Panasonic ET-EMF510C User manual

Model No. ET-EMF510C

Operating Instructions

Replacement Filter Unit Commercial Use

Thank you for purchasing this Panasonic product.

■Carefully read through these Operating Instructions and the operating instructions of the

projector to ensure safe and proper operation.

■Please save this manual for future use.

Attention

●Turn the main power o󰀨 before replacing the air lter unit.

●Make sure that the projector is stable when attaching the air lter unit, and work in an

environment that is safe, even in the event of the air lter unit dropping.

Replacing the air filter unit

1 ) Turn o󰀨 the projector and disconnect the power plug from the wall outlet.

●When the power is to be turned o󰀨, be absolutely sure to follow the procedure

described in “Switching o󰀨 the projector” in the operating instructions of the projector.

2 ) Remove the air lter cover.

●

Remove the air lter cover by turning the air lter cover

xing screw counterclockwise using the Phillips head

screwdriver until it turns freely.

3 ) Remove the air lter unit.

●While gently pressing the area near the center of

the frame on the lens side (front side) of the air

lter unit toward the inside as shown by the arrow,

disengage the frame from the projector tabs,

and draw it out. Then disengage the frame on

the other side from the tabs, and take out the unit.

●After taking o󰀨 the air lter unit, remove any

accumulations of dust and dirt on the area of the

projector where the air lter unit is stowed and on the

air intake of the projector.

Attention

●Take care not to touch the radiator ns or other parts when removing the dust and dirt.

Air lter cover

Air lter cover xing screw

Air lter unit

Area where the air lter unit is stowed

and air intake of the projector

Projector tabs

TQZJ435-1

https://panasonic.cn/

: :

日本福冈县福冈市博多区美野岛四丁目1番62号

2022

松下互联株式会社

2022

Replacing the air filter unit (Continued)

4 ) Insert a new air lter unit (replacement air lter unit) in the projector.

●There is no di󰀨erence between the top and bottom of the air lter unit, but there is a

di󰀨erence between the unit’s front and back. Align the protrusions of the air lter unit with

the grooves in the projector.

●Catch the frame of the air lter unit’s air outlet side on the two tabs at the back of the

projector where the air lter unit is stowed, and proceed with the installation following the

instructions in step 3) in reverse.

• Check that the air lter unit frame has latched onto the tabs where the air lter unit is

stowed in the projector.

Air lter unit

protrusion

Projector

groove

Air lter unit

protrusion

Projector

groove

Projector tabs

5 ) Install the air lter cover on the projector and use a Phillips screwdriver to

tighten the air lter cover xing screw.

●Insert the air lter cover by following the instructions for step 2) in the reverse order.

Attention

●Be sure to install the air lter unit before turning on the projector. Using the projector without

the air lter unit will cause dirt and dust to accumulate inside the projector and could result in

malfunction.

•

When the projector is used without the air lter unit installed, a message is displayed for

about 30 seconds on the projection screen.

●Dispose of the packaging materials properly after unpacking the product.

Note

●The frequency with which the air lter unit needs to be changed depends signicantly on the

environment where the unit is used.

●For procedures on maintaining the air lter unit, refer to the operating instructions supplied with

the projector.

 Disposal

When discarding this product, please contact your local authorities or dealer and ask for the

correct method of disposal.

SS0412AM1042 -PS

Printed in Japan
