Dimensions (W x H x D): 360 x 42 x 209 (mm)

Net Weight: 1.44 kg

Power

Power supply rating: 110 - 240 V, 50/60 Hz

Power consumption: < 8 W

Power consumption in standby mode: < 0.3 W

Accessories supplied

Remote control and one battery

AC Power cord

User Manual

Laser speciﬁcation

Type: Semiconductor laser InGaAIP (DVD), AIGaAs (CD)

Wave length: 658 nm (DVD), 790 nm (CD)

Output Power: 7.0 mW (DVD), 10.0 mW (VCD/CD)

Beam divergence: 60 degrees

•

1-3

•Power Plug Adapter

Note

Speciﬁcations are subject to change without notice.

•

DVD region code Countries

Asia Paciﬁc, Taiwan, Korea

Playable media

• Disc

DVD, DVD-Video, VCD, SVCD, Audio CD•

DVD+R/+RW, DVD-R/-RW, DVD+R/-R DL (Dual Layer),•

CD-R/-RW (Maximum number of ﬁles: 648)

• File

Video: .avi, .divx, .mp4, .xvid•

Audio: .mp3, .wma•

Picture: .jpg, .jpeg•

Video

Signal system: PAL, NTSC•

Composite video output: 1 Vp-p (75 Ohm)•

Component video output: 0.7 Vp-p (75 Ohm)•

Audio

2-channel analog output•

Audio Front L&R : 2 Vrms (47k Ohm)•

Digital output: 0.5 Vp-p (75 Ohm)•

Coaxial•

Sampling frequency:•

MP3: 8 kHz, 11 kHz, 12 kHz, 16 kHz, 22 kHz, 24 kHz, 32 kHz, 44.1 kHz, 48 kHz•

WMA: 44.1 kHz, 48 kHz•

Constant bit rate:•

MP3: 8 kbps - 320 kbps•

WMA: 64 kbps - 192 kbps•

Main unit

Dimensions (W x H x D): 360 x 42 x 209 (mm)•

Net Weight: 1.35 kg•

Specifications for DVP3800/96

1-4

Power

Power supply rating: 110–240 V~, 50/60 Hz•

Power consumption: < 8 W•

Power consumption in standby mode: < 0.3 W•

Accessories supplied

Remote control and one battery•

Audio/Video cables•

User Manual•

Laser speciﬁcation

Type: Semiconductor laser InGaAIP (DVD), AIGaAs (CD)•

Wave length: 658 nm (DVD), 790 nm (CD)•

Output Power: 7.0 mW (DVD), 10.0 mW (VCD/CD)•

Beam divergence: 60 degrees•

1-5

Note

Speciﬁcations are subject to change without notice.

•

DVD region code Countries

Asia Paciﬁc, Taiwan, Korea

Playable media

• Disc

DVD, DVD-Video, VCD, SVCD, Audio CD•

DVD+R/+RW, DVD-R/-RW, DVD+R/-R DL (Dual Layer),•

CD-R/-RW (Maximum number of ﬁles: 648)

• File

Video: .avi, .divx, .mp4, .xvid•

Audio: .mp3, .wma•

Picture: .jpg, .jpeg•

Video

Signal system: PAL, NTSC•

Composite video output: 1 Vp-p (75 Ohm)•

Component video output: 0.7 Vp-p (75 Ohm)•

Audio

2-channel analog output•

Audio Front L&R : 2 Vrms (47k Ohm)•

Digital output: 0.5 Vp-p (75 Ohm)•

Coaxial•

Sampling frequency:•

MP3: 8 kHz, 11 kHz, 12 kHz, 16 kHz, 22 kHz, 24 kHz, 32 kHz, 44.1 kHz, 48 kHz•

WMA: 44.1 kHz, 48 kHz•

Constant bit rate:•

MP3: 8 kbps - 320 kbps•

WMA: 64 kbps - 192 kbps•

Main unit

Dimensions (W x H x D): 360 x 42 x 209 (mm)•

Net Weight: 1.34 kg•

Specifications for DVP3800/98

1-6

Power

Power supply rating: 110–240 V~, 50/60 Hz•

Power consumption: < 8 W•

Power consumption in standby mode: < 0.3 W•

Accessories supplied

Remote control and one battery•

Power cord•

Audio/Video cables•

User Manual•

Laser speciﬁcation

Type: Semiconductor laser InGaAIP (DVD), AIGaAs (CD)•

Wave length: 658 nm (DVD), 790 nm (CD)•

Output Power: 7.0 mW (DVD), 10.0 mW (VCD/CD)•

Beam divergence: 60 degrees•

1-7

Note

Speciﬁcations are subject to change without

•

notice

DVD region code Countries

Playable media

• Disc

DVD, DVD-Video, VCD, SVCD, Audio CD•

DVD+R/+RW, DVD-R/-RW, DVD+R/-R DL

(Dual Layer), CD-R/-RW (Maximum number

•

of ﬁles: 648)

• File

Video: .avi, .divx, .mp4, .xvid•

Audio: .mp3, .wma•

Picture: .jpg, .jpeg•

Video

Signal system: PAL, NTSC•

Composite video output: 1 Vp-p (75 ohm)•

Audio

2-channel analog output•

Audio Front L&R : 2 Vrms (47k Ohm)•

Digital output: 0.5 Vp-p (75 ohm)•

Coaxial•

Sampling frequency:•

MP3: 8 kHz, 11 kHz, 12 kHz, 16 kHz,

22 kHz, 24 kHz, 32 kHz, 44.1 kHz, 48 kHz

•

WMA: 44.1 kHz, 48 kHz•

Constant bit rate:•

MP3: 8 kbps - 320 kbps•

WMA: 64 kbps - 192 kbps•

Main unit

Dimensions (W x H x D): 360 x 42 x 209 (mm)•

Net Weight: 1.31 kg•

Power

Power supply rating: 110–240 V~, 50/60 Hz•

Power consumption: < 8 W•

Power consumption in standby mode: < 0.3 W•

Accessories supplied

Remote control and one battery•

Specifications For DVP3800/93

China

•

Laser speciﬁcation

Type: Semiconductor laser InGaAIP (DVD),

AIGaAs (CD)

•

Wave length: 658 nm (DVD), 790 nm (CD)•

Output Power:

7.0 mW (DVD), 10.0 mW (VCD/CD)

•

Beam divergence: 60 degrees•

1-8

Note

Speciﬁcations are subject to change without notice.

•

DVD region code Countries

Australia, New Zealand

Playable media

• Disc

DVD, DVD-Video, VCD, SVCD, Audio CD•

DVD+R/+RW, DVD-R/-RW, DVD+R/-R DL (Dual Layer),•

CD-R/-RW (Maximum number of ﬁles: 648)

• File

Video: .avi, .divx, .mp4 (MPEG-4 Part 2), .xvid•

Audio: .mp3, .wma•

Picture: .jpg, .jpeg•

Video

Signal system: PAL, NTSC•

Composite video output: 1 Vp-p (75 Ohm)•

Component video output: 0.7 Vp-p (75 Ohm)•

Audio

2-channel analog output•

AUDIO OUT L&R : 2 Vrms (47k Ohm)•

Digital output: 0.5 Vp-p (75 Ohm)•

Coaxial•

Sampling frequency:•

MP3: 8 kHz, 11 kHz, 12 kHz, 16 kHz, 22 kHz, 24 kHz, 32 kHz, 44.1 kHz, 48 kHz•

WMA: 44.1 kHz, 48 kHz•

Constant bit rate:•

MP3: 8 kbps - 320 kbps•

WMA: 64 kbps - 192 kbps•

Main unit

Dimensions (W x H x D): 360 x 42 x 209 (mm)•

Net Weight: 1.35 kg•

1-9

DVP3800/79 Specification

Power

Power supply rating: 230–240 V~, 50 Hz•

Power consumption: < 8 W•

Power consumption in standby mode: < 0.3 W•

Accessories supplied

Remote control and one battery•

Audio/Video cables•

User Manual•

Laser speciﬁcation

Type: Semiconductor laser InGaAIP (DVD), AIGaAs (CD)•

Wave length: 658 nm (DVD), 790 nm (CD)•

Output Power: 7.0 mW (DVD), 10.0 mW (VCD/CD)•

Beam divergence: 60 degrees•

1-10
