Panasonic KXTGA750E User manual

Installation Manual

Additional Digital Cordless Handset

Model No. KX-TGA750E

Thank you for purchasing a Panasonic product.

Please read this installation manual before using the unit and

save it for future reference.

This unit is an additional handset compatible with the

following series of Panasonic Digital Cordless Phone:

KX-TG7521

You must register this handset with your base unit before it

can be used. This installation manual describes only the

steps needed to register and begin using the handset. Please

read the base unit’s operating instructions for further details.

TGA750E(e).fm Page 1 Thursday, January 21, 2010 6:33 PM

Helpline Tel. No.: U.K. 0844 844 3898 R.O.I. 01289 8333

Accessory information

Supplied accessories

*1 Please read the base unit’s operating instructions for replacement

battery information.

*2 The handset cover comes attached to the handset.

Note:

LPlease read the base unit’s operating instructions for additional/

replacement accessories.

LThis equipment is designed for use in the U.K. and Republic of Ireland.

LIn the event of problems, you should contact your equipment supplier

in the first instance.

Sales and support information

Customer Care Centre

LFor customers within the U.K.: 0844 844 3898

LFor customers within the Republic of Ireland: 01289 8333

LVisit our website for product information: www.panasonic.co.uk

LE-mail: customer[email protected]

Accessory item/Part number Quantity

Charger/PNLC1010ZM1 1

AC adaptor/PQLV219EW or PQLV219EZ 1

Rechargeable batteries*1/

HHR-55AAAB or N4DHYYY00005

Handset cover*2 1

Belt clip/PNKE1054Z1 1

TGA750E(e).fm Page 2 Thursday, January 21, 2010 6:33 PM

Helpline Tel. No.: U.K. 0844 844 3898 R.O.I. 01289 8333

Direct Sales at Panasonic U.K.

LOrder accessory and consumable items for your product with ease and

confidence by phoning our Customer Care Centre Monday - Thursday

9:00am - 5:30pm, Friday 9:30am - 5:30pm (Excluding public holidays).

LOr go on line through our Internet Accessory ordering application at

www.pas-europe.com

LMost major credit and debit cards accepted.

LAll enquiries transactions and distribution facilities are provided

directly by Panasonic U.K. Ltd.

LIt couldn’t be simpler!

LAlso available through our Internet is direct shopping for a wide range

of finished products, take a browse on our website for further details.

Setting up

Connection/Wall mounting

Note:

LUse only the supplied Panasonic AC adaptor PQLV219E.

LThe AC adaptor must remain connected at all times. (It is normal for

the adaptor to feel warm during use.)

LMake sure that the wall is strong enough to support the weight of the

unit.

(220-240 V AC,

50/60 Hz)

25 mm

Screws

(Not supplied)

Hooks

TGA750E(e).fm Page 3 Thursday, January 21, 2010 6:33 PM

Helpline Tel. No.: U.K. 0844 844 3898 R.O.I. 01289 8333

Battery installation/Battery charge

Important:

LUse the supplied rechargeable batteries. For replacement, we

recommend using the Panasonic rechargeable batteries noted in the

base unit’s operating instructions.

LWipe the battery ends (S, T) with a dry cloth.

LAvoid touching the battery ends (S, T) or the unit contacts.

LConfirm correct polarities (S, T).

LUSE ONLY Ni-MH batteries AAA (R03) size.

LDo NOT use Alkaline/Manganese/Ni-Cd batteries.

Charge for about 7 hours.

LWhen the batteries are fully charged, the charge indicator goes off and

“Fully charged”is displayed.

Note:

LWhen the language selection is displayed after installing the batteries

for the first time, you can select your desired language.

{V}/{^}: Select your desired language. iMi{ic}

LThe handset display may show “Please wait for 1 minute.”

when the handset is placed on the charger if it is not registered to the

base unit.

LIf the batteries are fully charged, but the operating time seems to be

shorter, clean the battery ends (S, T) and the charge contacts with a

dry cloth and charge again.

Confirm “Charging”

is displayed.

Rechargeable

Ni-MH ONLY

TGA750E(e).fm Page 4 Thursday, January 21, 2010 6:33 PM

Helpline Tel. No.: U.K. 0844 844 3898 R.O.I. 01289 8333

Registering the handset to the base unit

Ensure that the handset is switched on. If it is not on, press and hold

{ic}for few seconds to turn the handset on.

1Handset:

Lift the handset and press {ic}.

2Base unit:

Press and hold {x} for about 5 seconds, until the registration tone

sounds.

LIf all registered handsets start ringing, press the same button to

stop. Then repeat this step.

3Handset:

Place the handset on the base unit.

LContinue the operation even when the handset display shows

“Please wait for 1 minute.”.

4With the handset still on the base unit, wait until a confirmation tone

sounds and wis displayed.

Note:

LIf an error tone sounds, or if _is displayed, register the handset

according to the base unit’s operating instructions.

TGA750E(e).fm Page 5 Thursday, January 21, 2010 6:33 PM

Helpline Tel. No.: U.K. 0844 844 3898 R.O.I. 01289 8333

For your safety

To prevent severe injury and loss of life/property, read this section carefully before

using the product to ensure proper and safe operation of your product.

WARNING

Power connection

LCompletely insert the AC adaptor/power plug into the power outlet. Failure to do

so may cause electric shock and/or excessive heat resulting in a fire.

LRegularly remove any dust, etc. from the AC adaptor/power plug by pulling it

from the power outlet, then wiping with a dry cloth. Accumulated dust may cause

an insulation defect from moisture, etc. resulting in a fire.

LUnplug the product from power outlets if it emits smoke, an abnormal smell, or

makes an unusual noise. These conditions can cause fire or electric shock.

Confirm that smoke has stopped emitting and contact an authorised service

centre.

Installation

LTo prevent the risk of fire or electrical shock, do not expose the product to rain or

any type of moisture.

LDo not place or use this product near automatically controlled devices such as

automatic doors and fire alarms. Radio waves emitted from this product may

cause such devices to malfunction resulting in an accident.

Operating safeguards

LThe use of excessive sound volume through earphones, headphones, or

headsets may cause hearing loss.

CAUTION

Installation and location

LThe AC adaptor is used as the main disconnect device. Ensure that the AC outlet

is installed near the product and is easily accessible.

Battery

LWe recommend using the supplied batteries or additional/replacement batteries

noted in the base unit’s operating instructions for replacement battery

information. USE ONLY rechargeable Ni-MH batteries AAA (R03) size.

LDo not mix old and new batteries.

TGA750E(e).fm Page 6 Thursday, January 21, 2010 6:33 PM

Helpline Tel. No.: U.K. 0844 844 3898 R.O.I. 01289 8333

LDo not open or mutilate the batteries. Released electrolyte from the batteries is

corrosive and may cause burns or injury to the eyes or skin. The electrolyte is

toxic and may be harmful if swallowed.

LExercise care when handling the batteries. Do not allow conductive materials

such as rings, bracelets, or keys to touch the batteries, otherwise a short circuit

may cause the batteries and/or the conductive material to overheat and cause

burns.

LCharge the batteries provided with or identified for use with this product only, in

accordance with the instructions and limitations specified in this manual.

LOnly use a compatible base unit (or charger) to charge the batteries. Do not

tamper with the base unit (or charger). Failure to follow these instructions may

cause the batteries to swell or explode.

Other information

LOperating the product near electrical appliances may cause interference. Move

away from the electrical appliances.

LUse only the power cord and batteries indicated in this manual. Do not dispose

of batteries in a fire. They may explode. Check with local codes for possible

special disposal instructions.

Routine care

LWipe the outer surface of the product with a soft moist cloth.

LDo not use benzine, thinner, or any abrasive powder.

Notice for product disposal, transfer, or return

LThis product can store your private/confidential information. To protect your

privacy/confidentiality, we recommend that you erase information such as

phonebook or caller list entries from the memory before you dispose of, transfer,

or return the product.

TGA750E(e).fm Page 7 Thursday, January 21, 2010 6:33 PM

Helpline Tel. No.: U.K. 0844 844 3898 R.O.I. 01289 8333

Information for Users on Collection and Disposal of Old Equipment and used

Batteries

These symbols (1, 2, 3) on the products, packaging, and/or accompanying

documents mean that used electrical and electronic products and batteries should

not be mixed with general household waste.

For proper treatment, recovery and recycling of old products and used batteries,

please take them to applicable collection points, in accordance with your national

legislation and the Directives 2002/96/EC and 2006/66/EC.

By disposing of these products and batteries correctly, you will help to save

valuable resources and prevent any potential negative effects on human health and

the environment which could otherwise arise from inappropriate waste handling.

For more information about collection and recycling of old products and batteries,

please contact your local municipality, your waste disposal service or the point of

sale where you purchased the items.

Penalties may be applicable for incorrect disposal of this waste, in accordance with

national legislation.

For business users in the European Union

If you wish to discard electrical and electronic equipment, please contact your

dealer or supplier for further information.

Information on Disposal in other Countries outside the European Union

These symbols (1, 2, 3) are only valid in the European Union. If you wish to

discard these items, please contact your local authorities or dealer and ask for the

correct method of disposal.

Note for the battery symbol

This symbol (2) might be used in combination with a chemical symbol (3). In this

case it complies with the requirement set by the Directive for the chemical involved.

123

TGA750E(e).fm Page 8 Thursday, January 21, 2010 6:33 PM

Helpline Tel. No.: U.K. 0844 844 3898 R.O.I. 01289 8333

Declaration of Conformity:

LPanasonic System Networks Co., Ltd. declares that this equipment is

in compliance with the essential requirements and other relevant

provisions of Radio & Telecommunications Terminal Equipment

(R&TTE) Directive 1999/5/EC.

Declarations of Conformity for the relevant Panasonic products

described in this manual are available for download by visiting:

http://www.doc.panasonic.de

Contact to Authorised Representative:

Panasonic Testing Centre

Panasonic Marketing Europe GmbH

Winsbergring 15, 22525 Hamburg, Germany

TGA750E(e).fm Page 9 Thursday, January 21, 2010 6:33 PM

PNQX2541YA DC0110DN1010 (A)

Sales Department:

Panasonic House, Willoughby Road, Bracknell, Berkshire, RG12 8FP

1-62, 4-chome, Minoshima, Hakata-ku, Fukuoka 812-8531, Japan

This material is copyrighted by Panasonic System Networks Co., Ltd.,

and may be reproduced for internal use only. All other reproduction, in

whole or in part, is prohibited without the written consent of Panasonic

System Networks Co., Ltd.

TGA750E(e).fm Page 10 Thursday, January 21, 2010 6:33 PM

Table of contents

Other Panasonic Handset manuals

Panasonic

Panasonic KX-TGA510M - 5.8GHz Accessory Handset User manual

Panasonic

Panasonic KX-TGA520C User manual

Panasonic

Panasonic KX-TGA820EX User manual

Panasonic

Panasonic KX-TGWA41 User manual

Panasonic

Panasonic KX-TG2559LBS User manual

Panasonic

Panasonic KX-TGA560B - Cordless Extension Handset User manual

Panasonic

Panasonic KX-TGA661E User manual

Panasonic

Panasonic KX-TGA271B User manual

Panasonic

Panasonic KX-TD7696 User manual

Panasonic

Panasonic KX-TGA840E User manual

Panasonic

Panasonic KX-TGA840EX User manual

Panasonic

Panasonic KX-TGA810EX User manual

Panasonic

Panasonic KX-TGA740B - Cordless Extension Handset Instruction Manual

Panasonic

Panasonic KX-TCA130EX User manual

Panasonic

Panasonic KX-TD7685 - Wireless Digital Phone User manual

Panasonic

Panasonic KX-TGEA60M User manual

Panasonic

Panasonic KX-TGA731EX User manual

Panasonic

Panasonic KX-TPA60 User manual

Panasonic

Panasonic KX-TGA680 User manual

Panasonic

Panasonic KX-TGFA30E User manual

Panasonic

Panasonic KX-TGA950B User manual

Panasonic

Panasonic KX-TGA550C User manual

Panasonic

Panasonic KX-PRXA10 User manual

Panasonic

Panasonic KX-TGA820EX User manual

Popular Handset manuals by other brands

Swissvoice

Swissvoice ePure HD manual

Philips

Philips TD6736/BH051P user manual

ASCOM

ASCOM I62 - user manual

LG-Ericsson

LG-Ericsson LIP-9010 user guide

GE 1583 user guide

iiNet

iiNet Handset Quick installation guide

ASCOM

ASCOM 9p23 user guide

AT&T

AT&T DLP70110 user manual

AirCell

AirCell ST 3100 user manual

Eaton

Eaton HHIR-LCD-PROG Basic operations

Mitel

Mitel 112 manual

SBC

SBC SBC-381H installation manual

Mitel

Mitel 5602 user guide

ASCOM

ASCOM d81 Messenger Safety instructions

SpectraLink

SpectraLink 7522 quick start guide

Avaya

Avaya L100 Series Release notes

ooma

ooma HD2 Handset quick start guide

Yealink

Yealink IPW56 Quick reference guide
