Paradox K641 User manual

K641L-EQ00 05/2011

K641/K641LX LCD Keypad

Quick Start

How to Arm

Arming When Exiting (Regular/Force Arm)

To arm your system when exiting:

Arming When Staying (Stay/Instant Arm)

To arm your system when staying:

Overview

K641LX shown

LCD (displays system

status and messages)

Arrow keys (use to scroll the

menu options)

AC light (ON = power ON;

OFF = power OFF)

Status light (ON = zones closed

OFF = zones open

Flash = exit delay)

RX/TX logo (K641LX only) Enter key (saves current data

and exits current menu)

ACC key (press for 2 seconds to

perform an action without

entering an access code)

Clear key (erases current data entry

or reverts to preceding step)

Step Description

1. Enter your [ACCESS CODE].

• To Regular arm, press the [ARM]key (arms entire

area when all zones are closed).

• To Force arm, press the [FORCE]key (arms entire

area without waiting for all zones to close).

2. Select the desired area or press the [0] key for

all areas.

Step Description

1. Enter your [ACCESS CODE].

• To Stay arm, press the [STAY]key (arms area’s

perimeter only, which allows you to remain in the

protected area).

• To Instant arm, press the [5] key (stay arms the area

but an alarm will occur instantly any zone opens)

2. Select the desired area or press the [0] key for

all areas.

Printed in Canada

PAR ADOX. COM

How to Disarm

To disarm your system when entering:

Panic Keys

To send a silent or audible alarm to your security

company, press and hold one of the key combinations

listed below, for two seconds.

Alarm Memory Display

To view the alarms that occurred during the last armed

period:

Trouble Display

The LCD screen will display all troubles when they occur.

To view and clear troubles:

How to Bypass Zones

When a zone is bypassed, it remains unarmed when the

corresponding area is armed. To bypass zones:

Step Description

1. Enter your [ACCESS CODE].

2. Select the desired partition if necessary.

Panic Alarm Key Combination

Police [1] & [3]

Medical [4] & [6]

Fire [7] & [9]

Step Description

1. Disarm the system.

2. Press [MEM]. All zones that were breached

during the last armed period will be

displayed. Use the arrow keys to view zones.

3. Press [CLEAR]to save and exit.

Step Description

1. Press [TBL].

2. Scroll through the list of troubles using the

arrow keys. Refer to the EVO User Guide for

trouble descriptions and instructions.

3. Perform the recommended repair instruction

to clear the trouble. If no instructions are

given, contact your security company.

4. Press [CLEAR]to exit.

Step Description

1. Enter your [ACCESS CODE].

2. Press [BYP].

3. Select the zone you want to bypass by

entering the zone number, e.g., zone 3 = 003).

4. Press [ENTER].

Specifications may change without prior notice.

For complete patent, trademark, certification, and warranty

information, please visit www.paradox.com.
