Peerless-AV KOL547-XTR User manual

12015-02-23 #:150-9068-1

ENG

KOL547-XTR, KOL555-XTR

22015-02-23 #:150-9068-1

ENG - Do not begin to install product until you have read and understood the instructions and warnings

contained in this user guide. This product is designed to be installed on wood stud, solid concrete or cinder

block walls. Hardware is included for wood stud, solid concrete and cinder block installation. Before installing

make sure the supporting surface will support the combined load of the equipment and hardware. Screws must

be tightly secured. Do not overtighten screws or damage can occur and product may fail. Never exceed the

Maximum Load Capacity. Always use an assistant or mechanical lifting equipment to safely lift and position

equipment. This product is intended for indoor use only. Use of this product outdoors could lead to product

failure or personal injury. To reduce the risk of electric shock or ﬁre, do not expose product to water or moisture.

Be sure power cord is routed so that it will not be tripped on, stepped on, or pinched by heavy items. Avoid

overloading electrical outlets or extension cords. Always disconnect the power cord from the power outlet

when installing, servicing, or not using the product for an extended period of time. Do not block ventilation

slots or fan exhaust on product. Blocking airﬂow could damage product. Arrange product to allow air to ﬂow

freely around product. Keep product away from direct sunlight or any source of heat. For support please call

800-4-SIGNAGE.

WARNING

Symbols

ENG

WARNING

ENG #

Skip to step.

ENG x3

Screws must get at least three

full turns and ﬁt snug.

ENG

Front of mount.

ENG F

Do not overtighten screws.

ENG

Tools Needed for Assembly.

ENG

7/16"

(11mm)

32015-02-23 #:150-9068-1

Parts (Before beginning, make sure you have all parts shown below).

ENG

B (4)

M5 x 12 mm C (4)

M5 x 25 mm

D (4)

M6 x 12 mm E (4)

M6 x 25 mm

M5/M4/M6 washer

H (4)

M8 x 12 mm

F (4) M8 x 25 mm

G (4)

spacer

I (4)

K (1)

6x1 wrench

L (1)

power strip cable tie

M (6)

A (1)

kiosk

J (2)

key

42015-02-23 #:150-9068-1

Remove.

ENG

Remove.

ENG

52015-02-23 #:150-9068-1

F (4)

62015-02-23 #:150-9068-1

4 5

Replace.

ENG

Knock out.

ENG

Power Cord

ENG

72015-02-23 #:150-9068-1

Replace.

ENG

Replace.

ENG

Peerless-AV Europe

Unit 3 Watford Interchange,

Colonial Way, Watford, Herts,

WD24 4WP, United Kingdom

Customer Care

44 (0) 1923 200 100

www.peerless-av.com

Peerless-AV de Mexico

Ave de las Industrias 413

Parque Industrial Escobedo

Escobedo N.L Mexico 66050

Servicio al Cliente

01-800-849-65-77

www.peerless-av.com

Peerless-AV

2300 White Oak Circle

Aurora, IL 60502

Email: [email protected]

Ph: (800) 865-2112

Fax: (800) 359-6500

www.peerless-av.com

Patent Pending

Peerless Industries, Inc. (“Peerless”) warrants to original end-users of Peerless®products will be free from defects in material and

workmanship, under normal use, for a period of ﬁve years from the date of purchase by the original end-user (but in no case longer than

six years after the date of the product's manufacture). At its option, Peerless will repair or replace, or refund the purchase price of, any

product which fails to conform with this warranty.

In no event shall the duration of any implied warranty of merchantability or ﬁtness for a particular purpose be longer than the

period of the applicable express warranty set forth above. Some states do not allow limitations on how long a implied warranty lasts,

so the above limitation may not apply to you.

This warranty does not cover damage caused by (a) service or repairs by the customer or a person who is not authorized for such service

or repairs by Peerless, (b) the failure to utilize proper packing when returning the product, (c) incorrect installation or the failure to follow

Peerless' instructions or warnings when installing, using or storing the product, or (d) misuse or accident, in transit or otherwise, including

in cases of third party actions and force majeure.

In no event shall Peerless be liable for incidental or consequential damages or damages arising from the theft of any product,

whether or not secured by a security device which may be included with the Peerless® product. Some states do not allow the

exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.

This warranty is in lieu of all other warranties, expressed or implied, and is the sole remedy with respect to product defects. No dealer,

distributor, installer or other person is authorized to modify or extend this Limited Warranty or impose any obligation on Peerless in

connection with the sale of any Peerless®product.

This warranty gives speciﬁc legal rights, and you may also have other rights which vary from state to state.

LIMITED FIVE-YEAR WARRANTY
