OPTI-UPS 280ES User manual

User’s Guide

POWER ENHANCED SERIES

Models 280ES, 420ES, 650ES, 1000ES,

1400ES

OPTI-UPS and OPTI-SAFE are trademarks of OPTI-UPS Corporation

For your records

The serial number of your UPS is on the rear panel. You should note the serial

number in the space provided below. Retain this booklet as a permanent

record of your purchase to aid in identification in the event of theft or loss.

Model No:

Serial No.:

Purchase Date:

LIMITED WARRANTY

What the warranty covers:

We warrant this product to be free from defects in material and workmanship during the

warranty period. If a product proves to be defective in material or workmanship during the

warranty period, we will at our sole option repair or replace the product with a like product.

How long the warranty is effective:

Our UPS products which are purchased and installed in the contiguous United States or

Canada are warranted for three (3) years for parts, two (2) years for labor and two (2)

years for the batteries from the date of the first consumer purchase. For UPS products

which are located outside of the contiguous United States or Canada, contact your dealer

for warranty information.

Who the warranty protects:

This warranty is valid only for the first consumer purchaser.

What the warranty does not cover:

1. Any product on which the serial number has been defaced, modified or removed.

2. Damage, deterioration or malfunction resulting from:

a) Accident, misuse, neglect, fire, water, or other acts of nature, unauthorized

productmodification,orfailuretofollowinstructionssuppliedwiththeproduct.

b) Repair or attempted repair by anyone not authorized.

c) Any damage of the product due to shipment.

d) Removal or installation of the product.

e) Causes external to the product.

f) Use of supplies or parts not meeting our specifications.

g) Normal wear and tear.

h) Any other cause which does not relate to a product defect.

3. Removal, installation and set-up service charges.

Limitation of implied warranties:

THERE ARE NO WARRANTIES, EXPRESS OR IMPLIED, WHICH EXTEND BEYOND THE

DESCRIPTION CONTAINED HEREIN INCLUDING THE IMPLIED WARRANTY OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

Exclusion of damages:

OURLIABILITYISLIMITEDTOTHECOSTOFREPAIRORREPLACEMENTOFTHEPRODUCT.WE

SHALL NOT BE LIABLE FOR:

1. DAMAGE TO OTHER PROPERTY CAUSED BY ANY DEFECTS IN THE PRODUCT*,

DAMAGESBASEDUPONINCONVENIENCE,LOSSOFUSEOFTHEPRODUCT,LOSS

OF TIME, LOSS OF PROFITS, LOSS OF BUSINESS OPPORTUNITY, LOSS OF

GOODWILL, LOSS OF DATA, LOSS OF SOFTWARE, COSTS OF SUBSTITUTE

EQUIPMENT, INTERFERENCE WITH BUSINESS RELATIONSHIPS, CLAIMS BY THIRD

PARTIES, OR OTHER COMMERCIAL LOSS, EVEN IF ADVISED OF THE POSSIBILITY

OF SUCH DAMAGES.

2. ANY OTHER DAMAGES, WHETHER INCIDENTAL, CONSEQUENTIAL OR

OTHERWISE.

3. ANY CLAIM AGAINST THE CUSTOMER BY ANY OTHER PARTY.

Effect of state law:

This warranty gives you specific legal rights, and you may also have otherrights which vary

from state to state. Some states do not allow limitations on implied warranties and/or do not

allow the exclusion of incidental or consequential damages, so the above limitations and

exclusions may not apply to you.

Life Support:

We do not recommend the use of our UPS products for life support equipment or direct care

where failure of a UPS product could cause failure of, or diminished effectiveness of the life

support equipment or patient care.

*Except as expressly provided for by the UPS “Equipment Protection Policy”

EFFECTIVE October 1, 1997

280ES / 420ES / 650ES / 1000ES / 1400ES 1

TABLE OF CONTENTS

1. INTRODUCTION

1.1 Overview 7

1.2 Smart Buck and Boost Line Conditioning 7

1.3 User Replaceable Battery Design 7

1.4 Advanced Interface to Communicate with Computer 8

1.5 User Configurable Settings 8

1.6 Site Wiring Fault Indicator 8

1.7 Schedule Shutdown & Startup 8

1.8 Data-Line Surge Protection 8

2. UPS Controls

2.1 External Views 9

Front Panel Controls

2.2 On/Off Button 13

2.3 Test/Silence Button 13

2.4 Status Indication 14

Rear Panel Controls

2.5 Site Wiring Fault Indicator 16

2.6 User Configurable Settings 16

2.7 Communication Port and Pin Assignments 17

2.8 Data-Line Surge Suppression 18

3. INSTALLATION AND OPERATION

3.1 Unpacking and Inspection 19

3.2 Placement 19

3.3 Determining How Much Equipment You

Can Connect to Your UPS 20

3.4 Powering Up Your UPS 20

3.5 Connecting Your Equipment to the UPS 21

3.6 Operation and Functional Test 22

3.7 Storage Instructions 22

4. SPECIFICATIONS

4.1 Electrical Specifications 23

4.2 Mechanical Specifications 25

4.3 Environmental Specifications 25

5. TROUBLESHOOTING

5.1 Troubleshooting Chart 27

6. User Replaceable Battery

6.1 Warning 28

6.2 Battery Replacement Procedure for 280ES/420ES/650ES 29

2280ES / 420ES / 650ES / 1000ES / 1400ES

6.3 Battery Replacement Procedure for 1000ES/1400ES 30

280ES / 420ES / 650ES / 1000ES / 1400ES 3

IMPORTANT SAFETY INSTRUCTIONS

SAVE THESE INSTRUCTIONS !

•WHEN REPLACING BATTERIES, USE THE SAME NUMBER AND THE FOLLOWING TYPE

BATTERIES:SEALEDLEAD-ACIDMAINTENANCEFREE(280ES:One7AH/12V)(420ES:One,

7AH/12V) (650ES: One, 12AH/12V) (1000ES: Two, 12AH/12V) (1400ES: Two, 12AH/12V)

•PROPER DISPOSAL OF BATTERIES IS REQUIRED. REFER TO YOUR LOCAL CODES FOR

DISPOSAL REQUIREMENTS.

INSTRUCTIONS IMPORTANTES CONCERNANT LA SÉCURITE

•CONSERVER CES INSTRUCTIONS. CETTE NOTICE CONTIENT DES INSTRUCTIONS

IMPORTANTES CONCERNANT LA SÉCURITE.

•POUR LE REMPLACEMENT UTILISER LE MÊME NOMBRE DE BATTERIES DU MODÉLE

SUIVANT: (280ES: 1, 7AH/12V) (420ES: 1, 7AH/12V) (650ES: 1, 12AH/12V) (1000ES: 2,

12AH/12V) (1400ES: 2, 12AH/12V)

•L'ÉLIMINATION DES BATTERIES EST RÈGLEMENTÉE. CONSULTER LES CODES LOCAUX À

CET EFFET.

DIESE ANLEITUNG ENTHÄLT WICHTIGE SICHERHEITSANWEISUNGEN.

DIESE ANLEITUNG ZUR WEITERLEITUNG GRIFFBEREIT BEHALTEN.

•BEIM AUSTAUSCHEN DER BATTERIEN DIESELBE NUMMER UND FOLGENDES

BATTERIENTYP BENUTZEN: BLEI-SÄURE WARTUNGSFREI (280ES: 1-7AH/12V) (420ES:

1-7AH/12V) (650ES: 1- 12AH/12V) (1000ES: 2-12AH/12V) (1400ES: 2-12AH/12V)

•RICHTIGEVERÄUßERUNGDERBATTERIENISTERFORDERLICH.INDEN LOKALKODIZESUM

DIE VERÄUßERUNGSERFORDERNISSE NACHSCHAUEN.

4280ES / 420ES / 650ES / 1000ES / 1400ES

CAUTION: !

THE UPS CONTAINS VOLTAGES WHICH ARE POTENTIALLY

HAZARDOUS. ALL REPAIRS SHOULD BE PERFORMED BY QUALIFIED

SERVICE PERSONNEL.

THE UPS HAS ITS OWN INTERNAL ENERGY SOURCE (BATTERY). THE

OUTPUT RECEPTACLES MAY BE LIVE EVEN WHEN THE UPS IS NOT

CONNECTED TO AN AC SUPPLY.

Safe and continuous operation of the UPS depends partially on the care taken by users.

Please observe the following precautions.

•Do not disassemble the UPS.

•Do not attempt to power the UPS from any receptacle except a 2-pole

3-wire grounded receptacle.

•Do not place the UPS near water or in environments of excessive humidity.

•Do not allow liquid or any foreign objects to get inside the UPS.

•Do not block air vents on the side of the UPS.

•Do not plug appliances, such as hair dryers, into the UPS receptacles.

•Do not place the UPS under direct sunshine or close to heat-emitting sources.

•This UPS is intended for installation in a temperature controlled, indoor area free of

conductive contaminants.

A certified detachable power supply cord is to be used with this equipment. For the

280ES,420ES,650ES,and1000ES atypenotlighterthan SJT18AWGshouldbeused.

For the 1400ES, a type not lighter than SJT 16 AWG should be used.

280ES / 420ES / 650ES / 1000ES / 1400ES 5

VORSICHT: !

DIEUPS*ENTHÄLTSPANNUNGEN,DIEMÖGLICHERWEISEGEFÄHRLICH

SIND. ALLE REPARATUREN SOLLTEN VON QUALIFIZIERTEN

MONTEUREN DURCHGEFÜHRT WERDEN.

DIE UPS HAT EINE EIGENE INNERE STROMVERSORGUNG

(BATTERIE). DIE AUSGANGSANSCHLÜSSE KÖNNEN ALSO UNTER

STROM STEHEN, SELBST DANN, WENN DIE UPS NICHT AN EINEN

WECHSELSTROMKREIS ANGESCHLOSSEN IST.

Um die UPS auf Dauer sicher bedienen zu können, sollte der Benutzer auf folgende

Vorsichtsmaßnahmen genau achten:

•Die UPS nicht auseinandernehmen.

•Die Stromversorgung sollte nur durch einen 2-poligen, dreiadrigen, geerdeten

Anschluß erfolgen.

•Die UPS nicht in der Nähe von Wasser oder in Umgebungen übermäßiger

Feuchtigkeit aufstellen.

•Flüssigkeiten oder Fremdobjekte dürfen nicht in das Innere der UPS dringen.

•Lufteinfuhr an der Vorderseite und Luftaustritt an der Rückseite sollten nicht

behindert sein.

•Elektrogeräte, wie z. B. Haartrockner u.a. sollten nicht an die UPS angeschlossen

werden.

•Die UPS nicht direkter Sonnenbestrahlung oder Heizgeräten aussetzen.

•Die Steckdose solltenahe dem Gerätinstalliert und gut zugänglich sein,um sievom

Wechselstromeingang zu isolieren. Zur Trennung vom Wechselstromkreis den

Stecker aus der Steckdose ziehen.

Zur Stromzufuhr sollte ein gesichertes, trennbares Kabel benutzt werden. Für eine

Stromstärke bis 10A sollte dieses mit H05VV-F 3C; 0.75 mm² benutzt werden.

*UPS (Uninterrupted Power Supply) = Unterbrechungsfreie Stromversorgung

6280ES / 420ES / 650ES / 1000ES / 1400ES

ATTENTION: !

L'UPS contient de la haute tension qui peut poser risques. Toute

réparation doit être exécutéé par du personnel de service qualifié.

L'UPS a sa propre alimentation secteur interne (batterie). Les prises

femelles peuvent être chargées même si l'UPS n'est pas relié à une

alimentation secteur.

La sécurité de l'opération de I'UPS dépend des soins de l'utilisateur. Veuillez lire les

précautions ci-dessous:

•Ne jamais démonter I'UPS.

•Ne jamaisessayer debrancherl'UPSà uneprisefemellesaufà une quipossédeune

terre et 2 poles.

•Ne jamais mettre I'UPS prés de l'eau ou dans un milieu trop humide.

•Ne jamais faire entrer du liquide ou d'objet étranger dans I'UPS.

•Ne jamais boucher les ventilations d'air de I'UPS ou l'aération arrière.

•Ne jamais brancher d'appareils, comme les sèche-cheveux, à la prise femelle de

l'UPS.

•Ne jamais placer l'UPS aux rayons directs du soleil ou près d'autre source de

chaleur.

•La fiche d'alimentation secteur doit être installée tout près de cet appareil. Elle doit

être facilement accessible pourl'isoler de laprisesecteurde sortie. Pour couperla

connexion, enlever la fiche de la prise femelle.

Un câble d'alimentation secteur amovible et certifié est utilisé avec cet appareil. Pourun

courant jusqu'à 10A, un câble qui n'est pas plus légèr que 0,75mm² doit être utilisé.
