PANTRYCHIC Smart Storage System User manual

QUICK START INSTRUCTIONS

NOTE: For powdered ingredients, it is recommended to

redistribute ingredients in the SmartCanister™ before

seating on the base unit to loosen up contents.

1. Firmly place the SmartCanister™ in the base tray

of the base unit. Securely place each side of the

After cleaning and completely drying your

SmartCanisters™, follow the following steps to set up your

PantryChic®Smart Storage System.

INITIAL SETUP

To begin setting up your PantryChic® System for the rst

time:

1. PLUG IN THE BASE UNIT.

2. TURN THE POWER SWITCH

ON. The switch is located on

the bottom right side of the

base unit.

3. FOLLOW THE SYSTEM PROMPTS. Turn the SPOON

button to move through each menu and press it to

make selection.

INSERT/REMOVE SMARTCANISTER™ ON BASE UNIT

Large SmartCanisterTM/Small SmartCanisterTM

SmartCanister™ into the designated metal clips

(a,b) and rmly push down.

2. To Remove, lift the SmartCanister™ up, from its

sides. To reconstitute the airtight seal, remove

it from the base unit and place it securely on a

at surface. This will push the bottom cap into

compliance.

*Reminder: SmartCanisters™ cannot be stored on top of

the base unit as the airtight seal is released when afxed

to base unit.

ASSIGN SMARTCANISTER™

1. Place SmartCanister™ on the Base Unit. The

Base Unit Reads “Assign SmartCanister™?”

2. Press the SPOON button, then toggle through

Ingredient list to select an ingredient.

3. Press the SPOON button to complete

assignment. Using the UNIT button,

select the desired default unit of measure

then press the SPOON button. The

system will then proceed to ASSIGNED

SMARTCANISTER™ steps.

AUTO DISPENSING

1. Place a bowl on the base unit scale.

NOTE: DO NOT TOUCH THE BOWL OR

SCALE WHILE SETTING THE QUANTITY TO

DISPENSE AS THIS WILL AFFECT THE AUTO

TARING PROCESS

2. Place a SmartCanister™ on the base unit.

Using the SPOON button, scroll to the desired

quantity. Press the SPOON button to conrm

the quantity, then press the SPOON button to

dispense.

For your safety and continued enjoyment of this

product, always read the instruction book carefully

before using.

MACHINE FUNCTIONS

INGREDIENT STORAGE

SmartCanisters™ are airtight and validated to store over 100 different dry ingredients. Refer to the table below

for the complete list of validated ingredients:

Ingredient Name g/cup Lg Sm Ingredient Name g/cup Lg Sm

Baking powder 170.6g Y Y Flax meal 112g Y Y

Baking soda 220.8g Y Y Flaxseed 168g Y Y

Barley - akes 112g Y N Flour - AP 125g Y Y

Barley - pearled 200g Y Y Flour - AP, sifted 114g Y Y

Basil - dried ground 67.2g Y Y Flour - almond 112g Y Y

Beans - black (dried) 200g Y N Flour - bread 120g Y Y

Beans - garbanzo (dried) 200g Y N Flour - buckwheat 120g Y Y

Beans - lentils (dried) 192g Y N Flour - cake unbleached 128g Y Y

Beans - peas (dried) 145g Y N Flour - carob 103g Y Y

Bread crumbs - dried 108g Y Y Flour - chickpea 92g Y Y

Bread crumbs - panko 56g Y Y Flour - coconut 112g Y Y

Buckwheat - whole kasha 180g Y N Flour - corn, masa 114g Y Y

Bulgur - uncooked 168g N N Flour - gluten-free 160g Y Y

Caraway seeds 107.2g Y N Flour - GF brown rice 158g Y Y

Cereal - oat bran 80g Y N Flour - GF whole grain 120g Y Y

Cereal - Rice Krispies 40g Y N Flour - hazelnut 89g Y Y

Cheese - parm. (grated) 100g Y Y Flour - oat 104g Y Y

Chili Powder 128g Y Y Flour - pastry 106g Y Y

Chocolate chips - mini 170g Y N Flour - potato 160g Y Y

Cinnamon 96g Y Y Flour - quinoa 112g Y Y

Cloves - Ground 104g Y Y Flour - rice (white) 158g Y Y

Cocoa - unsweetened 86g Y Y Flour - rye (dark) 128g Y Y

Coconut milk powder 128g Y Y Flour - rye (light) 102g Y Y

Coffee beans 102.2g Y N Flour - rye (medium) 102g Y Y

Coffee ground 106.7g Y Y Flour - self-rising 120g Y Y

Coffee powder 96g Y Y Flour - semolina 168g Y Y

Cornmeal - WG yellow 122g Y Y Flour - spelt 120g Y Y

Cornstarch 128g Y Y Flour - sorghum 121g Y Y

Cumin - ground 96g Y Y Flour - soy 112g Y Y

Curry Powder 100.8g Y Y Flour - tapioca (starch) 120g Y Y

Dill Weed 49.6g Y Y Flour - teff 135g Y Y

Egg whites - powder 107g Y Y Flour - wheat (WG) 120g Y Y

Erythritol sweetener 192g Y Y Flour - WW pastry 120g Y Y

MACHINE FUNCTIONS

INGREDIENT STORAGE (CONTINUED)

SmartCanisters™ are airtight and validated to store over 100 different dry ingredients. Refer to the table below

for the complete list of validated ingredients:

Ingredient Name g/cup Lg Sm Ingredient Name g/cup Lg Sm

Flour - WW white 125g Y Y Rice - long grain (dry) 185g Y Y

Garlic powder 155.2g Y Y Rosemary leaves 52.8g Y Y

Garlic - granulated 160g Y Y Salt - Celery 134.4g Y Y

Ginger - ground 134.4g Y Y Salt - iodized 288g Y Y

Graham cracker crumbs 104g Y Y Salt - kosher 268.8g Y Y

Granola 112g Y N Salt - sea salt 288g Y Y

Gritz 164g Y Y Salt - Onion 288g Y Y

Gritz (quick) 148g Y Y Sesame seeds 144g Y Y

Guar gum 160g Y Y Splenda 200g Y Y

Herbs de Provence 38.4g Y Y Sprinkles 192g Y Y

Malted milk powder 184g Y Y Stevia sweetener 192g Y Y

Meringue powder 144g Y Y Sugar - coconut 192g Y Y

Milk - dry 120g Y Y Sugar - granulated white 200g Y Y

Millet - whole 220g Y Y Sugar - maple 152g Y N

Nuts - grape 116g Y Y Sugar - powdered 120g Y Y

Nuts - pine”, “ 135g Y N Sugar - powdered sifted 100.1g Y Y

Oats - quick cooking 80g Y N Sunower Seed - Raw 120g Y N

Oats - rolled or akes 80g Y N Tapioca – Pearls-dry 152g Y Y

Oats - steel cut (raw) 160g Y Y Tapioca - quick-cooking 320g Y Y

Onion - Flakes 80g Y Y Tarragon - ground 76.8g Y Y

Onion - Powder 115.2g Y Y Tarragon - leaves 28.8g Y Y

Oregano - dried ground 86.4g Y Y Thyme 43.2g Y Y

Paprika 110.4g Y Y Tumeric - Ground 150.4g Y Y

Parsley Flakes 25.6g Y Y Vital wheat gluten 144g Y Y

Pepper - black ground 134.4g Y Y Wheat - cracked 160g Y Y

Pepper - cayenne 134.4g Y Y Wheat germ 115g Y Y

Pepper - red akes 115.2g Y Y Xanthan gum 144g Y Y

Polenta 160g Y Y Yeast - instant 192g Y Y

Popcorn kernels 202.7g Y N

Poppy seeds 120g Y Y

Pumpkin Seeds 112g Y N

Quinoa - whole 170g Y Y

Rice - brown med. grain 190g Y Y
