Pelgrim GVW440L User manual
Instructions for use
Dishwasher
Anleitung
Geschirrspüler
GVW440L
EN User instruction EN 3 - EN 33
DE Anleitung DE 3 - DE 33
Pictograms used - Benutzte Piktogramme
Important information - Wissenswertes
Tip - Tipp
Contact a registered installer to fit your appliance
(see “Installation instructions”). Do not connect the
appliance to the electrical mains until the installation is
complete.
This appliance is intended to be used in household and
similar applications such as:
▷staff kitchen areas in shops, offices and other working
environments;
▷farmhouses;
▷by clients in hotels, motels and other residential type
environments;
▷bed and breakfast type environments.
For EN60335-1:
• This appliance can be used by children aged from
8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
• Children shall not play with the appliance. Cleaning and
user maintenance shall not be done by children without
supervision.
SAFETY INSTRUCTIONS
For IEC60335-1:
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety.
• Packaging material could be dangerous for children!
• This appliance is for indoor household use only.
• To protect against the risk of electrical shock, do not
immerse the unit, cord or plug in water or other liquid.
• Please unplug before cleaning and performing
maintenance on the appliance.
• Use a soft cloth moistened with mild soap, and then
use a dry cloth to wipe it again.
Earthing Instructions
• This appliance must be earthed. In the event of a
malfunction or breakdown, earthing will reduce the
risk of an electric shock by providing a path of least
resistance of electric current. This appliance is equipped
with an earthing conductor plug.
• The plug must be plugged into an appropriate outlet
that is installed and earthed in a ccordance with all local
codes and ordinances.
• Improper connection of the equipment-earthing
conductor can result in the risk of an electric shock.
SAFETY INSTRUCTIONS
• Check with a qualified electrician or service
representative if you are in doubt whether the appliance
is properly grounded.
• Do not modify the plug provided with the appliance, if it
does not fit the outlet.
• Have a proper outlet installed by a qualified electrician.
Use
• When loading items to be washed:
▷Locate sharp items so that they are not likely to
damage the door seal;
▷Warning: Knives and other utensils with sharp points
must be loaded in the basket with their points facing
down or placed in a horizontal position.
• Do not abuse, sit on, or stand on the door or dish rack
of the dishwasher.
• Do not operate your dishwasher unless all enclosure
panels are properly in place.
• Open the door very carefully if the dishwasher is
operating, there is a risk of water squirting out.
• Do not place any heavy objects on or stand on the door
when it is open. The appliance could tip forward.
• Some dishwasher detergents are strongly alkaline.
They can be extremely dangerous if swallowed.
Avoid contact with the skin and eyes and keep children
away from the dishwasher when the door is open.
• Check that the detergent powder is empty after
completion of the wash cycle.
SAFETY INSTRUCTIONS
• Do not wash plastic items unless they are marked
“dishwasher safe” or the equivalent.
• For unmarked plastic items not so marked, check the
manufacturer's recommendations.
• Use only detergent and rinse agents recommended for
use in an automatic dishwasher.
• Never use soap, laundry detergent, or hand washing
detergent in your dishwasher.
• The door should not be left open, since this could
increase the risk of tripping.
• If the supply cord is damaged, it must be replaced
by the manufacturer or its service agent or a similarly
qualified person in order to avoid a hazard.
• During installation, the power supply must not be
excessively or dangerously bent or flattened.
• Do not tamper with controls.
• The appliance needs to be connected to the main water
valve using new hose sets. Old sets should not be
reused.
• To save energy, in stand by mode, the appliance will
switch Off automatically while there is no any operation
in 30 minutes.
SAFETY INSTRUCTIONS
EN 3
CONTENTS
Your dishwasher
Introduction 4
Using your dishwasher
Description 5
Quick start 5
Control panel 6
Water softener 8
Adding salt 9
Preparing and loading dishes 9
Function of the rinse aid and dishwasher detergent 16
Filling the rinse aid reservoir 17
Filling the detergent dispenser 18
Programming the dishwasher
Wash cycle table 19
Starting a cycle wash 20
Changing the program mid-cycle 20
Forget to add a dish? 21
Maintenance
Filtering system 22
Cleaning the spray arms 23
Caring for the dishwasher 24
Cleaning the door 25
Errors
What should I do, if... 26
Error table 26
Technical data sheet
29
Loading the baskets according to EN50242
31
Your dishwasher and the environment
Disposal 33
EN 4
Introduction
You have opted to purchase a Pelgrim dishwasher. Optimum user comfort and easy operation
were paramount during the development of this product.
This manual describes how you can get the most out of your dishwasher. It provides you with
information on how to operate the appliance, as well as background information about how it
works. You will furthermore also find maintenance tips.
The safety instructions that are relevant during the installation are included in the installation
guide. This is intended for the installation technician.
Read this manual before using the appliance. Keep this manual somewhere safe so that
subsequent users can also benefit from the information contained within.
YOUR DISHWASHER
EN 5
USING YOUR DISHWASHER
Description
Features and appearance of baskets and cutlery baskets may vary, depending on your
model.
1. Salt container
2. Corner spray arm
3. Detergent dispenser
4. Rainse aid reservoir
5. Lower spray arm
6. Filtering system
7. Top spray arm
8. Cutlery rack
9. Cup rack
10. Upper spray arm
11. Upper basket
12. Lower basket
Quick start
Please read the corresponding content in this manual for more details about the operation.
Inside Outside
1. Setting the water softener/loading the salt.
2. Removing larges residues on the cutlery/dishes.
3. Loading the baskets.
4. Filling the dispenser and the rinse aid reservoir.
5. Selecting a program and running the dishwasher.
12
11
10
8
3
5
6
4
9
2
1
7
EN 6
USING YOUR DISHWASHER
Control panel
12
14 52 3 6 107 9 118 8
AUTO ECO
P
Operation (push buttons)
1 On/off Press this button to turn on your dishwasher, the screen lights up.
2 Function Press this button to select a function. The corresponding indicator will be
lit.
3 Program Select the appropriate washing program, the selected program indicator
will be lit.
4 Delayed
start Press this button to set a delayed start (up to 24 hours). One press on this
button delays the start by one hour.
5 Alt Press this button for specifically cleaning the load in the selected basket.
You do not have to wait until the whole dishwasher is loaded completely.
The corresponding indicator will be lit.
6Auto door
open After washing, the door will open automatically to achieve better drying
effect. Press the Delay and Alt button together for over three seconds to
cancel the Auto open function for the current cycle.
Indicators
7 Function
indicator
AUTO
ECO
KOUD
Extra cleaning
To wash very dirty, hard to clean dishes. It can only be used with
Intensive, Normal, ECO, Glass and 90 min.
AUTO
ECO
KOUD
Extra drying
To dry dishes more completely. It can only be used with Intensive,
Normal, ECO, Glass and 90 min.
AUTO
ECO
KOUD
Express
Reduce the program time.
