Panasonic DVD-LS92 User manual

2011 VIDEO

DVD-LS92

Portable DVD/ CD Player

9" LCD SCreen

High-quality picture in a compact design.

11-Hour Long Life Battery (with use of headphones and brightness set to lowest level)

Enjoy extended viewing without recharging.

DVD/ CD/ JPeg PLayBaCk

Plays all of the most popular formats.

•Slim and Stylish Design

•Car DC Adaptor Included

Screen image simulated.

04/11 Speciﬁcations subject to change without notice.

2011 VIDEO

DVD-LS92 Portable DVD/ CD Player

Playable Discs

DVD DVD-Video •

DVD-R*1/DVD-R DL*1/DVD-RW*1 DVD-Video •

MP3*2• (DVD-R/-R DL)

JPEG • (DVD-R/-R DL)

+R*1/ +R DL*1/ +RW*1 Video •

CD, CD-R/-RW*3 CD-DA •

Video CD •

SVCD •

MP3*2•

JPEG •

auDio system

Dolby®Digital Decode (2 ch)

HigH Quality Picture

LCD Monitor (Widescreen) 9” QVGA

Video D/A Converter 108MHz/ 14bit

HigH Quality sounD

Built-in Speaker 2 ch

Dialog Enhancer •

easy to use

Playback Times*4approx. 11H (with battery pack)

Rechargeable Battery •

Car DC Adaptor •

LCD Selector • (Normal/ Full/ OFF)

Picture Adjustment on LCD • (Bright/ Color/ Contrast/ Tint)

terminal

AV Out •

Headphone Out • (2)

otHers

Video System NTSC

Audio S/N 100dB

Dynamic Range 80dB

Power Supply AC 100-240V, 50/60Hz

Power Consumption (using included AC adaptor) (Approx.) Normal Use 14W

Standby 0.4W

Dimensions, WeigHts

Main Unit Dimensions (W x H x D excluding battery) (Approx.) 9 - 9/ 16 x 1 - 13/ 16 x 6 - 27/ 32 inch

(242.6 x 46 x 173.5 mm)

(Approx.) Weight (including battery) 39.15 oz (1110g)

*1 Discs recorded and ﬁnalized on recording devices.

*2 For contents recorded disc media from CDs for your personal use.

*3 Playability may vary depending on the contents, discs and quality of the recording.

*4 When brightness is set to lowest level and use of headphones.
