ORDERNO. ITD0203006C2

22”Diagonal LCD TV

TX-22LT2F

LH4Chassis

SPECIFICATIONS

Specifications

PowerSource

AC100~240V, 50/60Hz

PowerConsumption

Averageuse:67W

Stand-bycondition:5W

TVset: DC15V, 4.1Amax.

LCD

22-inch(558mm), 16:9aspectratio LCDpanel

Screen Size

19.17-inch (486.7mm)(W)x10.77-inch (273.6mm)(H)x/ 22-

inch (558mm)(Diagonal)

Sound

Speaker

Tweeter(4x7cm 2pcs, 8 ), Woofer( 5cm 2pcs, 4 )

Audio Output

9W (2.5W+2.5W+4.0W (Woofer)), 10%THD

Headphones

M3(3.5mm)Jack x18 impedance

FEATURES

Aero-Hammer DoubleWooferSystem (2Way

4SpeakerSystem)

Receiving Systems/ Band name

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

PAL B,G,H, SECAMB,GSECAML/L’

VHF E2-E12 VHF H1-H2(ITALY)

VHF A-H(ITALY) UHF E21-E69

CATV(S01-S05) CATVS1-S10 (M1-M10)

CATVS11-S20 / (U1-

U10)

CATVS21-S41 (Hyperband)

PAL 525/60

Playback ofNTSCtapefromsome PAL video recorders

(VCR)

M.NTSC

Playback fromM.NTSCVideo recorders(VCR)

NTSC

Playback fromNTSCVideo recorders(VCR)

(AVINPUTONLY)

Aerial-Rear

UHF-VHF

Operating Conditions

Temperature:41°F-95°F(5-35°C)

Humidity:5%-90%RH(non-condensing)

Connection Terminals

AV1

21Pin socket(Audio/Video in, TVout, RGBin)

AV2

21Pin socket(Audio/Video in, Audio/Video out, S-Video, Q

-Link)

AV3

VIDEO

RCAPINTypex1

S-VIDEO

Mini DIN4-pin

AUDIOL-R

RCAPINTypex2

Dimensions(W xHxD)

Including TVStand

586mm x424mm x240mm

TVSetOnly

586mm x388mm x67mm

Weight(Mass)

11.5kg Net

Note:

Design and Specificationsaresubjectto changewithoutnotice.

Weightand Dimensionsshown areapproximate.

Unauthorizedcopying and distribution isaviolation oflaw.

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

1. SafetyPrecautions

1.1. General Guidelines

1. Whenservicing, observetheoriginal leaddress. Ifashortcircuit

isfound, replace all parts whichhavebeenoverheatedor

damagedbytheshortcircuit.

2. Afterservicing, see toitthat all theprotectivedevices suchas

insulation barriers, insulation papersshieldsareproperlyinstalled.

3. Afterservicing, make thefollowing leakagecurrentchecks to

preventthecustomerfrombeing exposedtoshock hazards.

1.2. Touch-CurrentCheck

1. Plug theACcorddirectlyintotheACoutlet. Donotuse an

isolation transformerforthischeck.

2. Connect ameasuring networkfortouchcurrents betweeneach

exposedmetallicparton theset and agood earthground suchas

awaterpipe, as showninFigure1.

3. Use LeakageCurrentTester(Simpson 228 orequivalent) to

measurethepotential across themeasuring network.

4. Check eachexposedmetallicpart, and measurethevoltageat

eachpoint.

5. ReservetheACplug intheACoutlet and repeat eachoftheabove

measure.

6. Thepotential at anypoint(TOUGHCURRENT)expressedas

voltageU1and U2, does notexceedthefollowing values:

Fora. c.:U1=35 V(peak) and U2=0.35 V(peak);

Ford. c.:U1=1.0V,

Note:

ThelimitvalueofU2=0.35 V (peak)for a. c. and U1=1.0V for d. c. correspond tothevalues 0.7

mA(peak)a. c. and 2.0mAd. c.

ThelimitvalueU1=35 V (peak)for a. c. correspond tothevalue70 mA(peak)a. c. for

frequencies greaterthan100 kHz.

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

7. Incase ameasurementisoutofthelimits specified, thereisa

possibilityofashock hazard, and theequipmentshouldbe

repairedand recheckedbeforeitisreturnedtothecustomer.

Figure1

2. Prevention of ElectroStaticDischarge (ESD) to

ElectrostaticallySensitive(ES) Devices

Somesemiconductor (solidstate)devices canbedamagedeasilybystaticelectricity. Such

componentscommonlyarecalledElectrostaticallySensitive (ES)Devices. Examples oftypical

ES devices areintegratedcircuitsand somefield-effecttransistorsand semiconductor "chip"

components. Thefollowing techniques shouldbeusedtohelpreduce theincidence of

componentdamagecausedbyelectro staticdischarge(ESD).

1. Immediatelybeforehandling anysemiconductorcomponentor

semiconductor-equippedassembly, drainoff anyESDon your

bodybytouching aknownearthground. Alternatively, obtainand

wearacommerciallyavailabledischarging ESDwrist strap,

whichshouldberemovedforpotential shock reasonspriorto

applying powertotheunitundertest.

2. Afterremoving anelectrical assemblyequippedwithES devices,

place theassemblyon aconductivesurface suchas alminumfoil,

topreventelectrostaticchargebuildup orexposureofthe

assembly.

3. Use onlyagrounded-tipsoldering iron tosolderorunsolderES

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

devices.

4. Use onlyananti-staticsolderremoval device. Somesolder

removal devices notclassifiedas "anti-static(ESDprotected)"can

generate electrical chargesufficienttodamageES devices.

5. Donotuse freon-propelledchemicals. These cangenerate

electrical charges sufficienttodamageES devices.

6. DonotremoveareplacementES device fromits protective

packageuntil immediatelybeforeyou arereadytoinstall it. (Most

replacementES devices arepackagedwithleadselectrically

shortedtogetherbyconductivefoam, alminumfoil or

comparableconductivematerial).

7. Immediatelybeforeremoving theprotectivematerial fromthe

leadsofareplacementES device, touchtheprotectivematerial to

thechassisorcircuitassemblyintowhichthedevice will be

installed.

Caution

Besureno powerisappliedtothechassisorcircuit, and observe

all othersafetyprecautions.

8. Minimizebodilymotionswhenhandling unpackagedreplacement

ES devices. (Otherwise hamless motion suchas thebrushing

togetherofyourclothes fabricorthelifting ofyourfootfroma

carpetedfloorcangenerate staticelectricity(ESD)sufficient

todamageanES device).

3. About lead free solder(PbF)

Note:Leadislistedas (Pb)intheperiodictableofelements.

Intheinformation below, Pbwill refertoLeadsolder, and PbF will refertoLeadFree Solder.

TheLeadFree Solderusedinour manufacturing process and discussedbelowis(Sn+Ag+Cu).

ThatisTin(Sn), Silver(Ag)and (Cu)although othertypes areavailable.

Thismodel uses PbFree solderinit’smanufactureduetoenvironmental conservation issues.

For service and repairwork, we’dsuggesttheuse ofPbfree solderas well, although Pbsolder

may beused.

PCBsmanufacturedusing leadfree solderwill have thePbF withinaleafSymbol

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

stampedon theback ofPCB.

Caution

-Pbfree solderhas ahighermelting pointthanstandardsolder.

Typicallythemelting pointis50 ~70 ~F(30~40~C)higher. Please

use ahigh temperaturesoldering iron and set itto700 ±20 ~F(370

±10 ~C).

-Pbfree solderwill tend tosplashwhenheatedtoo high (about1100

~For600~C).

Ifyou must use Pbsolder, please completelyremoveall ofthePb

free solderon thepinsorsolderarea beforeapplying Pbsolder. If

thisisnotpractical, besuretoheat thePbfree solderuntil itmelts,

beforeapplying Pbsolder.

-Afterapplying PbF soldertodoublelayeredboards, please check

thecomponentsideforexcess solderwhichmayflow ontothe

opposite side. (see figurebelow)

SuggestedPbfree solder

Thereareseveral kindsofPbfree solderavailablefor purchase. Thisproductuses Sn+Ag+Cu

(tin, silver, copper)solder. However, Sn+Cu(tin, copper), Sn+Zn+Bi (tin, zinc, bismuth)soldercan

alsobeused.

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

4. Self Check

1. Self-Check isusedtoautomaticallycheck thebuslines and

hexadecimal codeoftheTVset.

2. To get intotheSelf-Check modepress theDown( )

button on thecustomercontrolsat thefrontoftheset, at thesame

timepressing theRecall button on theremote control, andthe

screenwill show :

IftheCCU portshave beencheckedand found tobeincorrector notlocatedthen“--”will appear

inplace of“O.K.”.

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

5. ChasisBoardLayout

PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

Other manuals for TX-22LT2F

Table of contents

Other Panasonic LCD TV manuals

Panasonic

Panasonic LCD-201603 Quick start guide

Panasonic

Panasonic TC-L55WT60W User manual

Panasonic

Panasonic TCL32U3 - 32" LCD TV User manual

Panasonic

Panasonic VIERA TX-L32BL6B User manual

Panasonic

Panasonic TX-37LZ8P User manual

Panasonic

Panasonic TX-40CS610EW User manual

Panasonic

Panasonic VIERA TC-L32E5X User manual

Panasonic

Panasonic TC-L19C30 User manual

Panasonic

Panasonic CTL1400 - 14" LCD MONITOR User manual

Panasonic

Panasonic Viera TX-32AS500E User manual

Panasonic

Panasonic Viera TX-36LX70P User manual

Panasonic

Panasonic TX-26LXD52 User manual

Panasonic

Panasonic TCL37U3 - 37" LCD TV User manual

Panasonic

Panasonic Viera TX-32LZD85F User manual

Panasonic

Panasonic TH-L32C10R2 User manual

Panasonic

Panasonic TX-L42E6B User manual

Panasonic

Panasonic TX-L42ET60E User manual

Panasonic

Panasonic TX-L32DT35E User manual

Panasonic

Panasonic TX-P42VT30E User manual

Panasonic

Panasonic TX-25A1DP User manual

Panasonic

Panasonic TC-26LX14 User manual

Panasonic

Panasonic TH-L42U5D User manual

Panasonic

Panasonic TX-R32LX80K User manual

Panasonic

Panasonic TCL32C12 - 32" LCD TV User manual

Popular LCD TV manuals by other brands

LG 32LC4R* Service manual

ViewSonic

ViewSonic N4200w-1 VS10945-1M Service manual

Salora

Salora 22LED1600 user manual

Samsung

Samsung LA32E420 E-manual

Dell

Dell W1900 19 Setting up

Samsung

Samsung LN40C670M1F user manual

Samsung

Samsung Series 4+ user manual

Samsung

Samsung 5 Series user manual

Grundig

Grundig 40 VLE 8230 BP manual

Philips

Philips 43PFL4901/F7 Service manual

Sony

Sony Bravia XBR-43X830C Service manual

LG 32LS350 owner's manual

VIORE

VIORE LED32VF60 Specifications

Toshiba

Toshiba Regza 42HL167 owner's manual

JVC

JVC LT-32A220 instructions

Philips

Philips 20TA1000/93 user manual

Philips

Philips 32PFL3158T/12 quick start guide

Sony

Sony Bravia KDL-V32XBR2 Specifications
