Panasonic NV GS400EG-S User manual

Panasonic NV GS400EG-S

Panasonic's vision of the digital future is driven by the needs and

aspirations of its business customers and millions of consumers

around the world who use its products every day. The company

shares their dream to live a fuller life by providing ways of working

smarter and enjoying the rewards of technological advances.

www.dooyoo.co.uk :: Photography :: Digital Camcorder :: Panasonic NV GS400EG-S

General

Product Type Camcorder

Width 8.1 cm

Depth 17.8 cm

Height 8 cm

Weight 0.7 kg

Enclosure Colour Silver

Main Features

Camcorder Sensor Resolution 1.0 Mpix

Webcam Capability Yes

Media Type Mini DV

Colour Support Colour

Optical Sensor Type 3CCD

Optical Sensor Size 1/4.7"

Min Illumination 1 lux

Analogue Video Format PAL

Digital Zoom 600 x

Recording Speed SP, LP

Shooting Modes Digital photo mode, frame movie mode

Shooting Modes Spotlight, portrait mode, surf & snow, low light, sports m

ode

Special Effects Wipe, solarisation, Negative, Sepia, Mosaic, Stretch, Trai

l, Slim, Mirror, Gain-up, Mix, Picture-in-Picture, Strobe

Faders Black fader

Image Stabiliser Optical

Max Shutter Speed 1/8000 sec

Min Shutter Speed 1/2 sec

Exposure Modes Programme, automatic

White Balance Custom, automatic, presets

White Balance Presets Indoor, outdoor

Digital Video Format MPEG-4

Still Image Format JPEG

Remote Control Remote control - infrared

Video Capture 320 x 240 - 6 fps - web camera mode ¦ MPEG-4 - 320 x 240

¦ MPEG-4 - 176 x 144

Memory / Storage

Flash Memory 8 MB Flash - SD Memory Card

Image Storage JPEG 2288 x 1728 ¦ JPEG 1600 x 1200 ¦ JPEG 1280 x 960 ¦

JPEG 640 x 480

Camera Flash

Camera Flash Pop-up flash

Guide Number (m / ISO 100) 6

Flash Modes Auto mode, flash OFF mode

Lens System

Type Zoom lens - 3.3 mm - 39.6 m - f/1.6-2.8

Focal Length 3.3 mm - 39.6 m

Focus Adjustment Automatic, manual

Auto Focus TTL contrast detection

Lens Aperture F/1.6-2.8

Optical Zoom 12 x

Zoom Adjustment Motorised drive

Filter Size 43 m

Lens Manufacturer Leica

Additional Features

DV input Yes

Edit Functions Audio dubbing

Low Lux / Night Mode Yes

Digital Still Camera Function Yes

Search Modes Edit search

Time Code Yes

Additional Features USB 2.0 compatibility, backlight compensation, date/time

stamp, DPOF support, PictBridge support, accessories hot

shoe

Viewfinder

Viewfinder Type Electronic

Viewfinder Colour Support Colour

Viewfinder Diagonal Size 0.3"

Viewfinder Resolution 123,000 pixels

Display

Type LCD display - TFT active matrix - 3.5" - colour

Display Form Factor Rotating

Display Format 200,000 pixels

Microphone

Type Microphone - built-in

Microphone Technology Electret condenser

Microphone Operation Mode Stereo

Microphone Features Zoom, wind noise reduction

Connections

Connector Type 1 x microphone ¦ 1 x headphones ¦ 1 x IEEE 1394

(FireWire/i.LINK) ¦ 1 x composite video/audio (input/outpu

t) ¦ 1 x S-Video input / output ¦ 1 x USB

Expansion Slot(s) 1 x SD Memory Card

Software

Software Drivers & Utilities

Miscellaneous

Included Accessories Camcorder shoulder strap, lens cap, wired remote control

with microphone

Cables Included A/V cable ¦ USB cable

Power

Power Device Power adapter - external

Battery

Supported Battery Details 1 x Li-ion rechargeable battery ( included )
