Philips SDW5004GN User manual

For preview purpose only

Combine and separate satellite

and antenna signals

Consolidate satellite and antenna signals into a single path. Use a second to separate

the signals. For use with quad shield cable. For indoor or outdoor use.

Enjoy a better, brighter picture

• Minimum signal loss

Enjoy extended durability

• Corrosion-resistant connections

Philips

Digital Satellite Diplexer

SDW5004GN

For preview purpose only

SDW5004GN/17

Technical specifications Product highlights

Digital Satellite Diplexer

Date of issue 2006-10-06

Version: 2.0

12 NC: 9082 100 09585

UPC: 6 09585 11882 9

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips

Electronics N.V. or their respective owners.

www.philips.com

Packaging

•EAN/UPC/GTIN: 6 09585 11882 9

•Quantity: 1

•Gross Weight: 0.27 kg

•Tare Weight: 0.04 kg

•Net Weight: 0.23 kg

•Length: 19.7 cm

•Width: 10.8 cm

•Height: 4.40 cm

Inner Carton

•EAN/UPC/GTIN: 1 06 09585 11882 6

•Quantity: 6

•Gross Weight: 1.64 kg

•Tare Weight: 0.22 kg

•Net Weight: 1.42 kg

•Length (cm): 20.3 cm

•Width (cm): 10.8 cm

•Height (cm): 15.9 cm

Outer Carton

•EAN/UPC/GTIN: 2 06 09585 11882 3

•Quantity: 72

•Gross Weight: 19.64 kg

•Tare Weight: 2.62 kg

•Net Weight: 17.02 kg

•Length (cm): 41.9 cm

•Width (cm): 32.4 cm

•Height (cm): 34.3 cm

•

Corrosion-resistant connection

24K gold-electroplated connectors create secure and

extremely durable connections that optimize signal

quality and deliver the best picture and data transfer.

Minimum signal loss

Signal information is inevitably lost going from any digital

source to any TV. Minimum signal loss means you only

lose the least amount of that signal information.
